How to put rav4 spare tire cover back on


Another way to put the tire cover back on.

Greetings,

It has been a while since I have posted. I finally took the plunge and removed the spare tire cover from my spare to see what was under it. I knew that there was a lot of leaves and stuff in there from the Fall because stuff kept falling out. I wanted to get that junk out before it started to rot.

When I picked up the car last Summer, the delivery lady at the dealership warned me never to take off the cover unless I really needed to because I would never be able to get it back on. Well, now I needed to take it off to clean it out, even though it was rumored to be difficult to put back on.

In the end, it was an effort to do it, but far from impossible.

The word descriptions on this forum for how to do this job were not helping me much, so just for grins (and perhaps to enlighten someone who has not done this yet) I decided to post some photos of what I found and how I got the tire cover back on. I hope this is not considered redundant information. The following procedure worked for me. Others may do it a different way.

To get the cover off, I opened the door to gain access to the handhold at the bottom of the door. There is an opening where you can reach the elastic, but the opening is covered by the rear bumper when the door is closed.

So I opened the door and peeled the elastic off of the bottom of the tire, and then pulled the elastic off of the top of the tire, and the cover just came off. That was pretty easy. Here is what I found inside of the cover:

/forums/album_pic.php?pic_id=4538

It's the directions for how to put the cover back on, virtually destroyed by the the weather. LOL! I wish I had taken off the cover earlier. I wish the delivery lady had told me that the directions were inside! Dang! Anyway, the directions are still readable, so I put them into the car to dry out. Then I took the wheel off and found this:

/forums/album_pic.php?pic_id=4537

Dirt and crud! And that is only half of it because a bunch of it fell out when I took the wheel off.

I also found this little trick....

/forums/album_pic.php?pic_id=4542

the elastic does not go all the way around the tire. The sides are not stretchy. The little non-stretchy areas of the cover are what go into the narrow slots along the sides of the tire.

So I cleaned it all up, took a pressure reading of the spare, remounted the spare onto the bracket, and then tried to put the cover back on. Here is how I did it.

First, I jammed a blanket into the door to keep the door open while I pushed on the cover to get it back on. The door has to be open in order to gain access to the opening at the bottom.

/forums/album_pic.php?pic_id=4539

Then I took the cover and stretched the top elastic over the top of the tire as it says to do in the directions. You can kind of see in this photo that the bottom elastic is not over the bottom of the tire yet.

/forums/album_pic.php?pic_id=4543

In case you cannot see it in that photo, here is a closeup:

/forums/album_pic. php?pic_id=4541

The sides and bottom of the elastic were all rolled up so I worked my fingers down both sides from the top until I had unrolled the elastic all the way to the bottom. Then I stretched the bottom elastic over bottom of the tire as best I could. The sides and bottom were still not completely tucked in since it is impossible to get your fingers into those skinny slots on the side of the tire.

But here is the other trick. You rotate the tire cover 90 degrees either way while it is on the tire. I just twisted the cover around so that different parts of the elastic were accessible in the handhold at the bottom of the tire and tucked it all the way in while it was down there. I twisted it counter clockwise to do the left hand side and clockwise to do the right hand side. Then when I was done I twisted it to the proper orientation and finished tucking in the bottom elastic.

One more trick is that by twisting the tire cover back and forth it sort of settles in and seats itself on the wheel.

Just to make sure that it was not blind luck the first time, I took the cover off again and installed it again. The procedure works. It isn't dead easy, but it can be done in a few minutes.

Given the amount of decomposing crud I found inside of my tire cover, I think that I might make this a regular maintenance exercise from now on. I let it go way too long this time. You are supposed to check the tire pressure of the spare on a regular basis anyway.

I hope this helps any others who have wondered about this system, and if not, I hope you got a chuckle out of it anyway.
