Rim width and tire width are two closely related sizes. Flexible tire sidewalls alow a single tire size to be mounted on a rim of various widths.
Actually, there is an approved rim width range for every tire size, but on the other side, there is a tire width range for every rim size, specifically, rim width.
Note: There are three charts on this page. First chart shows tire widths adequate for a certain rim width and tire aspect ratios. The other two charts are doing the same but in a separate table for each rim width; inside the table data is ordered by tire width or tire aspect ratio.
When replacing a rim or a tire with a wider one you could ask a question in two different ways:
The answer would be: "Rim widths corresponding to the tire size 195/65 R15 are: 5.5, 6.0, 6.5 and 7.0 inches". The information related to other tire sizes can be found in Wheel/Rim Size Calculator or Rim Width Range and Measuring rim for Tire Size chart.
If you want to mount a wider or a narrower tire on the existing rim you could ask the question:
For example, appropriate tire widths for the 6" rim are from 175mm to 225mm. That's answer you can find in the charts below this text.
When replacing OE(original equipment) tire with a wider one, aftermarket tire, the width of rim should be taken into consideration because each rim width corresponds to only a few tire widths.
The charts presented below could help you to make the rational decision about the tire width you need for the given wheel/rim width.
But, please consider that the resulting tire list lacks certain tire sizes, so it should not be treated as complete. When we say tire size in this context(relation between tire width and rim width), we mean only on tire width(i.e., section width) and tire aspect ratio/series, there is no rim diameter. Tires presented in the list should not be all considered suitable for your car, because only a few of them or maybe, only one would satisfy a requirement that their overall diameter should be almost the same as your OE (original equipment) tire diameter.
The data presented in the charts is only for the passenger car metric tires.
NOTICE: These charts do not represent complete or ultimate solution for this particular purpose, they are only a reference.
So, when you find tire sizes, i.e., tire width and series combinations that fit your wheels/rims, use our Tire Size Calculator – Tire Dimensions to compare them with your OE Tire size to ensure that the selected tires circumferences or diameters do not deviate too much from the OE tire circumference or diameter. This is extremely important for many reasons.
The charts, as an addition to our tire4rim calculator, should be used along with our rim4tire calculator, which complement each other. If you choose a tire size in these charts or in the Tire size for rim size calculator, do one more check in the Wheel/Rim size calculator(or in the chart: Rim width range and Measuring rim width for Tire Size) for the selected tire size, to double check if the selected tire size has your rim in
the acceptable rim width range.
Find more relevant information below these charts.
Can I mount a smaller tire width than the one presented in the chart as the smallest, for the specific rim width?
Notes: A Tire with higher profile(series) for the same tire width or the same profile for a wider tire width, has a higher tire sidewall, that means more comfortable ride. Wider tires create more traction on the road, resulting in reducing fuel economy.
Disclaimer:
Please note that these charts should be used only as a reference and they should be verified with tire/wheel manufacturers. They are for informative purposes only. The tyresizecalculator.com is not responsible for any errors that may arise with their usage.
In the charts, every tire width and aspect ratio combination, listed below the certain rim width, could be mounted on the rim width, but the question is: which tire width is the best fit to the rim width?
The tire Measuring Rim Width, which stems from the tire size could help.
You already have the tire width, the aspect ratio, the rim diameter you want to use, that is, you have the full tire size. if your rim width is closer to the measuring rim of selected tire, it's more likely that the chosen tire would fit your rim.
Every tire size has its own Measuring Rim (check the Measuring Rim Width for a tire size by clicking the previous link). In other words, the nominal tire size(imprinted on a tire sidewall) becomes the real tire size when fitted on the appropriate Measuring Rim.
For the specific rim size and adequate tire dimensions try out our Tire size for rim size/width calculator which tells you what tire sizes to pick for entered rim size(i.e., rim width).
The charts in this article show what tire width and series combinations fit to the specific wheel/rim width i.e., they show the tire width range for the given rim width.
E.g., for the 7" (inch) rim width, following tire widths can be fitted: from 195mm to 255mm.
In the charts, beside each tire width, there is one more tire dimension: a tire series. The tire series is the ratio between the tire section height(i.e., tire sidewall height) and the tire section width (i.e., tire width). Series = tire sidewall height / tire width.
If two tires have the same tire width, but different series: the first has 50, the second has 30, that means that the second tire has the smaller tire sidewall height(lower profile) in relation to the first, so rims will be closer to the road.
The tire width, the rim width and the tire series are closely related sizes when we talk about the tire to rim fitment. The reason for this is that for almost every tire series there is a different rim width/tire width ratio(specified by the tire associations). The ratio is used for determining the Measuring Rim for the tire. In other words, a lower aspect ratio means that you could use a wider rim for the same nominal tire width.
