“A tire only loses air if it’s punctured.” This is a common misconception that we have all had or heard and yet the reality is quite different. Indeed, a tire can lose air even without a puncture, as for example in the case of a crack in the valve that is used to inflate your tires. A punctured valve is difficult to detect, and not taking care of it in time can have real consequences for your tire, but also (and above all!) for your safety. Blackcircles Canada, your online tire specialist, offers below a complete guide to the causes and consequences of a punctured valve, and how to repair a leaking valve stem.

Wear and tear is the main cause of a leaking valve.

A valve is a pin located on the outside of the tire, through which the tire can be inflated/deflated. It has a mechanism consisting of a spring-mounted valve that closes tightly with the air pressure inside the tire. Over time, the stem valve may become brittle and cracked, which may increase the risk of air leaking through it.

When the stem valve leaks, the affected tire is no longer able to retain air. Depending on the extent of the damage, the air will leak out slowly or more quickly. In both cases, the valve must be replaced.

If the air leakage is slow, you will be subject to the problems encountered by drivers driving with underinflated tires. Internal damage that can shorten the service life of the tire by up to a quarter, increased fuel consumption due to higher rolling resistance: the tire will damage faster, and your energy-efficiency will be significantly lower. The tire will also have poorer traction and the stability of your car will be reduced when cornering, not to mention the more pronounced deformation of the tire that increases its internal temperature, which can cause it to burst. Finally, an under-inflated tire increases the risk of hydroplaning. Tire pressure is thus very important!

Repairing a leaking tire valve is therefore imperative.

Here’s how to do it!

Step 1: Make sure it’s your valve stem that’s leaking.

First of all, make sure it is the tire valve stem that is leaking. To do so, there’s a very simple trick! Apply a mixture of water and dishwashing soap to the valve with the cap removed. If bubbles start to appear, your valve is leaking. If this is not the case, and there is a definite air leak, it will be located elsewhere on the tire.

Step 2: Gather the right tools before you start!

Before you begin, make sure you have all the necessary equipment to complete the replacement of the faulty valve stem.

For this, you will need the following:

  • An air compressor with the right nozzle for your tire,
  • A jack,
  • Jack stands,
  • A lug nut wrench for wheel mounting/removal,
  • Needle-nosed pliers,
  • A big hammer, preferably a sledgehammer,
  • A tire iron,
  • A valve stem removal tool,
  • A new valve stem.

You are now ready to start the process!

Step 3: Loosen the nuts on the wheel you are going to work on.

To do so, use the wrench mentioned in the previous step to loosen each of the lug nuts holding your wheel in place. Do this while the car is still on the ground.

However, for certain models of vehicles, it is possible that the wheel nuts have an anti-theft ring. If this is the case, you’ll have to use the appropriate special key to remove the locking nut(s).

Step 4: Raise your vehicle with the jack and then remove the wheel.

First and foremost, make sure the handbrake is applied so that your vehicle is completely immobilized. Then, use your jack to lift your car. Be sure to position it on the right part of the chassis so that the car is properly supported. This will prevent any damage to the car and any bodily injury. Once your car is lifted, secure it on jack stands. Unscrew the wheel bolts completely, then remove the wheel. Finally, place the wheel on the ground flat, with the outside of the wheel facing up.

Step 5: Remove the valve stem core with the removal tool and let the tire deflate.

If you have not already done so, remove the valve cap. Then remove the valve stem core using the valve stem removal tool to release the air from the wheel, which should normally deflate completely on its own.

Step 6: Separate the tire’s bead from the wheel.

For this step, use the sledgehammer in the following way: hit the tire sidewall with the sledgehammer in the same spot until you hear a crack or popping sound, and see the inside lip of the tire visibly break loose from the rim. This means that the tire has been successfully detached from the lip of the wheel.

Once the tire bead has been broken, continue hitting with the sledgehammer around the tire to detach the sidewall around the entire circumference of the wheel.

