Offroaders.com Guide to P-Metric Tire Sizes, Conversion Chart and Tire Terminology – P-Metric to Inches
The following chart lists common p-metric tires sizes and the converted tread width and the actual tire height in inches. The values shown are calculated measurements based on the p-metric formula, which is explained below on this page. This chart is for an estimated conversion and the actual advertised tire height and tread width will vary from manufacturer to manufacturer. If you need to know the actual p-metric tire size and the equivalent measurements in inches for a specific tire, check with the manufacturer’s actual dimensions per individual tire brand before purchasing.
| Rim Size | P-Metric Size | Tread Width | Actual Tire Height |
| 15 Inch | 205/70R15 | 8. | 26.3 inches |
| 215/75R15 | 8.46 inches | 27.7 inches | |
| 235/75R15 | 9.25 inches | 28.9 inches | |
| 265/70R15 | 10.4 inches | 29.6 inches | |
| 16 Inch | 225/75R16 | 8.8 inches | 29.3 inches |
| 235/85R16 | 9.25 inches | 31.7 inches | |
| 245/75R16 | 9. 6 inches | 30.5 inches | |
| 265/70R16 | 10.4 inches | 30.6 inches | |
| 265/75R16 | 10.4 inches | 31.6 inches | |
| 285/75R16 | 11.2 inches | 32.8 inches | |
| 305/70R16 | 12.0 inches | 32.8 inches | |
| 315/75R16 | 12.4 inches | 34.6 inches | |
| 345/75R16 | 13.6 inches | 36. 4 inches | |
| 17 Inch | 235/65R17 | 9.25 inches | 29.0 inches |
| 245/70R17 | 9.6 inches | 30.5 inches | |
| 255/75R17 | 10.0 inches | 32.0 inches | |
| 255/80R17 | 10.0 inches | 33.0 inches | |
| 265/70R17 | 10.4 inches | 31.6 inches | |
| 275/70R17 | 10. 8 inches | 32.2 inches | |
| 285/70R17 | 11.2 inches | 32.7 inches | |
| 285/75R17 | 11.2 inches | 33.8 inches | |
| 305/65R17 | 12.0 inches | 32.6 inches | |
| 315/70R17 | 12.4 inches | 34.4 inches | |
| 18 Inch | 265/60R18 | 10.4 inches | 30.5 inches |
| 275/65R18 | 10. 8 inches | 32.1 inches | |
| 275/70R18 | 10.8 inches | 33.2 inches | |
| 285/75R18 | 11.2 inches | 34.8 inches | |
| 295/65R18 | 12.6 inches | 33.1 inches | |
| 305/60R18 | 12.0 inches | 32.4 inches | |
| 305/70R18 | 12.0 inches | 34.8 inches | |
| 20 Inch | 275/60R20 | 10. 8 inches | 33.0 inches |
| 275/65R20 | 10.8 inches | 34.0 inches | |
| 285/60R20 | 11.2 inches | 33.4 inches | |
| 285/65R20 | 11.2 inches | 34.5 inches | |
| 295/55R20 | 12.6 inches | 32.8 inches | |
| 295/60R20 | 11.6 inches | 33.9 inches | |
| 305/55R20 | 12.0 inches | 33. 2 inches | |
| 325/60R20 | 12.8 inches | 35.3 inches |
Other 4×4 Related Calculators
▪ Convert P-Metric Tire to Inches
▪ Ring Pinion and Gear Ratio
▪ Speedometer Converter
▪ Find new Gear Ratio with new Tire Size
▪ Find Overall Crawl Ratio
▪ Find MPH
▪ Find RPM
▪ Convert P-Metric Tire to Inches
All tires are required to have certain information molded into the side of the tire in a location known as the sidewall. Some of the information is self explanatory while other information requires a little knowledge to decipher. The following will help you understand what this information means.
Tire Type – This Defines the intended proper use of the tire. P indicates this is a passenger car tire while LT indicates the tire would be for a light truck with a heavier load rating.