Actual tire dimensions depend on a rim on which a tire is mounted. The nominal tire size is imprinted on the tire sidewall, but the tire gets its real dimensions(i.e., real tire size) only when mounted on the rim. That's the reason why a Measuring Rim exists for every tire size.
Next important info is that the tire width changes for about 5mm (2/10") for every 0.5" (inches) change in the rim width, in the Approved Rim Width Range for the tire.
Suppose you have the tire size 195/65 R15 on the 6" (inch) rim width (6"x15"). If you changed the rim to 7"x15", according to the previous rule, when you mount the tire 195/65 R15 on that rim, the real tire width would be 195mm + (2 x 5mm) = 205 mm.
The type of rim, that tire is designed for, is also important.
All these things could affect the overall tire diameter(or circumference), which is important to stay in the permissible limit, during the process of tire replacement.
These charts are only for the passenger car metric tires.
The charts are a compilation of data from year books of renowned tire manufacturers, and it might not be in accordance with the newest data, so please, always check the data from these charts with tire manufacturers or tire specialists!
Looking at one chart row, for one rim width, treated as a measuring rim width(MRW), there are various tire widths in columns, designated as aspect ratio(i.e., tire series/profile). In the row, as series rises, the tire width rises also. So, we may say there are the minimum and the maximum tire width for one rim width, but only in the context of the tire series.
If we took only one cell in the row, which contains one tire width, for e.g., the one with the minimum tire width(TW) for observed rim width(RW), could we say that this is the minimum tire width that can be mounted on the rim width? No. The cell contains the real tire width for the rim width, the one which is equal to the nominal tire width/size(imprinted on the tire sidewall), the one we get when the tire with that nominal tire width is mounted on the rim with the rim width.
This doesn't mean we can't mount a smaller tire width than the one showed in the chart as the smallest for the same rim width. How so? For e.g., the row with 9" rim width lists as the smallest tire width, 255mm for AR: 25,30,35 and 40. Is it possible to mount smaller tire width than 255 on that rim? Yes.
In our Wheel/Rim Size Calculator-Shows acceptable rim width range for the tyre size, enter tire size 245/40 R 18, you'll get approved rim width range(ARWR): 8" – 9.5" and measuring rim width of 8.5", which means you can mount that tire size(with 245mm tire width) on 9" wide rim, because it's in the ARWR for that tire size. But, measuring rim width(MRW) for that tire size is 8.5", and we were talking about mounting the tire on the rim width of 9".
A tire gets its final size after being mounted on a rim. Every rim width increase of 0.5" as a result has tire width increase of 5mm or 2/10", when the tire is mounted.
Every tire size has a measuring rim width and an approved rim width range.
Hence, when we mount the nominal tire size(imprinted on the tire sidewall) 245/40 R 18, which has MRW equal to 8.5", on the rim width of 9", the real tire size, specifically, real tire width would be 250mm, not 245mm, because the rim on which the tire is mounted is 0.5" greater than the tire MRW.
Related articles:
Over the course of the last five years we’ve seen rim profiles change dramatically with the most notable change being in width. Some models of rims even come in several widths. Yet these changes are coming with very vague information from manufacturers about how that rim interfaces with the tire and impacts your ride. Sometimes manufacturers even provide different information for similar profile rims.
The truth is that we, as an industry, are still trying to figure things out.
This leaves a lot of gray area and also plenty of opportunity for you, as the consumer, connoisseur and rider, to weigh in. There are no hard and fast rules, which means you can experiment and lean on experts to help you make informed selections. We’re here to guide you through that process.
The upside is that this also means there is plenty of room to geek out! And boy do we like to geek out!
For the most part, road cycling has settled on 25mm and 28mm tires as the ideal sizes to mate with rims that have a 20-21mm internal width. Larger cycling companies are offering wind tunnel data paired with these tire sizes. The benefits include more stability while descending, further dampening of road vibrations and for you aero-worshippers, better aero performance (less wind turbulence where the tire mates with the rim, and often a toroidal, or tear drop, shape).
The same rules apply to selecting a tire as before: tire casing, thread count and weight still matter.
In fact, they’re more important, I think, because you’re riding on a larger surface area (but that’s a whole other topic for another article).
Tubeless compatibility is also a game changer.
As we get into gravel riding, things get a little foggy. I think the foremost reason is that there aren’t many true gravel (or all-road) rims available capable of handling tires 28-45mm, especially in rim brake models. Finding these rims with tubeless compatibility is even more challenging.
To create a gravel-ready set up, we borrow wide rims from road cycling with features that aren’t needed, such as aero performance. Or we use lightweight 29″ rims that are only available in disc brake models, which may have tire pressure limitations, which may or may not matter for your set-up.