Step 7: Remove the tire from the rim.

Once the sidewall of the tire is separated from the outer edge of the rim around the entire circumference of the wheel, insert your tire iron between the edge of the rim and the inside lip of the tire, and then pry upward to pull the lip of the tire over the edge of the wheel. Once you have pulled the lip of the tire over the edge of the wheel, work the tire iron around the rim until the entire lip of the tire is off the rim.

Once the sidewall of the tire is completely above the wheel, grab it by its removed lip and pull it upward so that the opposite lip that was at the bottom of the wheel is now touching the top edge of the rim. Use your tire iron again by inserting it between the tire’s lip and the edge of the wheel and pry upwards to pull the lip over the edge of the rim. As before, work the tire iron around the edge of the wheel until the tire is removed from the wheel.

Step 8: Remove the defective valve stem and replace it with the new one.

Once the tire is separated from the rim, it is time to remove the valve stem. To do this, first pull out the valve stem free from the wheel using the needle-nose pliers. Once this has been done, install the replacement valve stem from the inside of the wheel. Once it is in position, use the needle-nose pliers again to pull it through into its right place on the wheel.

Step 9: Reinstall the tire on the wheel and inflate it.

Once the stem is in place, it is time to put the tire back on its rim. To do this, start by pressing the tire down over the rim until the bottom bead clears the edge of the rim. The aim here is to return the lower sidewall of the tire to its original position on the wheel.

Then press the upper sidewall of the tire down underneath the edge of the wheel. Then tuck your tire iron between the tire sidewall and the rim edge and use it to make the opposite movement to the one you used to pull the tire sidewall out of the rim. Once the bead clears the lip of the wheel, use the tire iron to work your way round the entire wheel until the tire is completely installed on the wheel. Then inflate it to the correct pressure using the air compressor.

Step 10: Make sure there are no other leaks, and mount your wheel back on!

Once the tire is inflated to the correct pressure, check for other leaks. If all is well, mount the wheel on your vehicle and bring it down by lowering the level of the jack stands until the repaired wheel touches the ground and you can safely remove them.

Ultimately, it is very important to make sure your tires are free of air leaks to maintain proper air pressure at all times. In the case of a slow air leak, the consequences can be dramatic. If the air leak is due to a faulty tire valve, you will definitely need to replace it. You can either follow the above procedure on how to repair a leaking tire valve or take it directly to a specialist. If, on the other hand, you need to change the entire tire, consult our selection of tires adapted for your car directly online on our website!

Tire Installation 101: When and how to change your tires?

About the Author

Similar articles

How do I fix a tire valve stem leak?

I just filled up my tires and, two days later, my right tire is losing pressure. I’ve checked the tire for leaks and don’t think the tire itself needs replacing, so my next guess is the tire valve stem is leaking. How do I fix a tire valve stem leak?

Rachel Juillerat · Answered on Feb 18, 2022

Reviewed by Shannon Martin, Licensed Insurance Agent.

Fortunately for you, fixing a tire valve stem leak is both easy and cheap. You just need to purchase a replacement tire valve stem and a valve core tool. A pack containing both of these items is on Amazon for less than $5!

To replace the leaking tire valve stem, do the following:

  • Wear goggles (in case dirt or the tire valve stem go flying into your face).
  • Use the core valve tool to pull out the old stem and replace it with the new one.
  • Use the core valve tool to tighten the stem until it’s snug (it’s easy to strip the threading, so don’t over tighten the new stem).
  • Make sure you put the stem’s cover back on to prevent dirt from getting in!

Note: If you notice corrosion on the old stem, be sure to clean the interior threads of the tire stem on the tire.

While this is an easy and cheap fix, there are some car fixes you may need assistance with, so it’s always a good idea to invest in a solid car insurance policy.

Jerry makes finding the right policy for you easy. Jerry compares personalized rates from more than 50 top providers and delivers the best deals to your phone in minutes for free. The average Jerry driver saves $887 a year on car insurance.