Tire Width – This is the width of the tire measured in millimeters from sidewall to sidewall. An example might be 215 representing 215 millimeters.
Aspect Ratio – This is the ratio of the height of the tire’s cross-section to its width. An example of this might be 65, which means that the height is equal to 65% of the tire’s width. To calculate the aspect ratio, multiple the first number (e.g. 215) by the second number with a decimal before the number (e.g. .65). Using the example numbers the tires aspect ratio would calculate as 215x.65=139.75 where 139.75 is the tires height in millimeters. This is the height of the rubber from rim to tread on one side of the tire.
To convert the aspect ratio to a full tire height in inches, do this:
Convert the above calculated tire height (aspect ratio) in millimeters to inches by multiplying the millimeters by .03937 (139.
75 x .03937 = 5.5 inches). Then take the inches and multiply by two and add the rim size. Example: 5.5 x 2 + 15 (rim size in inches) = a 26 inch tall tire.
Construction – This indicates how the how the tire was put together and will say much about the tires handling characteristics. R indicates the tire is a radial type tire. For more information about what a radial is, click here. B indicates the tire is a bias ply type tire. For more information about bias ply type tires, click here.
Wheel Diameter – This is the width of the opening in the tire where it would be mounted to a wheel. This is measured from one bead across the opening to the other side of the same bead. This measurement is in inches and an example would be 15 and indicates that this tire is for a 15 inch rim, or wheel.
Load Index – This is a number corresponds to the maximum load in pounds that a tire can support when properly inflated.
You will also find the maximum load in pounds and in kilograms molded elsewhere on the tire sidewall.
Speed Rating – This is a number that corresponds to the maximum service speed for a tire. See Chart for ratings. Note: Speed ratings are specific for passenger car tires and not light truck tires. Light truck tires (LT) are not speed rated.
Rating | Maximum Speed |
| Q | 99 mph |
| S | 112 mph |
| T | 118 mph |
| U | 124 mph |
| H | 130 mph |
| V | 149 mph |
| W | 168 mph |
| Y | 186 mph |
| Z | Above 149 mph |
Reference
Knowing your Jeep's tire size can be essential information when it comes time to replace that rubber, or even if you ever decide to change wheels.
And while a stock tire size is imprinted right inside the driver side B pillar, you may not know what if have if you are not the original owner.
So here is some helpful information to assist you in determining what you currently have on the vehicle.
First, the sidewall of your tire contains all the information needed to understand everything about that specific tire. All tires are required to have this information, regardless of the manufacturer brand name.
Now, this information could read in a few different ways. For example, it could simply say 35x12.5 R17, or it may show as P265 75 R15. If it is the first listing, then here is the breakdown. That first number is your tire size at 35", and then the second number tells you the tire width at 12.5". That third reading is the tire type as radial and diameter as 17".
The second listing is a metric set up, and is what is more common on factory-type sized tires. From left to right, the P indicates a passenger tire while 265 indicates the tires width in millimeters.
That 75 is the tire's aspect ratio and simply means the tire's height is equal to 75 percent of its width. Finally, like the first set of numbers, that R15 means it is a radial tire and has a 15" diameter.
For those who have the metric reading on their tires, you can simply plug that into the conversion calculator to determine the tire size, or find that corresponding reading on one of the below conversion charts.