Below are the soft guidelines we think about when designing wheels. Your preference, personal experience and bike tolerances are part of the final consideration.
We will talk you through your options to help you make the perfect selection.
The first step is to figure out what size tire your bike can handle. The pinch points are usually the fork crown, rear brake bridge, and rear triangle by the dropouts. The widest tire you can reliably run leaves about 2mm of clearance on either side of the tire.
Image 1:
The fork crown. The current tire size on this wheel is a 32mm. This rider likely has clearance for a 40mm or 45mm tire.
Image 2:
The chainstays at the bottom bracket. The rider has significant clearance here also.
Image 3:
Brake bridge (even though the brakes aren’t mounted here on this bike). For a rim brake bike, the rider would also have to consider the clearance through the brakes. There is less (but still quite ample) space for a wider tire.
Thanks to our friends at Breadwinner for letting us showcase their B-Road in these examples.
The outer width of the rim and the tire size should be closely aligned with variation depending on subjective preference such as comfort. So, 25mm wide rim with a 25mm wide tire. This would be about 20.5mm internal rim width.
The wall of a carbon rim is thicker than an alloy rim and many carbon manufacturers do extensive wind tunnel testing with different sized tires. For a starting point, I recommend starting with the manufacturer’s tire size recommendation, which is usually 25mm-28mm.
If your wheel set is going to be used for both road and gravel, select a road rim and tire sizes 25mm-50mm. This means an internal rim width of at least 20mm. Ideally, for a 40mm tire intended for gravel roads select a 21-24mm internal rim width. Wider internal widths limit the smallest tire size you can use.
The guidelines are even broader for MTB/Plus riding. Ideally you want a few millimeters of tire on either side of the rim to provide cushion and to protect the rim from hard rock thumps.
The tread of the tire also dictates what the ideal internal width is, or vice versa where you have the wheel set and you’re looking for the perfect tire.
This is where the experimentation becomes both exhilarating and frustrating. You might stumble upon what seems like the perfect set up only to find that tire width is too narrow for a given rim and the tread of the tire is stretched so that the lugs (side knobs) of the tire aren’t useful. The latter typically happens when the tire size and the internal width are too closely matched. If the rim is too narrow, however, the tire can feel floppy, especially through corners.
| Use | Internal Width | IDEAL TIRE RANGE* |
| Road-alloy | 19-21 | 23-28mm |
| Road-carbon | 17-23 | 25-28mm (or per manufacturers recommendation) |
| Gravel | 21-26 | 28-50mm |
| Cross Country MTB + Bikepacking | 26-32 | 1. 9”-2.5”48mm-63mm |
| Plus | 35-45 | 2.5”-3.0” |
*There are no hard and fast rules. For example, many wheels serve multiple purposes and rider preference certainly comes into play. Everything is subject to change. And again, we are here to talk you through your options.
In an ideal world rim manufacturers would offer more precise information. At Sugar Wheel Works, we listen closely to the stories and experiences of riders – our customers and everyone we encounter. We log this data to help inform our recomnendations.
If you like geeking out on these details, a platform like Ride with GPS Ride Reports is a handy way for you to add your input and learn about the experiences of other riders.
If you don’t like geeking out on the details or if all of that sounds too overwhel,ing, we’ve got you covered. Send us a note and we’ll start a conversation to talk you through the perfect combination for your dream wheels.
And we promise to use normal language with easy-to-grasp details.
home
Articles
* These tables are for informational purposes only and are not intended as a guide to action. For specific applicability of non-standard discs, please contact the vehicle manufacturer or vehicle dealer. We do not test wheel interchangeability and cannot make recommendations.
