The most commonly asked question amongst truck owners and the 4WD community is, what are the largest/biggest tires you can fit on your truck. Tire upgrades are usually the first thing most truck owners do and if you own a Ram 1500 with the radius arm type suspension (2013-Present) then you’d probably want to know the answer to this question before you run out and drop a load on tires that won’t fit.
What are the biggest tires you can fit on a sock Ram 1500? The biggest tire you can fit without any additional modification is a 35”. If you are prepared to do a bit of trimming you can fit 37″. 39-inch and bigger require fender rolling, body mount trimming, and wheel-well cutting.
The suspension is not a major limiting factor when it comes to fitting bigger tires. With that being said, the recommendations you will get here are not to check what the maximum size wheel you can fit with limited travel and mobility, but rather what the most practical size is to fit for on-road, off-road, and over-landing adventure applications.
At the end of the day, you still want all the practicality of your truck, and your tire size upgrade should enhance your truck’s abilities and capability, not detract from it. You still want full articulation and droop with maximum suspension travel.
So let’s get into it and see what exactly you need to be aware of when fitting bigger tires on your Ram 1500 with a stock suspension.
Table of Contents
Keep in mind, once you fit a larger tire on your stock suspension and later decide to upgrade the suspension, you won’t need to change anything in terms of bump stops, levels, wheel spacers, or make any wheel-well modifications.
This is a hassle-free upgrade that allows for a wider and longer footprint, enhancing the truck’s off-road capability while still taking advantage of its suspension travel.
So, the biggest tire recommended for a Ram 1500 with factory stock suspension is 35” x12.
50 on
factory stock rims.
This allows you full wheel lock without any trimming, rub, grinding away body panels, or adjustment of suspension components. This is a straight bolt-on-and-go tire option with only a speedometer adjustment needed to calibrate the reading.
The simple answer is, yes. As mentioned above, the 35” x12.5 is the biggest wheel you can fit without hampering off-road performance or any body-panel trimming required to make them fit on the stock wheels.
So with a 33” tire, it will definitely fit provided it has the correct offset to clear the brake calipers. The more positive the offset, the closer the inside of the wheel is aligned with the centerline of the tire.
Below are some measurements to help you understand the differences between a 33” and 35”
| Measurement | 33-Inch | 35-inch | Difference |
| Diameter | 285/75/17 | 305/75/17 | +7% |
| Width | 11. 2” | 12” | +7.1” |
| Sidewall | 7.9” | 9” | 13.9” |
| Circumference | 102.7” | 109.9” | +7% |
| Revs/Mile | 617 | 576 | -41 |
I find this tool very useful when determining tire size differences and what effect it has on your truck: https://tiresize.com/comparison/
Next, let’s investigate the biggest tires you can possibly squeeze on a Ram 1500 with a stock suspension.
So this is probably one of the most commonly asked questions on all discussion forums and FB groups. Every guy wants to know what the biggest tires are he can get away with on a factory stock suspension and stock wheels.
Fitting a 37″ is the biggest size on stock rims, If you are prepared to live with the following:
The biggest tire you can fit on a Ram 1500 with stock rims are 37”x12.
5
As mentioned, you will need to do a little bit of trimming on the inside fender liner. This applies to 2500, 3500, and Power Wagon stock wheels. The Power Wagon wheel has a slight advantage since it has a wider offset wheel in stock form, meaning there is a bit more backspace clearance.
Fitting aftermarket wheels when upgrading your tires is always a smarter move. It allows for better backspacing while not forfeiting too much in terms of offset. Provided you don’t go to a very negative offset where the wheels protrude extensively.
A wider stance wheel with a negative offset would probably look insane, however, you’ll need to start doing a lot of fender flair trimming which are more permanent modifications.
Besides, there could be some legality issues as well. This could also pose a problem if you decide to sell the vehicle at a later stage.
When selecting an aftermarket rim, you want to pay particular attention to the offset of the rim. The offset can be described as the distance between the inside face of the rim to the centerline of the tire. The measurement where the rim meets the hub, to the center of the tire is the offset measurement.
A more positive offset (larger backspacing) moves the mounting surface closer to the outside of the wheel which will tuck the wheel further under the truck. A more negative offset (smaller backspacing) moves the mounting surface closer to the inside of the wheel which will push the wheel further out from the truck.
When shopping around for your aftermarket rim, try and stay between an offset measurement of +18mm to +27mm.
