How to change front tire on zero turn mower


How to Fix a Front Flat Tire on a Cub Cadet Zero Turn Mower | Home Guides

By Mary Lougee

The front tires on a zero turn mower are caster wheels that swivel to enable the rear drive wheels to make sharp turns and speedily cut a lawn. Fixing a flat tire on your Cub Cadet mower means using one method for small holes under 1/16 inch or a second method for larger punctures.

Small Holes or Slow Leaks

  1. Pull out any object, such as a nail or screw, that made the puncture, if it is visible, with a pair of pliers.

  2. Remove the valve cap counterclockwise and set it aside. Unwind the hose of a can of aerosol tire inflator.

  3. Shake the can vigorously for about 30 seconds to activate the can contents. Press the end of the tire inflator hose onto the valve stem. Release the end and pull slightly back on the hose to make certain it is locked in place.

  4. Press the button on top of the can while holding it in an upright position until you no longer see the product traveling through the clear hose into the tire. Pull the locking collar back and remove it from the valve stem.

  5. Drive the lawn mower slowly for a few minutes to distribute the tire inflator, if the tire rim is off the ground. Otherwise, add air from an air compressor to inflate the tire to between 20 and 25 psi and then drive the mower to distribute the tire inflator. Replace the valve cap and tighten it clockwise.

Larger Holes

  1. Park the lawn mower on a flat hard surface, such as a driveway. Place a brick behind each of the rear wheels so they cannot move.

  2. Insert a jack under the axle near the flat tire and raise it so the tire is off the ground a few inches. Loosen and remove the lock nut on the flat tire's axle with an adjustable wrench. Pull the axle outward and the tire and two spacers will drop free.

  3. Apply a few squirts of dish detergent to a bucket, add water from a garden hose and swish the contents to make a soapy mixture.

  4. Place the flat tire in the bucket, turn it slowly and observe it for soap bubbles. Holes in the tire are evident when air leaks out of the tire. Mark each area with a paint marker.

  5. Insert the small tip of a rubber tire plug from a tire repair kit into the eye of the needle tool. Insert the needle with the plug into a marked hole until it has about two-thirds of its length inside the tire.

  6. Pull the needle tool straight out without turning or twisting it to deposit the plug in the hole. Trim off excess plug on the outside of the tire with scissors.

  7. Add air to the tire from an air compressor to between 20 and 25 psi. Replace the tire on the lawn mower with a spacer on each side and slide it onto the axle. Replace the locking nut on it and tighten it clockwise with an adjustable wrench. Release the jack to lower the lawn mower and remove the bricks from the rear tires.

References

  • Cub Cadet: Model 18HP 48" Stamped Deck Operator's and Service Manual

Resources

  • University of California Agriculture & Natural Resources: Recommended Cutting Height

Tips

  • Keep valve stem caps on tires tight to prevent slow leaks.
  • Remove debris and loose grass before mowing an area. Loose leaves and other objects reduce the traction from the rear tires.
  • Tire plug kits are available at automotive, home improvement and hardware stores.

Warnings

  • Mow across the face of slopes, rather than up and down them to prevent the mower from tipping over.

Writer Bio

Mary Lougee has been writing for over 10 years. She holds a Bachelor's Degree with a major in Management and a double minor in accounting and computer science. She loves writing about careers for busy families as well as family oriented planning, meals and activities for all ages.