| Landing width of the disc | Minimum tire width | Optimum tire width | Maximum tire width |
|---|---|---|---|
| 5.0 inches | 155 mm | 165 or 175 mm | 185 mm |
| 5.5 inches | 165 mm | 175 or 185 mm | 195 mm |
| 6.0 inches | 175 mm | 185 or 195 mm | 205 mm |
6. 5 inches | 185 mm | 195 or 205 mm | 215 mm |
| 7.0 inches | 195 mm | 205 or 215 mm | 225 mm |
| 7.5 inches | 205 mm | 215 or 225 mm | 235 mm |
| 8.0 inches | 215 mm | 225 or 235 mm | 245 mm |
| 8.5 inches | 225 mm | 235 or 245 mm | 255 mm |
| 9.0 inches | 235 mm | 245 or 255 mm | 265 mm |
| 9.5 inches | 245 mm | 255 or 265 mm | 275 mm |
| 10.0 inches | 255 mm | 265 or 275 mm | 285 mm |
| 10.5 inches | 265 mm | 275 or 285 mm | 295 mm |
| 11.0 inches | 275 mm | 285 or 295 mm | 305 mm |
11. 5 inches | 285 mm | 295 or 305 mm | 315 mm |
| 12.0 inches | 295 mm | 305 or 315 mm | 325 mm |
| 12.5 inches | 305 mm | 315 or 325 mm | 335 mm |
| Profile | Designation in metric dimension | Permissible range of landing width of the disk |
|---|---|---|
| 35 Series | 275/35R17 | 9.0-10.5 |
| 335/35R17 | 11.0-13.0 | |
| 345/35R15 | 11.0-13.5 | |
| 40 Series | 285/40R15 | 11.0-13.5 |
| 215/40R15 | 7.0-8.5 | |
| 245/40R17 | 8.0-9.5 | |
| 255/40R17 | 8. 5-10.0 | |
| 265/40R17 | 8.5-10.0 | |
| 235/40R18 | 8.0-9.5 | |
| 45 Series | 195/45/R15 | 6.5-7.5 |
| 215/45R15 | 7.0-8.5 | |
| 255/45R15 | 8.5-10.0 | |
| 205/45R16 | 7.0 | |
| 225/45R16 | 7.5-9.0 | |
| 245/45R16 | 8.0-9.5 | |
| 215/45R17 | 7.0-8.5 | |
| 235/45R17 | 8.0-9.5 | |
| 255/45R17 | 8.5-10.5 | |
| 50 Series | 175/50R13 | 5.0-6.0 |
| 195/50R14 | 5.5-7.0 | |
| 205/50R15 | 5.5-7.5 | |
| 215/50R15 | 6.0-7.5 | |
| 225/50R15 | 6. 0-8.0 | |
| 195/50R16 | 5.5-7.0 | |
| 205/50R16 | 5.5-7.5 | |
| 225/50R16 | 6.0-8.0 | |
| 235/50R16 | 6.5-8.5 | |
| 215/50R17 | 6.5-7.5 | |
| 55 Series | 205/55R14 | 5.5-7.5 |
| 185/55R15 | 6.0-6.5 | |
| 195/55R15 | 5.5-7.0 | |
| 205/55R15 | 5.5-7.5 | |
| 205/55R16 | 5.5-7.5 | |
| 225/55R16 | 6.0-8.0 | |
| 60 Series | 185/60R13 | 5.0-6.5 |
| 205/60R13 | 5.5-7.5 | |
| 185/60R14 | 5.0-6.5 | |
| 195/60R14 | 5.5-7.0 | |
| 205/60R14 | 5. 5-7.5 | |
| 195/60R15 | 5.5-7.0 | |
| 205/60R15 | 5.5-7.5 | |
| 215/60R15 | 6.0-7.5 | |
| 225/60R15 | 6.0-8.0 | |
| 235/60R15 | 6.5-8.5 | |
| 65 Series | 185/65R15 | 5.0-6.5 |
| 195/65R15 | 5.5-7.0 | |
| 205/65R15 | 5.5-7.5 | |
| 215/65R15 | 6.0-7.5 | |
| 70 Series | 165/70R10 | 4.5-5.5 |
| 175/70R12 | 5.0-6.0 | |
| 175/70R13 | 5.0-6.0 | |
| 205/45R16 | 7.0 | |
