Off Road vehicles with an aggressive tire tread, add 2oz to the recommended application..jpg)
ABC Balancing Beads can be installed through the valve stem. For any questions please feel free to contact us at the number located at the top of your screen.
Light Truck
6000 lbs or less
6001 lbs to 10,000 lbs
Delivery & Light Truck
10,001 lbs to 14,000 lbs
14,001 lbs to 16,000 lbs
Medium Duty Truck
16,001 lbs to 19,500 lbs
19,001 lbs to 26,000 lbs
Heavy Duty Truck & Bus
26,001 lbs to 33,000 lbs
33,001 lbs to 105,000+ lbs
Off Road and Lifted Pickups
Tire Size:
215/75R14 4oz
205/70R14 4oz
215/70R14 4oz
Tire Size:
700R15 4oz
7.50R15 6oz
8.25R15 6oz
9R15 8oz
10R15 8oz
215/80R15 4oz
195/75R15 40z
205/75R15 40z
215/75R15 4oz
225/75R15 4oz
235/75R15 4oz
245/75R15 40z
255/75R15 40z
265/75R15 40z
235/70R15 40z
245/70R15 40z
255/70R15 4oz
265/70R15 4oz
285/70R15 40z
315/70R15 6oz
245/65R15 4oz
225/60R15 4oz
325/60R15 6oz
Tire Size:
325/75R20 80z
275/65R20 6oz
275/60R20 6oz
325/60R20 6oz
255/60R20 6oz
275/55R20 4oz
285/55R20 4oz
255/50R20 4oz
285/50R20 4oz
305/50R20 6oz
325/50R20 6oz
355/50R20 6oz
325/45R20 6oz
275/40R20 6oz
315/35R20 6oz
Tire Size:
6.
5R16 4oz
7.50R16 4oz
8.25R16 6oz
1R16 8oz
215/85R16 4oz
225/85R16 4oz
245/85R16 4oz
255/85R16 4oz
265/85R16 6oz
275/85R16 6oz
205/80R16 4oz
325/80R16 6oz
175/75R16 4oz
195/75R16 4oz
225/75R16 4oz
235/75R16 4oz
245/75R16 4oz
265/75R16 6oz
285/75R16 6oz
315/75R16 6oz
215/70R16 4oz
225/70R16 4oz
235/70R16 4oz
245/70R16 4oz
255/70R16 4oz
265/70R16 4oz
275/70R16 4oz
305/70R16 4oz
315/70R16 6oz
355/70R16 6oz
365/70R16 6oz
395/70R16 6oz
195/65R16 4oz
215/65R16 4oz
225/65R16 4oz
245/65R16 4oz
255/65R16 4oz
305/65R16 4oz
345/65R16 6oz
375/65R16 6oz
215/60R16 4oz
225/60R16 4oz
235/60R16 4oz
285/60R16 4oz
255/55R16 4oz
315/55R16 4oz
345/55R16 6oz
355/55R16 6oz
375/55R16 6oz
245/50R16 4oz
Tire Size:
8R16.5 6oz
8.75R16.5 6oz
9.50R16.5 6oz
10R16.5 6oz
12R16.5 6oz
Tire Size:
235/80R17 6oz
235/75R17 6oz
245/75R17 6oz
255/75R17 6oz
245/70R17 6oz
255/70R17 6oz
285/70R17 6oz
305/70R17 6oz
315/70R17 6oz
355/70R17 6oz
255/65R17 6oz
235/65R17 4oz
245/65R17 4oz
255/65R17 4oz
265/65R17 6oz
305/65R17 6oz
375/65R17 8oz
225/60R17 4oz
235/60R17 4oz
255/60R17 6oz
275/60R17 6oz
285/60R17 6oz
225/55R17 4oz
255/55R17 4oz
275/55R17 6oz
345/55R17 6oz
255/50R17 4oz
Tire Size:
325/55R22 6oz
335/55R22 6oz
325/50R22 6oz
305/45R22 6oz
305/40R22 6oz
285/35R22 6oz
Tire Size:
8R17.