This will allow for full articulation/wheel travel. Fitting 0 to (-) negative offset wheels might look aesthetically pleasing, however, it doesn’t translate well when venturing off-road.
If you decide to go -18 offset rims, you’ll be required to cut a lot of sheet metal and roil the arches to make them fit nicely without rubbing. These are permanent modifications that are hard to reverse and are not highly recommended.
Once you install a leveling kit on the Ram you are essentially increasing the wheel well area which will allow for a bigger tire. Now it also depends on how much of a lift you are planning, but by way of example, if you go with a 2” lift you could get away with a 35×12.50×20. There will be no rubbing or touching against the UCA or fenders.
The biggest tire you could fit on a 2019 Ram 1500 with a leveling kit is 35×12.5×20. Alternatively a 39” with a 12.5×17.
Obviously, this is purely for aesthetics and will drastically reduce your MPG and off-road performance. This is not a recommended upgrade if you ever plan to venture off-road.
Ram 1500 2” Front leveling kit
Full 2” Lift Kit
Adjustable Shocks
Rough Country 2″ Leveling Lift Kit For Dodge Ram 1500, Suspension Parts | 2012-2018 Dodge Ram 1500,
Warn Fender Flare Set For 13-18 Ram 1500, Satin Black, Set Of 4 | 2013-2018 RAM 1500, W102028
Teraflex Tow Haul Adjustable Leveling System, Suspension Parts | 2009-Current Dodge Ram 1500,
Going bigger tires might look awesome, however, you want to limit how big you go, especially if you still want to maintain full functionality of your truck.
Bigger isn’t always better since the bigger you go, the more modifications you’ll need to make as well as having to calibrate/adjust your speedometer reading. Don’t forget, lower MPG. So, for the best all-round upgrade, we recommend not going bigger than 37”
Are you on the hunt for new tires? Maybe you just want to see what will fit your model. Here is a quick guide to what tires sizes RAM uses. Plus, some information on how to go a bit larger.
Before we begin, we have a bit of a disclaimer. With RAM or Dodge building trucks for decades, this guide will attempt to address many of the models out there. However, we won’t be able to hit every single one and we will only be addressing 1990 and newer trucks. Lastly, this is a “guide” and it is always recommended to double-check with a tire store and/or reseller.
OEM Tire Sizes – RAMLug Nut PatternsOne thing that is pretty helpful to know when looking for tires is the lug nut pattern can tell you whether or not your truck and/or rim is setup for a 2wd or 4wd.
The rule of thumb is that 6 lug patterns (wheels with 6 lug nuts) are for 4wd and 5 lug patterns are more common for 2wd.
Lift kits are great and many trucks really improve their appearance with them. However, there is an additional expense of adding the kit. If you want to raise the truck without adding the lift, putting on larger tires is the quick option.
Most trucks come with the ability to add a larger tire with the wheel well openings. By larger, we mean an extra inch or so. You simply can’t throw a large tire in there without encountering rubbing when turning or driving – that requires a lift.
If you want to go larger keep the following in mind:
The first rule of thumb is the 3% Height and Width or “plus 1” rule. This generally means that you can increase your tire height and width by 3% without having to do a lift or leveling kit.
Now, the 3% is great except that not every tire manufacture offers a tire that is exactly that much larger. This is why the plus 1 name came into existence.
The plus 1 states: 1” Lift = 1” Height. This is pretty self-explanatory. You can go 1” inch taller on the tire for each inch of lift. However, this doesn’t apply to width. If you increase width, you may need different backspacing for your wheels.
Note: The recommendations made below are based on factory wheels. If you have an upgraded rim with different backspacing, you will be able to increase to a wider tire.
Max tire sizes are:
1.5-2″ Leveling Kit (or less)
Note when installing a leveling kit you might be able to fit wider tires than we have listed. These tires can be trimed to fit.
Max tire sizes are:
3″ Lift Kit
If you add a 3″ lift kit, your options get better. Yet, the wideness still could be a concern requiring trimming.
Max tire sizes are:
Third Generation – 2002-2008
No Lift Kit
Max tire sizes are:
1.5-2″ Leveling Kit (or less)
Max tire sizes are:
3″ Lift Kit
Max tire sizes are:
Lastly, remember that tire makers build all sorts of tires. This means you may not be able to find the exact tire for BOTH height and width when shopping for new tires.
These days it is a lot easier to find tires. Your first step should be online research at different online outlets. Then, check out your local brick and mortar tire shop. In a lot of cases, these brick and mortar stores will give you some good information and/or have a coupon which offsets the online savings.