| 185/70R13 | 5.0-6.5 | |
| 185/70R14 | 5.0-6.5 | |
| 195/70R15 | 5.5-7. 0 | |
| 205/70R14 | 5.5-7.5 | |
| 185/70R15 | 5.0-6.5 | |
| 205/70R15 | 5.5-7.5 | |
| 215/70R15 | 6.0-7.5 | |
| 82 Series | 155R12 | 4.0-5.0 |
| 155R13 | 4.0-5.5 | |
| 165R13 | 4.0-5.5 | |
| 175R14 | 4.5-6.0 | |
| 185R14 | 4.5-6.0 | |
| 165R15 | 4.0-5.5 | |
| Profile | Designation in metric dimension | Permissible range of landing width of the disk |
|---|---|---|
| 75 Series | P205/75R15 | 5.5-7.5 |
| P215/75R15 | 5. 5-7.5 | |
| P225/75R15 | 6.0-8.0 | |
| P235/75R15 | 6.0-8.0 | |
| 80 Series | P155/80R13 | 4.5-5.5 |
| P165/80R13 | 4.5-6.0 | |
| P175/80R13 | 4.5-6.0 | |
| P185/80R13 | 5.0-6.5 | |
| 35 Series | P315/35R17 | 10.0-12.0 |
| 40 Series | P275/40R17 | 8.5-10.0 |
| 50 Series | P215/50R13 | 5.5-8.5 |
| P235/50R13 | 6.0-9.0 | |
| P245/50R14 | 6.5-9.0 | |
| P225/50R15 | 6.0-8.0 | |
| P295/50R15 | 7.5-11.0 | |
| P225/50R16 | 6.0-8.0 | |
| P245/50R16 | 6. 5-9.5 | |
Return to list
Tire and rim size charts
| Diameter | Size | Rim width | ||
|---|---|---|---|---|
| Min. | Recommended mend. | Max. | ||
| 12 | 125 R12 | 3.5 | 3.0 | 4.0 |
| 135 R12 | 4.0 | 3.5 | 4.5 | |
| 145 R12 | 4.0 | 3.5 | 5.0 | |
| 155 R12 | 4. 5 | 4.0 | 5.0 | |
| 145/70 R12 | 4.5 | 4.0 | 5.0 | |
| 155/70 R12 | 4.5 | 4.0 | 5.5 | |
| 13 | 145/80 R13 | 3.5 | 4 | 5 |
| 145/70 R13 | 3.5 | 4.5 | 5 | |
| 145/60 R13 | 4 | 4.5 | 5 | |
| 155/80 R13 | 4 | 4.5 | 5 | |
| 155/70 R13 | 4 | 4.5 | 5 | |
| 165/80 R13 | 4 | 4.5 | 5 | |
| 165/70 R13 | 4 | 5 | 5.5 | |
| 165/65 R13 | 4.5 | 5 | 6 | |
| 175/70 R13 | 4.5 | 5 | 6 | |
| 175/65 R13 | 5 | 5 | 6 | |
| 185/70 R13 | 4. 5 | 5.5 | 6 | |
| 14 | 145/65 R14 | 4 | 4.5 | 5 |
| 155/65 R14 | 4.5 | 4.5 | 5.5 | |
| 165/70 R14 | 4 | 5 | 5.5 | |
| 165/65 R14 | 4.5 | 5 | 6 | |
| 165/60 R14 | 4.5 | 5 | 6 | |
| 175/80 R14 | 4.5 | 5 | 6 | |
| 175/70 R14 | 4.5 | 5 | 6 | |
| 175/65 R14 | 5 | 5 | 6 | |
| 175/60 R14 | 5 | 5 | 6 | |
| 185/70 R14 | 4.5 | 5.5 | 6 | |
| 185/65 R14 | 5 | 5.5 | 6.5 | |
| 185/60 R14 | 5 | 5.5 | 6. 5 | |
| 185/55 R14 | 5 | 6 | 6.5 | |
| 195/70 R14 | 5 | 6 | 6.5 | |
| 195/65 R14 | 5.5 | 6 | 7 | |
| 195/60 R14 | 5.5 | 6 | 7 | |
| 15 | 145/65 R15 | 4 | 4.5 | 5 |
| 155/70 R15 | 4 | 4.5 | 5 | |
| 155/65 R15 | 4.5 | 4.5 | 5.5 | |
| 165/65 R15 | 4.5 | 5 | 6 | |
| 175/65 R15 | 5 | 5 | 6 | |
| 175/60 R15 | 5 | 5 | 6 | |
| 175/55 R15 | 5 | 5.5 | 6 | |
| 185/65 R15 | 5 | 5.5 | 6.5 | |
| 185/60 R15 | 5 | 5. 5 | 6.5 | |
| 185/55 R15 | 5 | 6 | 6.5 | |