5 6oz
8.5R17.5 6oz
9R17.5 6oz
9.5R17.5 8oz
10R17.5 80z
11R17.5 80z
225/90R17.5 8oz
205/80R17.5 8oz
225/80R17.5 8oz
205/75R17.5 6oz
215/75R17.5 6oz
225/75R17.5 6oz
235/75R17.5 6oz
245/75R17.5 6oz
195/70R17.5 6oz
215/70R17.5 6oz
235/70R17.5 6oz
195/60R17.5 6oz
205/60R17.5 6oz
225/60R17.5 6oz
Tire Size:
7.50R18 8oz
255/70R18 6oz
285/60R18 6oz
325/60R18 6oz
375/60R18 8oz
395/60R18 8oz
255/55R18 4oz
275/55R18 4oz
285/55R18 4oz
285/50R18 4oz
375/50R18 6oz
Tire Size:
255/55R19 4oz
255/50R19 4oz
275/45R19 4oz
285/45R19 4oz
Tire Size:
325/45R24 6oz
Tire Size:
8R19.5 8oz
9R19.5 80z
18R19.5 14oz
280/75R19.5 8oz
285/75R19.5 8oz
225/70R19.5 8oz
245/70R19.5 8oz
265/70R19.5 8oz
275/70R19.5 10oz
285/70R19.5 10oz
305/70R19.5 12oz
385/65R19.
5 14oz
445/65R19.5 14oz
Tire Size:
7.50R20 10oz
8.25R20 10oz
9.00R20 12oz
10.00R20 12oz
11R20 14oz
12.00R20 14oz
12.5R20 14oz
14/80R20 14oz
14.00R20 16oz
365/80R20 16oz
395/80R20 16oz
Tire Size:
525/65R20.5 20oz
615/65R20.5 20oz
Tire Size:
10.00R22 12oz
1.00R22 12oz
Tire Size:
9R22.5 10oz
10R22.5 10oz
11R22.5 12oz
12R22.5 14oz
13R22.5 12oz
15R22.5 12oz
16R22.5 14oz
16.5R22.5 14oz
18R22.5 16oz
235/80R22.5 6oz
255/80R22.5 8oz
275/80R22.5 12oz
295/80R22.5 14oz
315/80R22.5 14oz
365/80R22.5 14oz
245/75R22.5 10oz
265/75R22.5 10oz
285/75R22.5 12oz
295/75R22.5 12oz
315/75R22.5 12oz
345/75R22.5 12oz
350/75R22.5 14oz
235/70R22.5 8oz
255/70R22.5 10oz
11/70R22.5 10oz
265/70R22.5 10oz
275/70R22.5 12oz
305/70R22.5 12oz
315/70R22.5 12oz
365/70R22.
5 120z
365/65R22.5 12oz
385/65R22.5 12oz
425/65R22.5 14oz
445/65R22.5 160z
285/60R22.5 10oz
295/60R22.5 10oz
305/60R22.5 10oz
315/60R22.5 10oz
385/55R22.5 12oz
455/55R22.5 16oz
275/50R22.5 10oz
445/50R22.5 16oz
Tire Size:
1.00R24 14oz
12.00R24 14oz
14.00R24 16oz
445/70R24 16oz
495/70R24 16oz
Tire Size:
11R24.5 12oz
12R24.5 14oz
285/75R24.5 12oz
305/75R24.5 12oz
315/75R24.5 12oz
275/80R24.5 12oz
295/80R24.5 12oz
MUD TERRAIN
Tire Size:
35/12.5 R20 14oz
35/13.5 R20 14oz
36/13.5 R20 14oz
37/13.5 R20 14oz
38/13.5 R20 14oz
33/12.5 R20 12oz
37/12.5 R20 14oz
33/12.5 R22 14oz
35/12.5 R22 14oz
37/12.5 R22 14oz
36/13.5 R22 112oz
37/13.5 R22 16oz
38/13.5 R22 16oz
33/12.5 R18 12oz
34/12.5 R18 12oz
35/12.5 R18 12oz
36/12.5 R18 12oz
37/12.5 R18 12oz
42/12.
5 R18 12oz
33/13.5 R18 12oz
36/13.5 R18 12oz
37/13.5 R18 14oz
38/13.5 R18 14oz
40/13.5 R18 14oz
35/14.5 R18 12oz
38/14.5 R18 14oz
40/14.5 R18 14oz
41/14.5 R18 16oz
33/12.5 R17 12oz
35/12.5 R17 12oz
37/12.5 R17 14oz
33/13.5 R17 12oz
36/13.5 R17 14oz
37/13.5 R17 14oz
40/13.5 R17 14oz
35/14.5 R17 12oz
31/12.5 R16 10oz
32/12.5 R16 10oz
33/12.5 R16 10oz
34/12.5 R16 10oz
35/12.5 R16 12oz
36/12.5 R16 12oz
37/12.5 R16 12oz
33/13.5 R16 10oz
36/13.5 R16 12oz
40/13.5 R16 14oz
33/14.5 R16 12oz
35/14.5 R16 12oz
36/14.6 R16 14oz
38/14.5 R16 14oz
40/14.5 R16 16oz
31/12.5 R15 8oz
32/12.5 R15 10oz
33/12.5 R15 10oz
34/12.5 R15 10oz
35/12.5 R15 10oz
36/12.5 R15 12oz
37/12.5 R15 12oz
38/12.5 R15 12oz
31/13.5 R15 8oz
33/13.5 R15 610oz
35/13.5 R15 12oz
37/13.5 R15 12oz
40/13.5 R15 14oz
31/14.5 R15 10oz
33/14.