Enter the metric size (i.e. 285/75 R17)
| Metric | Standard |
|---|---|
| 215/75/15 | 27.7"x 8.5" |
| 225/70/15 | 27.4"x 8.9" |
| 225/75/15 | 28.3"x 8.9" |
| 235/75/15 | 29.0"x 9.3" |
| 245/75/15 | 29.5"x 9.6" |
| 255/75/15 | 30.0"x 10.0" |
| 265/75/15 | 30. 6"x 10.4" |
| Metric | Standard |
|---|---|
| 205/85/16 | 29.7"x 8.1" |
| 215/75/16 | 28.7"x 8.5" |
| 225/70/16 | 28.4"x 8.9" |
| 225/75/16 | 29.2"x 8.9" |
| 235/70/16 | 29.0"x 9.3" |
| 235/85/16 | 31.7"x 9.3" |
| 245/70/16 | 29.5"x 9.6" |
| 245/75/16 | 30.5"x 9.6" |
| 255/70/16 | 30.0"x 10.0" |
| 265/70/16 | 30.6"x 10.4" |
| 265/75/16 | 31.6"x 10.4" |
| 275/70/16 | 31.2"x 10.8" |
| 285/75/16 | 32.8"x 11.2" |
| 295/75/16 | 33.4"x 11.6" |
| 305/70/16 | 33.0"x 12.2" |
| 315/75/16 | 34. 8"x 12.4" |
| 375/55/16 | 32.8"x 15.5" |
| 395/70/16 | 37.9"x 16.0" |
| Metric | Standard |
|---|---|
| 245/70/17 | 30.6"x 9.8 |
| 265/70/17 | 31.6"x 10.7 |
| 285/70/17 | 33.0"x 11.5 |
| 315/70/17 | 34.4"x 12.4 |
| Metric | Standard |
|---|---|
| 275/65/18 | 32.1"x 11.0 |
| 375/50/18 | 33.0"x 15.4 |
| 325/60/18 | 33.2"x 13.3 |
| 325/65/18 | 34.8"x 13.5 |
| 305/70/18 | 35.0"x 12.2 |
| 375/60/18 | 35. 7"x 15.5 |
| 395/65/18 | 37.8"x 15.7 |
| Metric | Standard |
|---|---|
| 325/50/20 | 33.0"x 13.2" |
Metric measurement example: 225/70R15
225 = Section width in millimeters
70 = Aspect ratio (ratio of section height to section width)
R15 = Rim diameter
R = Radial Construction, B = Bias Construction, D = Bias Belted Construction
Calculations for Measurements
Tire Width: Section width divided by 25.4 (Ex: 225 / 25.4 = 8.86")
Section Height: Tire width times aspect ratio (Ex: 8.86" x 70% = 6.20")
Overall Diameter: Section height times 2 plus rim diameter (Ex: (6.20" x 2) + 15 = 27.40")
See all tires here
When Is It Time To Change My Jeep's Tires?
Choosing The Best Jeep Tires
How Do You Rotate Jeep Tires?
Tags:
Tactik Cup Holder Phone Mount
How To Put Bigger Tires On Your Jeep
If you have your eye on some larger tires for your vehicle, here is what you need to know.
READ MORE
Quadratec QRC Side Armor with Step for Jeep Wrangler JL & Gladiator JT
Best Jeep Gifts For 2022
Part One of Two — Popular categories and products for any enthusiast on your holiday gift list.
READ MORE
Are Jeeps Good In The Snow?
Rugged and capable in most situations, do these skills translate to snow driving for a Jeep as well?
READ MORE
Nine Things You Need In Your Jeep This Winter
A good winter emergency kit is always a good idea to pack in the vehicle. Because you never know when something may happen.
READ MORE
Bestop Supertop Ultra, Yukon Axle Upgrade, the SEMA Show & Moab, UT to Give the Jeep Away!
CAT Soft Vinyl Tri-Fold Tonneau Cover & Tie-Downs for Jeep Gladiator JT
Installing the ARB BASE Rack and Mounting Kit for Jeep Wrangler JL
American and European tires are distinguished by their markings.
European tires have a metric marking system. Therefore, when replacing tires, the problem of translating tire parameters may arise. In most cases, this is the conversion of inches to centimeters. Enter the size in inches and click calculate. You will see the tire size in meters (dimensions will be rounded to European parameters).
|
Comparison: inch and meter sizes When you enter the old inch parameters and new European ones, you can see how the external parameters of the tire and ground clearance will change, as well as differences in the speedometer readings. |
|
| ||||||||||||||||||||||||||||||
Thanks to the Tire Calculator, you can do the reverse calculation - convert "cm" and "mm" to inches.