| 195/70 R15 | 5 | 6 | 6.5 | |
| 195/65 R15 | 5.5 | 6 | 7 | |
| 195/60 R15 | 5.5 | 6 | 7 | |
| 195/55 R15 | 5.5 | 6 | 7 | |
| 195/50 R15 | 5.5 | 6 | 7 | |
| 195/45 R15 | 6 | 6.5 | 7.5 | |
| 205/70 R15 | 5 | 6 | 7 | |
| 205/65 R15 | 5.5 | 6 | 7.5 | |
| 205/60 R15 | 5.5 | 6 | 7.5 | |
| 205/55 R15 | 5.5 | 6.5 | 7.5 | |
| 205/50 R15 | 5.5 | 6.5 | 7.5 | |
| 215/70 R15 | 5. | 6.5 | 7 | |
| 215/65 R15 | 6 | 6.5 | 7.5 | |
| 225/60 R15 | 6 | 6.5 | 8 | |
| 225/55 R15 | 6 | 7 | 8 | |
| 225/50 R15 | 6 | 7 | 8 | |
| 16 | 195/60 R16 | 5.5 | 6 | 7 |
| 195/55 R16 | 5.5 | 6 | 7 | |
| 195/50 R16 | 5.5 | 6 | 7 | |
| 195/45 R16 | 6 | 6.5 | 7.5 | |
| 205/60 R16 | 5.5 | 6 | 7.5 | |
| 205/55 R16 | 5.5 | 6.5 | 7.5 | |
| 205/50 R16 | 5.5 | 6.5 | 7.5 | |
| 205/45 R16 | 6.5 | 7 | 7. 5 | |
| 215/65 R16 | 6 | 6.5 | 7.5 | |
| 215/60 R16 | 6 | 6.5 | 7.5 | |
| 215/55 R16 | 6 | 7 | 7.5 | |
| 215/40 R16 | 7 | 7.5 | 8.5 | |
| 225/60 R16 | 6 | 6.5 | 8 | |
| 225/55 R16 | 6 | 7 | 8 | |
| 225/50 R16 | 6 | 7 | 8 | |
| 235/60 R16 | 6.5 | 7 | 8.5 | |
| 245/55 R16 | 7.5 | 8 | 9 | |
| 17 | 205/55 R17 | 5.5 | 6.5 | 7.5 |
| 205/50 R17 | 5.5 | 6.5 | 7.5 | |
| 205/45 R17 | 6.5 | 7 | 7.5 | |
| 205/40 R17 | 7 | 7. 5 | 8 | |
| 215/60 R17 | 6 | 6.5 | 7.5 | |
| 215/55 R17 | 6 | 7 | 7.5 | |
| 215/50 R17 | 6 | 7 | 7.5 | |
| 215/45 R17 | 7 | 7 | 8 | |
| 215/40 R17 | 7 | 7.5 | 8.5 | |
| 225/60 R17 | 6 | 6.5 | 8 | |
| 225/55 R17 | 6 | 7 | 8 | |
| 225/50 R17 | 6 | 7 | 8 | |
| 225/45 R17 | 7 | 7.5 | 8.5 | |
| 225/35 R17 | 7.5 | 8 | 9 | |
| 235/65 R17 | 6.5 | 7 | 8.5 | |
| 235/55 R17 | 6.5 | 7.5 | 8.5 | |
| 235/50 R17 | 6. 5 | 7.5 | 8.5 | |
| 235/45 R17 | 7.5 | 8 | 9 | |
| 235/40 R17 | 8 | 8.5 | 9.5 | |
| 245/55 R17 | 7 | 7.5 | 8.5 | |
| 245/45 R17 | 7.5 | 8 | 9 | |
| 245/40 R17 | 8 | 8.5 | 9.5 | |
| 255/55 R17 | 7 | 8 | 9 | |
| 255/45 R17 | 8 | 8.5 | 9.5 | |
| 255/40 R17 | 8.5 | 9 | 10 | |
| 265/40 R17 | 9 | 9.5 | 10.5 | |
| 275/40 R17 | 9 | 9.5 | 11 | |
| 285/40 R17 | 9.5 | 10 | 11 | |
| 335/35 R17 | 11 | 12 | 13 | |
| 18 | 205/40 R18 | 7 | 7. 5 | 8 |
| 215/45 R18 | 7 | 7 | 8 | |
| 225/60 R18 | 6 | 6.5 | 8 | |
| 225/45 R18 | 7 | 7.5 | 8.5 | |
| 225/40 R18 | 7.5 | 8 | 9 | |
| 225/35 R18 | 7.5 | 8 | 9 | |
| 235/65 R18 | 6.5 | 7 | 8.5 | |
| 235/50 R18 | 6.5 | 7.5 | 8.5 | |
| 235/45 R18 | 7.5 | 8 | 9 | |
| 235/40 R18 | 8 | 8.5 | 9.5 | |
| 245/50 R18 | 7 | 7.5 | 8.5 | |
| 245/45 R18 | 7.5 | 8 | 9 | |
| 245/40 R18 | 8 | 8.5 | 9.5 | |
| 245/35 R18 | 8 | 8. 5 | 9.5 | |