5 R15 12oz
35/14.5 R15 12oz
36/14.5 R15 14oz
37/14.5 R15 14oz
40/14.5 R15 14oz
Tire Size:
27/8.5R14 4oz
Tire Size:
31/10.50R16.5 6oz
33/12.50R16.5 8oz
35/12.50R16.5 8oz
37/12.50R16.5 10oz
33/14.50R16.5 10oz
35/14.50R16.5 10oz
38/15.50R16.5 12oz
33/16.50R16.5 10oz
36/16.50R16.5 12oz
40/17B16.5 14oz
44/18.50B16.5 14oz
Tire Size:
33/12.50R17 10oz
35/12.50R17 10oz
37/12.50R17 10oz
37/13.50R17 10oz
40/13.50R17 10oz
ALL TERRAIN
Tire Size:
35/12.5 R20 12oz
35/13.5 R20 12oz
36/13.5 R20 12oz
37/13.5 R20 12oz
38/13.5 R20 12oz
33/12.5 R20 10oz
37/12.5 R20 12oz
33/12.5 R22 12oz
35/12.5 R22 12oz
37/12.5 R22 12oz
36/13.5 R22 12oz
37/13.5 R22 14oz
38/13.5 R22 14oz
33/12.5 R18 10oz
34/12.5 R18 10oz
35/12.5 R18 10oz
36/12.5 R18 10oz
37/12.
5 R18 10oz
42/12.5 R18 10oz
33/13.5 R18 10oz
36/13.5 R18 10oz
37/13.5 R18 12oz
38/13.5 R18 12oz
40/13.5 R18 12oz
35/14.5 R18 10oz
38/14.5 R18 12oz
40/14.5 R18 12oz
41/14.5 R18 14oz
33/12.5 R17 10oz
35/12.5 R17 10oz
37/12.5 R17 12oz
33/13.5 R17 10oz
36/13.5 R17 12oz
37/13.5 R17 12oz
40/13.5 R17 12oz
35/14.5 R17 10oz
31/12.5 R16 8oz
32/12.5 R16 8oz
33/12.5 R16 8oz
34/12.5 R16 8oz
35/12.5 R16 10oz
36/12.5 R16 10oz
37/12.5 R16 10oz
33/13.5 R16 8oz
36/13.5 R16 10oz
40/13.5 R16 12oz
33/14.5 R16 10oz
35/14.5 R16 10oz
36/14.6 R16 12oz
38/14.5 R16 12oz
40/14.5 R16 14oz
31/12.5 R15 8oz
32/12.5 R15 8oz
33/12.5 R15 8oz
34/12.5 R15 8oz
35/12.5 R15 8oz
36/12.5 R15 10oz
37/12.5 R15 10oz
38/12.5 R15 10oz
31/13.5 R15 8oz
33/13.5 R15 8oz
35/13.5 R15 10oz
37/13.5 R15 10oz
40/13.5 R15 12oz
31/14.5 R15 8oz
33/14.
5 R15 10oz
35/14.5 R15 10oz
36/14.5 R15 12oz
37/14.5 R15 12oz
40/14.5 R15 12oz
Tire Size:
29/9.50R15 8oz
30/9R15 8oz
33/9.50R15 8oz
31/10.50R15 8oz
33/10.50R15 8oz
31/11.50R15 8oz
32/11.50R15 8oz
31/12.50R15 8oz
32/12.50R15 8oz
33/12.50R15 8oz
35/12.50R15 8oz
36/12.50R15 10oz
37/12.50R15 10oz
35/13.50R15 10oz
31/14.50R15 8oz
33/14.50R15 10oz
36/14.50R15 10oz
38/15.50R15 12oz
33/16.50R15 10oz
36/16.50R15 12oz
40/17R15 12oz
44/18.50R15 12oz
Tire Size:
35/12.50R20 12oz
ALL SEASON
Tire Size:
35/12.5 R20 10oz
35/13.5 R20 10oz
36/13.5 R20 10oz
37/13.5 R20 10oz
38/13.5 R20 10oz
33/12.5 R20 8oz
37/12.5 R20 10oz
33/12.5 R22 10oz
35/12.5 R22 10oz
37/12.5 R22 10oz
36/13.5 R22 10oz
37/13.5 R22 12oz
38/13.5 R22 12oz
33/12.5 R18 8oz
34/12.5 R18 8oz
35/12.