MORE: Will insurance cover a flat tire?

Car RepairCar Tires

View full answer

WHY YOU CAN TRUST JERRY

Jerry partners with more than 50 insurance companies, but our content is independently researched, written, and fact-checked by our team of editors and agents. We aren’t paid for reviews or other content.

Browse More Content

Car Repair Resources
  • Car Heater Blower Motor Resistor Replacement

  • What To Do If You Smell Oil In Car

  • What To Do If Clutch Is Not Fully Disengaging

  • Ignition Relay Replacement Cost Estimate

  • What To Do If Your Window Is Moving Up Or Down Very Slowly

Insurance for Your Car
  • Chevrolet Impala Super Sport Insurance Cost

  • Saturn Vue Insurance Cost

  • Cadillac Xt4 Premium Luxury Insurance Cost

  • Dodge Durango Insurance Cost

  • Subaru Outback Wilderness Insurance Cost

Insurance in Your State
    Insurance In Your City
    • Jonben Car Insurance

    • Aberdeen Car Insurance

    • Ocean Isle Beach Car Insurance

    • Christiana Car Insurance

    • Rochester Car Insurance

    What Others Are Asking
    How much does car insurance for a Lamborghini cost?

    I’ve loved Lamborghinis since I was a kid. They’re sleek, they’re fast—they’re my dream car! I’m already saving up to buy one someday. How much does car insurance for a Lamborghini cost?

    Melanie Johnson

    Feb 18, 2022

    Can I ask a judge to reduce a ticket?

    I got a ticket yesterday and I’m so bummed. I’ve never gotten a ticket before—I was just zoned out and didn't realize I was going 10 over. Can I ask the judge to reduce my ticket?

    Melanie Johnson

    Feb 18, 2022

    Where can I sell my car that doesn’t run anymore?

    I’ve been sitting on my old car that no longer works and I’m ready to move on and clean out. Where can I sell it?

    Pat Roache

    Feb 18, 2022

    Browse All Questions

    Read Advice From Car Experts At Jerry

    2013 Audi S8 0-60 Time

    The 2013 Audi S8 0-60 time is 3.6 seconds. Can it keep up with the competition?

    Ethan Moser

    Sep 16, 2022

    2022 Bentley Flying Spur MSRP and Pricing Information

    The 2022 Bentley Flying Spur MSRP starts at $208,225, but you’ll likely pay more at the dealership. Click to find out why.

    Ethan Moser

    Aug 04, 2022

    Why You Should Know About Bentley's Mulliner

    Bentley Mulliner gives ultra-luxe Bentleys even more personalized treatment.

    Ethan Moser

    Aug 12, 2022

    Browse By Topics

    Speeding

    driving record

    Car Body Repair

    Car Reviews

    FS-1 Form

    Collision Coverage

    Car Loans

    No Fault State

    Emergency Insurance

    State Farm

    Young Drivers

    Cheap Auto Insurance

    Full Coverage Insurance

    Car Prices

    driving record

    Travelers

    Natural Disasters

    Save Money

    Title Transfers

    Donating a Car

    Fleet Sales

    Identity Theft

    Chrysler

    Mitsubishi

    No long forms

    No spam or unwanted phone calls

    Quotes from top insurance companies

    Find insurance savings — it's 100% free

    Car Insurance by Make

    Toyota

    Hyundai

    Mercedes-Benz

    Subaru

    Chevrolet

    Mitsubishi

    Car Insurance by State

    The faucet is dripping, what to do if the faucet is leaking - Armashop.

    ua

    There is nothing more irritating when water drips from the faucet. This negatively affects the nervous system of the tenants of the apartment, and increases the consumption of energy resources, for which you have to pay.

    The faucet is leaking: causes and repair technology

    If the faucet is dripping, the breakdown is solved in two ways:

    1) call a plumber;

    2) fix the leaks yourself.