| 255/45 R18 | 8 | 8.5 | 9.5 | |
| 255/40 R18 | 8.5 | 9 | 10 | |
| 255/35 R18 | 8.5 | 9 | 10 | |
| 265/40 R18 | 9 | 9.5 | 10.5 | |
| 265/35 R18 | 9 | 9.5 | 10.5 | |
| 275/45 R18 | 8.5 | 9 | 10.5 | |
| 275/40 R18 | 9 | 9.5 | 11 | |
| 275/35 R18 | 9 | 9.5 | 11 | |
| 285/40 R18 | 9.5 | 10 | 11 | |
| 285/35 R18 | 9.5 | 10 | 11 | |
| 285/30 R18 | 10 | 10 | 10.5 | |
| 295/35 R18 | 10 | 10.5 | 11.5 | |
| 295/30 R18 | 10. 5 | 10.5 | 11 | |
| 315/30 R18 | 11 | 11 | 12.5 | |
| 335/30 R18 | 12 | 12 | 12.5 | |
| 345/35 R18 | 11.5 | 12 | 13.5 | |
| 345/30 R18 | 12 | 12 | 12.5 | |
| 19 | 225/40 R19 | 7.5 | 8 | 9 |
| 225/35 R19 | 7.5 | 8 | 9 | |
| 235/35 R19 | 8 | 8.5 | 9.5 | |
| 245/45 R19 | 7.5 | 8 | 9 | |
| 245/40 R19 | 8 | 8.5 | 9.5 | |
| 245/35 R19 | 8 | 8.5 | 9.5 | |
| 255/40 R19 | 8.5 | 9 | 10 | |
| 255/35 R19 | 8.5 | 9 | 10 | |
| 255/30 R19 | 8. 5 | 9 | 9.5 | |
| 265/35 R19 | 9 | 9.5 | 10.5 | |
| 265/30 R19 | 9 | 9.5 | 10 | |
| 275/50 R19 | 7.5 | 8.5 | 9.5 | |
| 275/40 R19 | 9 | 9.5 | 11 | |
| 275/35 R19 | 9 | 9.5 | 11 | |
| 275/30 R19 | 9 | 9.5 | 10 | |
| 285/35 R19 | 9.5 | 10 | 11 | |
| 295/30 R19 | 10.5 | 10.5 | 11 | |
| 305/30 R19 | 11 | 11 | 12 | |
| 315/25 R19 | 11 | 11.5 | 12 | |
| 325/30 R19 | 11 | 11.5 | 12 | |
| 345/30 R19 | 12 | 12 | 12.5 | |
| 20 | 235/30 R20 | 8. 5 | ||
| 245/40 R20 | 8 | 8.5 | 9.5 | |
| 245/35 R20 | 8 | 8.5 | 9.5 | |
| 245/30 R20 | 8 | 8.5 | 9 | |
| 255/35 R20 | 8.5 | 9 | 10 | |
| 255/30 R20 | 8.5 | 9 | 9.5 | |
| 275/45 R20 | 8.5 | 9 | 10.5 | |
| 275/35 R20 | 9 | 9.5 | 11 | |
| 285/30 R20 | 10 | 10 | 10.5 | |
| 285/25 R20 | 10.5 | |||
| 295/25 R20 | 10.5 | 10.5 | 11 | |
| 305/35 R20 | 10 | 11 | 12 | |
| 305/25 R20 | 10.5 | 11 | 11.5 | |
| 325/25 R20 | 11. 5 | 12 | 12.5 | |
| 335/30 R20 | 12 | 12 | 12.5 | |
| 21 | 245/35 R21 | 8 | 8.5 | 9.5 |
| 255/30 R21 | 9 | 9 | 9.5 | |
| 285/30 R21 | 10 | 10 | 10.5 | |
| 295/25 R21 | 10 | 10.5 | 11 | |
| 22 | 255/30 R22 | 8.5 | 9 | 9.5 |
| 295/25 R22 | 10.5 | 10.5 | 11 | |
| Diameter | Size | Rim width | ||
|---|---|---|---|---|
| Min. | Recommended mend. | Max. | ||
| 15 | 185/65 R15 | 5 | 5.5 | 6.5 |
| 195/80 R15 | 5 | 5.5 | 6.5 | |
| 195/70 R15 | 5 | 6 | 6.5 | |
| 205/70 R15 | 5 | 6 | 7 | |
| 215/80 R15 | 5.5 | 6 | 7 | |
| 225/75 R15 | 6 | 6 | 7.5 | |
| 235/75 R15 | 6 | 6.5 | 8 | |
| 255/75 R15 | 6.5 | 7 | 8.5 | |
| 265/70 R15 | 7 | 8 | 9 | |
| 16 | 205/80 R16 | 5 | 5.5 | 7 |
| 215/70 R16 | 5.5 | 6.5 | 7 | |
| 215/65 R16 | 6 | 6. 5 | 7.5 | |