5 R18 8oz
36/12.5 R18 8oz
37/12.5 R18 8oz
42/12.5 R18 10oz
33/13.5 R18 8oz
36/13.5 R18 8oz
37/13.5 R18 10oz
38/13.5 R18 10oz
40/13.5 R18 10oz
35/14.5 R18 8oz
38/14.5 R18 10oz
40/14.5 R18 12oz
41/14.5 R18 12oz
33/12.5 R17 8oz
35/12.5 R17 8oz
37/12.5 R17 10oz
33/13.5 R17 8oz
36/13.5 R17 10oz
37/13.5 R17 10oz
40/13.5 R17 10oz
35/14.5 R17 8oz
31/12.5 R16 6oz
32/12.5 R16 6oz
33/12.5 R16 6oz
34/12.5 R16 6oz
35/12.5 R16 8oz
36/12.5 R16 8oz
37/12.5 R16 8oz
33/13.5 R16 6oz
36/13.5 R16 8oz
40/13.5 R16 10oz
33/14.5 R16 8oz
35/14.5 R16 8oz
36/14.6 R16 10oz
38/14.5 R16 10oz
40/14.5 R16 12oz
31/12.5 R15 6oz
32/12.5 R15 6oz
33/12.5 R15 6oz
34/12.5 R15 6oz
35/12.5 R15 6oz
36/12.5 R15 8oz
37/12.5 R15 8oz
38/12.5 R15 8oz
31/13.5 R15 6oz
33/13.5 R15 6oz
35/13.5 R15 8oz
37/13.5 R15 8oz
40/13.5 R15 10oz
31/14.
5 R15 6oz
33/14.5 R15 8oz
35/14.5 R15 8oz
36/14.5 R15 10oz
37/14.5 R15 10oz
40/14.5 R15 10oz
Tire Size:
32/9.50R16 6oz
35/10.50R16 6oz
31/12.50R16 6oz
32/12.50R16 6oz
33/12.50R16 6oz
35/12.50R16 6oz
36/12.50R16 8oz
37/12.50R16 8oz
33/14.50R16 8oz
36/14.50R16 10oz
38/15.50R16 10oz
Tire Size:
35/12.50R18 6oz
37/12.50R18 8oz
NOTE – For aggressive Mud Terrain Tires add an additional 2oz per tire application.
A bar chart is made up of a string field on the x-axis and a number field (or rate/ratio field) on the y-axis. Each bar is a length corresponding to a category value. Bar charts can also use subgroup to create a grouped or stacked bar chart so that you can compare categories within them as well.
Column charts can answer questions about data such as: How are numbers distributed or summarized across categories? How is the data ranked?
An insurance company is reviewing the types of policies it offers to compare its current offerings with the results of a recently completed insurance market survey.
The first step of the review is to determine the overall value of the policies for each class. You can use a bar chart to show the sum of total insurance values (TIV) for each policy class.
The bar chart shown above contains the sum of the TIV values for each category of insurance policies: auto, disability, property, and life. If the chart is sorted in ascending order, it is very easy to determine its maximum and minimum values.
The insurance company is particularly interested in expanding its business in five specific cities. The Subgroup field can be used to compare the total insured value for each policy class across cities.
The bar chart displays the distribution of subgroups for each of the categories. The Policy_Class values (Property, Life, Disability, and Auto insurance policy classes) are divided into subgroups, which are displayed as different colored bars for each city.
Follow these steps to create a bar chart:
Drag another match string field from the second dataset onto your bar chart to create a combo chart.
You can also build charts using the Chart menu above the data panel or the Visualization Type button on an existing card. In the Charts menu, only charts that are applicable to the existing data selection will be available. The Visualization Type menu will display only suitable visualization options (maps, charts, or tables).
The Layer Options button opens the Layer Options panel. You can use the Layer Options panel to view the legend, change chart options, and update the chart style.
The Legend tab is used to view the symbols on the chart. The popup legend button will display the legend as a separate card on your page. You can use the legend to make a selection in the chart if a subgroup is applied.