To do this, enter the size, diameter, width and height of the tire profile and click the "calculate" button. The calculator will convert the values to inches.
| Attention! This R-metric calculator is used to convert European tire size to US tire size. But you can also use it to convert a tire from "inch" style to R-metric. Some dimensions may not be translated correctly (for example, the metric tire dimensions are 33x12.50x15 when converted to R-metric 318/72 R15, but if you translate the dimensions back, you will see 33x12.52x15). This may be due to minor rounding errors. |
Go to the content of
Search for:
Home »Wheels , 2018
The labeling of tires manufactured in America is very different from the European designations.
Therefore, drivers constantly have to convert inches to millimeters or centimeters. Only by making such calculations, you can choose the right wheel for your car.
Contents
The Russian SUV is produced with wheels whose diameter is slightly smaller than that of a conventional SUV. The standard size of foreign cars is 29 inches or 235/75R15.
Domestic SUV (Niva) is factory-equipped with 175/80R15 wheels. On such tires, the car quickly burrows into the mud, hardly moves along our impassability.
To remedy this situation, it is necessary to install 29 inch tires. It will increase the clearance by 25 mm. If you install tires 31 inches, the ground clearance will increase by 50 mm. To install such wheels, you only need to change the wheel arches. It will be necessary to increase their dimensions.
Most Jeeps use tires marked 31x10.
5R15.
31 here refers to the inch diameter of the wheel. One inch, as you know, corresponds to two and a half centimeters, and to be completely accurate, then 2.54 cm. In other words, after the transfer, D will become equal to 78.7 cm.
This marking is quite in demand, because it is convenient, as it shows the size of the wheel with the disk parameters already taken into account.
The wheel diameter 31x10.5R15 is almost equal in dimensions to the tire with the designation 31x10.5R16. The only difference will be a reduction in tire profile by 2.5 cm.
10.5 - tire width in inches. But this value is not entirely accurate, because when converted from inches to traditional centimeters, it will turn out to be 26.5 cm.
However, when measuring this value with a regular ruler, the value will fluctuate within 23 cm. it will be possible to talk about a width of 26.5 cm.
You should always remember this nuance if you decide to install the maximum tire size in the arch of an SUV.
This measurement system is much more difficult to use. Take rubber marked 265-75-15.
265 mm - tire width. Just like in the inch system, its actual width will be approximately 230-235 mm.
75 - profile height in millimeters. To get the true value, you need to take 75% of 265 mm. It will be 198.75 mm. This number is then multiplied by two. This is because the total wheel diameter is D of the rim plus twice the profile height.
In our case, it is 15 inches. As a result, after the calculations, we get a D disk of 381 mm. Total wheel D: 397.5 + 381 = 778 mm or 77.8 centimeters.
R15 - radial rubber. Disc diameter is in inches. Always a surprise. Why is the inch designation left in the metric system.
If you look closely at these two systems, you will notice a slight difference, about 1.1 centimeters. It does not affect the design and installation of the wheels in any way.
Today, a large number of various calculators are offered on the Internet for the correct calculation of tire size.
All of them work completely free of charge and make it much easier to find the right tire size.
You can get acquainted with the rating of summer tires 2019 on our website
We have compiled a table of the most common sizes, perhaps it will help you quickly find the right wheel size.
| Key | Дюймы |
| 235/65R16 | 28,0 |
| 235/75R15 | 28,9 |
| 225/75R16 | 29,3 |
| 245/70R16 | 29.5 |
| 285/60r16 | 29.5 |
| 225/85R15 | 30.1 |
| 245/75R16 | 9000.5|
| 265/70r16 | 30.6 |
| 305/60R17 | 31.4 | 265/70R17 | 31.6 | 265/75R16 | 9000 31.6 9000 9000 9000 31. /85R16 31.  |