| 215/60 R16 | 6 | 6.5 | 7.5 | |
| 225/75 R16 | 6 | 6 | 7.5 | |
| 225/70 R16 | 6 | 6.5 | 7.5 | |
| 235/85 R16 | 6 | 6.5 | 7.5 | |
| 235/70 R16 | 6 | 7 | 8 | |
| 235/60 R16 | 6.5 | 7 | 8.5 | |
| 245/70 R16 | 6.5 | 7 | 8 | |
| 255/70 R16 | 6.5 | 7.5 | 8.5 | |
| 255/65 R16 | 7 | 7.5 | 9 | |
| 265/70 R16 | 7 | 8 | 9 | |
| 275/70 R16 | 7 | 8 | 9 | |
| 17 | 225/65 R17 | 6 | 6.5 | 8 |
| 225/55 R17 | 6 | 7 | 8 | |
| 235/65 R17 | 6. 5 | 7 | 8.5 | |
| 235/55 R17 | 6.5 | 7.5 | 8.5 | |
| 245/65 R17 | 7 | 7 | 8.5 | |
| 255/60 R17 | 7 | 7.5 | 9 | |
| 255/50 R17 | 7 | 8 | 9 | |
| 265/65 R17 | 7.5 | 8 | 9.5 | |
| 265/70 R17 | 7 | 8 | 9 | |
| 275/65 R17 | 7.5 | 8 | 9.5 | |
| 275/55 R17 | 7.5 | 8.5 | 9.5 | |
| 18 | 225/55 R18 | 6 | 7 | 8 |
| 235/60 R18 | 6.5 | 7 | 8.5 | |
| 235/50 R18 | 6.5 | 7.5 | 8.5 | |
| 255/60 R18 | 7 | 7.5 | 9 | |
| 255/55 R18 | 7 | 8 | 9 | |
| 255/45 R18 | 8 | 8. 5 | 9.5 | |
| 265/60 R18 | 7.5 | 8 | 9.5 | |
| 285/50 R18 | 8 | 9 | 10 | |
| 19 | 255/55 R19 | 7 | 8 | 9 |
| 255/50 R19 | 7 | 8 | 9 | |
| 275/45 R19 | 8.5 | 9 | 10.5 | |
| 285/45 R19 | 9 | 9.5 | 10.5 | |
| 20 | 255/50 R20 | 7 | 8 | 9 |
| 275/50 R20 | 7.5 | 8.5 | 9.5 | |
| 275/40 R20 | 9 | 9.5 | 11 | |
| 295/40 R20 | 10 | 10.5 | 11.5 | |
| 315/35 R20 | 10.5 | 11 | 12.5 | |
| 21 | 295/35 R21 | 10 | 10. 5 | 11.5 |
| 22 | 285/35 R22 | 9.5 | 10 | 11 |
| 295/30 R22 | 10 | 10.5 | 11 | |
| 23 | 315/25 R23 | 11 | 11.5 | 12 |
| Diameter | Size | Rim width | ||
|---|---|---|---|---|
| Min. | Recommended mend. | Max. | ||
| 13 | 155/80 R13 | 4 | 4.5 | 5 |
| 165/70 R13 | 4.5 | 5 | 5 | |
| 14 | 165/70 R14 | 4.5 | 5 | 5 |
| 165/75 R14 | 4 | 4. 5 | 5 | |
| 175/65 R14 | 5 | 5 | 5.5 | |
| 175/75 R14 | 4.5 | 5 | 5.5 | |
| 185/75 R14 | 4.5 | 5 | 6 | |
| 185/80 R14 | 4.5 | 5 | 6 | |
| 195/75 R14 | 5 | 5.5 | 6 | |
| 195/80 R14 | 5 | 5.5 | 6 | |
| 205/75 R14 | 5 | 5.5 | 6.5 | |
| 15 | 185/80 R15 | 4.5 | 5 | 6 |
| 195/70 R15 | 5.5 | 6 | 6 | |
| 205/65 R15 | 5.5 | 6 | 6.5 | |
| 205/70 R15 | 5.5 | 6 | 6.5 | |
| 215/65 R15 | 6 | 6.5 | 7 | |
| 215/70 R15 | 6 | 6. 5 | 7 | |
| 225/70 R15 | 6 | 6.5 | 7 | |
| 16 | 6.5/100 R16 | 4.5 | 4.5 | 6 |
| 175/75 R16 | 4.5 | 5 | 5.5 | |
| 175/80 R16 | 4.5 | 5 | 5.5 | |
| 185/75 R16 | 4.5 | 5 | 6 | |
| 195/60 R16 | 5.5 | 6 | 6.5 | |
| 195/65 R16 | 5.5 | 6 | 6 | |
| 195/75 R16 | 5 | 5.5 | 6 | |
| 205/65 R16 | 5.5 | 6 | 6.5 | |
| 205/75 R16 | 5 | 5.5 | 6.5 | |
| 215/60 R16 | 6 | 6.5 | 7 | |
| 215/65 R16 | 6 | 6.5 | 7 | |
| 215/75 R16 | 5.  | |||