To change the color associated with a value, click on the symbol and select the desired color from the palette, or enter its six-digit code.
The Symbology tab is used to change the Symbol Type to Unique Symbol and turn labels on or off. The Symbology tab is not available if a subgroup field is specified for the chart.
Labels display the numeric values associated with the chart. The following settings are available for labels:
The Appearance tab is used to change the color of the symbol (single color only) and change the color of the chart outline.
Column values can be designated as the number of items in each of the categories on the x-axis, or as a field of numbers or proportion/ratio. If a field is used, the column values can be calculated as the sum, minimum, maximum, or median of the field values for each of the categories.
Median and percentile are not available for some remote feature layers. If the deleted feature layer does not support median or percentile, you can copy the layer to a workbook.
An optional Subgroup field can be selected on the x-axis. The Subgroup field must be a string field and can be used to split categories on the x-axis into subcategories.
Design related maps using the same field used for the subgroup in the bar chart. When working with a chart or map, you will be able to see both categorical and spatial characteristics at the same time.
Use the Chart Statistics button to display the mean, median, upper quartile, lower quartile, or custom value.
The Sort button is used to sort categorical data by a numeric variable either in ascending or descending order, alphabetically or manually. If you selected Sort Manually, you can click and drag the columns to a new position on the chart. Click Apply to apply the changes, or Cancel to revert to the previous order.
Charts on the published page will by default use the same sort style that was used when the page was published. Manual sorting will be called Predefined, and manual sorting will not be available to readers. Charts that were sorted in ascending, descending, or alphabetical order when published will not have a predefined sort option.
Use the Visualization Type button to switch between a bar chart and other types of visualizations such as a summary table, treemap, or donut chart.
Use the Flip Card button to view the back of the card.
The Card Information tab provides information about the data on the card, the Image Export tab allows users to export an image of the card, and the Data Export tab allows users to export card data.
When you create a bar chart, a result dataset will be added to the data pane with the string and number fields used to create the chart. The resulting dataset can be used when searching for answers in non-spatial analysis using the Action button.
Feedback on this section?
Excel for Microsoft 365 Word for Microsoft 365 PowerPoint for Microsoft 365 Excel for Microsoft 365 for Mac Word for Microsoft 365 for Mac PowerPoint for Microsoft 365 for Mac Excel 2021 Word 2021 PowerPoint 2021 Excel 2021 for Mac Word 2021 for Mac PowerPoint 2021 for Mac Excel 2019 Word 2019 PowerPoint 2019 Excel 2019for Mac Word 2019 for Mac PowerPoint 2019 for Mac Excel 2016 Word 2016 PowerPoint 2016 Excel 2016 for Mac Word 2016 for Mac PowerPoint 2016 for Mac Excel 2013 Word 2013 PowerPoint 2013 Excel 2010 Word 2010 PowerPoint 2010 More.
..Less
You can combine multiple charts to emphasize different types of data in the Plot View. For example, you can combine a chart containing price data with a bar chart that displays sales volumes.
Note: Only flat charts such as 2D plots, 2D bar charts, and scatter or bubble charts can be used to create a combo chart.
Note: You must use an existing chart to complete these steps. To learn how to create a chart, see Create a chart from start to finish.
Do one of the following:
To change the chart type, click the chart area or plot area. Chart tools will appear.
Tip: You can also right-click the chart area or chart area, click Change chart type and go to step 3.
To change the chart type for a data series, click it.
Note: You can only change the chart type for one data series at a time. To change the chart type for multiple series, repeat these steps for each of them.
The Chart Tools panel opens with additional tabs Constructor , Layout and Format .
On the Design tab , in the Type group, click the button Change chart type .
In the dialog box Change chart type select type.
The first field shows a list of categories, while the second shows the available chart types for each category. For more information about supported chart types, see Chart Types.
Note: You must use an existing chart to complete these steps. To learn how to create a chart, see Create a chart from start to finish.
This step only applies to Word for Mac: on the View menu, select Print Markup .
Select a data series in the chart. For example, click one of the graph lines.
The codes do not go beyond 150mm in width. With these tires, the first number of the tire size is not the actual width, it is just a number. The M-code is what tells you the actual width.
Two rim locks opposite each other don't require any more Dyna Beads other than stated above, as they have a tendency to cancel each other out.
50 R20
00 R20
50 R20
00 R20
5
5
5
5
5
5
5
5
5
5
50 R18
5
5
5
5
5
5