    Those who chose the last option should first of all figure out why the water is dripping from the tap, since there can be many options:

    1. Poor quality faucet installed. Buying cheap plumbing in order to save money will soon turn against you in the form of a failed product. The water tap is leaking due to poorly fitting components or extremely poor quality gaskets, which actively wear out under the influence of water pressure.
    2. Incorrect installation. The result of a leaking ball valve may be a violation of the installation technology or banal inattention. Do not be surprised if an expensive branded ball valve drips - it was not installed correctly. If there is little experience and no skills, do not take risks, call the master. nine0022
    3. Violation of operation. In 70% of cases, the breakdown is the result of improper handling of the device. Strong pressure, twisting the valve at a curved angle, applying a lot of force to the spout will lead to a quick failure of the product.
    4. Natural wear. Over time, the parts and assemblies of the locking device are subject to wear, the gaskets are worn out, and as a result, water flows from the tap. What to do in this case? Periodic inspection of the equipment and regular maintenance with the replacement of worn components will help prevent an unforeseen situation. But almost no one does this. They remember him when the "lamb" of the crane flows. nine0022

    What to do if the faucet drips in the kitchen

    A single-lever mixer is usually mounted here. The result of a leak in 50% of cases is a violation of the integrity of the gasket and rubber or damage to the locking elements.

    How and what to do so that the faucet does not drip? You need to buy a repair kit and replace the damaged product. We shut off the water. Then the crane box is disassembled. If it's a worn gasket, change it.

    If a leak is observed in the area where the sink and faucet are joined, the most likely cause lies in a defect in the sealing ring. You will need to remove and replace the seal. Given the design differences between the devices, it is advisable to read the manufacturer's instructions. nine0003

    Important! When installing the gasket, make sure it fits snugly. Otherwise, the liquid will leak out and the expected effect will not happen. If there is water with rust and mechanical impurities in the pipeline, open the tap and let the water escape for a couple of minutes. Simple manipulations will remove blockages and improve pressure.

    Experts advise to replace the crane box or the entire crane. To replace, you will need a screwdriver to unscrew the screw located on the flywheel under the plug. To unscrew the faucet box, you need a pipe wrench.

    Tip! Remember the sequence of manipulations so that during assembly there are no extra spare parts on hand.

    Having changed the gasket and assembled the device, carefully open the supply at the inlet and observe whether water continues to drip from the tap. How to fix plumbing if leakage has not stopped? Without hesitation, you need to contact the services of a plumber and remember the technology of work in order to repair similar breakdowns on your own in the future. We looked at why the faucet drips in the kitchen and what steps should be taken.

    What to do if the tap in the bathroom is leaking

    Types of shower and bath faucets:

    • valves;
    • swivel single lever;
    • ball;
    • shower faucet.

    For repair work, have on hand:

    • Phillips or straight screwdriver;
    • open end wrench set;
    • pipe wrench;
    • sealant tape;
    • repair kit (gaskets, crane box).
    • nine0107

      We repair the valve faucet

      This type of plumbing most often fails, but the repair cost will be lower due to the use of rubber seals for stuffing boxes and locking parts. Although experts recommend more effective silicone seals, this will not affect the service life.

      There are 2 types of valves:

      1. With worm box. The movable threaded stem during rotation acts on the hexagon, thereby sealing the junction of the gasket and the seat - there is a bottleneck here. The gasket will quickly fail if handled carelessly. The locking device is also not reliable, so when buying an axle box, purchase a repair kit for seals. nine0022
      2. With ceramic inserts. The stem is stationary. The box has 2 ceramic washers with semicircular cutouts.

      Specialists distinguish between the following failures of the faucet mixer. Let's consider them in detail.

      Fault #1. The valve does not block the flow, causing water to seep through the gooseneck. The reason is the wear of the seal on the crane box. To fix the problem, you need to buy seals (rubber or plastic). And it’s better to keep a repair kit in the house so as not to waste time buying when a breakdown occurs. Choose flexible rubber seals. Rigid products quickly become unusable. nine0003

      Important! Broken half-turn valves with ceramic inserts are not repaired and replaced!

      If the tap in the bathroom drips, what should I do? Procedure:

      1. The plug is unscrewed with a screwdriver.
      2. Use a Phillips screwdriver to remove the locking screw to remove the valve handle. nine0022
      3. Use a pipe wrench to unscrew the decorative barrel (usually nickel). In order not to scratch the nickel surface, wrap the keg with textile material and only then turn.
      4. Remove the bushing and evaluate the appearance of the gasket. Usually the problem lies in it. Also, the crane box itself often breaks.
      5. When assembling the assembly, wrap the threads with 4-5 layers of sealing tape to ensure a tight seal.

      Tip! After troubleshooting, supply water and check the connection for leaks. Why does the faucet drip when the water is turned off? Possibly a loose connection. Add a few layers of sealing tape and carefully tighten with a pipe wrench. The main thing is not to overdo it with the tightening force and the amount of sealing tape.

      Fault #2. A valve is leaking. We find the area where the liquid leaks. If the tightness or integrity of the thread is broken, the axle box is unscrewed, the worn seal is removed, new layers of fum-tape are wound, the knot is assembled and tightened. If a leak comes from the stem, the clamp nut is unscrewed, the seal is replaced (it is better to take a moistened linen cloth).

      Why water drips from the tap in the bathroom: defects in the single-lever valve

      These instruments are easy to use and maintain. In this case, the ceramic cartridge is replaced as it cannot be repaired.

      What to do if the faucet in the bathroom with a single-lever valve is leaking?

      Procedure:

      1. The decorative caps are removed.
      2. The screw securing the handle of the device that controls the cartridge is unscrewed.
      3. Unscrew the nut holding the cartridge.
      4. Cartridge replacement in progress (make sure cartridge and seat holes match). nine0022

      What to do if a ball valve leaks

      Ball valves are the second largest single lever valve in sales. They are characterized by reliability and durability. The service life depends on the quality and design of the parts. Plumbing performance is greatly affected by pollution and mechanical impurities contained in water.

      We recommend installing coarse and fine filters, which are metal meshes, in front of the locking device. They allow you to trap large solid and microscopic inclusions. nine0003

      How to fix a leaking ball valve

      Usually, threaded ball valves that are used on pipes in an apartment are not repaired. Their design consists of two halves of the body, which are pressed in at the factory with a special glue, so at home it will not be possible to achieve the desired tightness.

      Tip! If the ball valve drips, replace it. It is problematic to repair the device due to the high accuracy of fitting parts of the nodes. Moreover, replaceable balls and gaskets are not sold for ball valves. nine0059

      How to fix a leak in the gander-shower faucet

      The appearance of a gander-shower leak indicates the need to change the gasket and perform a number of manipulations:

      1. The water supply valves are closed.
      2. The lever is dismantled, which is fixed with a screw (sometimes the handle is simply unscrewed).
      3. The gasket is being replaced and the winding is updated with a fum tape.
      4. nine0019 The device is assembled in reverse order.
      5. Plumbing functionality tested for leaks.

      If water is leaking from the hose, there is only one way out - replacement.

      Conclusion

      Here are a few simple tips that can significantly extend the life of the product:

    • In case of intensive use of plumbing, we recommend inspection and maintenance every 3-6 months. nine0022
    • Due to poor water quality and the presence of mechanical impurities, install cleaning filters.
    • If you bought a new faucet and it leaks after installation, feel free to contact the seller and demand a refund or exchange of products. In our article, we looked at what to do if the faucet is dripping. We hope our information will be useful.

      See also the article " How to choose the right quality ball valve ".

      Toilet repair: instructions for those who are not plumbers at all

      March 22, 2020 Likbez Do it yourself

      This manual will help troubleshoot broken valves or buttons, water leaks and other problems.

      How the toilet is made

      The toilet consists of a toilet bowl, a cistern and a seat with a lid. The bowl serves as a base and is fixed to the floor with screws. It contains a siphon, which is connected through a cuff or a flexible corrugation to the sewer. The main function of the siphon is a quick flush due to the gravity of the flow and the pressure difference. This part is constantly filled with water and works as a water seal, preventing unpleasant odors from spreading. nine0003

      The flush cistern is either mounted on the bowl shelf in compact toilets or fixed to the wall in old style sanitary ware. From the side or from the bottom, the container is connected to the water supply with a flexible connection, which is connected to the filler fittings. The latter, in turn, is equipped with a float valve that controls the filling of the tank with water to the desired level.

      In the same place, inside, there is a drain valve responsible for draining water. It is to it that a button is attached through a special mechanism, with which we control the flush. To protect against overflow, the drain valve has an overflow pipe. Through it, in the event of a malfunction of the float valve, water flows into the toilet, and not onto the floor. nine0003

      Now reading 🔥

      • How to make a fence with your own hands

      How to disassemble the toilet for repair

      Most of the malfunctions are associated with the drain and fill mechanisms. To eliminate such breakdowns, you need to disassemble the tank. So let's first look at how it's done.

      How to remove the cover

      In older toilets with a plastic cistern, the lid is held on by snaps and removed by moving upwards. Sometimes you additionally have to pry its edges with a screwdriver or other sharp object.

      In today's compact toilets, the lid simply rests on the cistern and is fixed only by a button. Therefore, to remove the part, you must first unscrew the bezel of the button counterclockwise and remove it.

      In some toilet models, the push button mechanism is secured with a screw hidden inside. In this case, pry off the top of the button with a sharp knife or thin screwdriver, and then unscrew the screw and remove the button. nine0003

      There are also drains equipped with a stem with a handle that lifts up. To remove it, you need to lift the ball and unscrew it counterclockwise, holding it by the stem.

      How to remove the drain valve

      First, turn off the water at the inlet to the toilet bowl, and then grasp the flush mechanism with your hand and, turning it slightly counterclockwise until it clicks, lift it up. Sometimes there is a latch on the armature that needs to be pushed back before removing the mechanism. nine0003

      To replace the drain valve with fittings of a different design or manufacturer, the mechanism, including the seat, must be completely removed. To do this, remove the tank and unscrew the large nut from the bottom.

      The filling valve with side connection is very easy to remove. It is enough to remove the cover and disconnect the flexible hose, and then unscrew the fixing nut from the outside and pull out the mechanism.

      Bottom fitting is more difficult. First, remove the flexible hose and tank cap. Then wash off the water and remove the drain valve. Next, unscrew the nut with which the filling valve is attached from below, and take it out. If the water has not drained completely, it is better to substitute a basin or other container so as not to spill everything on the floor. nine0003

      How to remove the cistern

      In older toilets, it is plastic and can be removed quite simply. First, they shut off the water supply and wash off the residue, and then lift the lid and unscrew the screws that secure the tank to the wall. After that, unscrew the flexible hose and the nut of the drain socket at the bottom of the tank.

      On compact toilets, the tank is attached to the bowl shelf, so it is taken apart differently. The first step is to turn off the water and press the flush. Then remove the cover, remove the drain and fill fittings and remove the remaining water with a sponge or cloth. Next, a flexible eyeliner is unscrewed, as well as the fixing screws of the tank from the bottom of the toilet bowl. nine0003

      How to fix common breakdowns of toilet bowls

      Leak in the sewer socket

      If a puddle forms in the area of ​​​​the connection to the sewer socket or at the outlet of the toilet bowl itself, the cause lies in the drying of the cuff or a break in the flange of the flexible corrugated pipe. With a rigid connection on plastic pipes, there are practically no such problems.

      This is corrected by replacing the corrugation with a new one, while it is important to carefully install it without kinks and kinks. As a temporary solution, you can treat the joint around the pipe with silicone sealant, after wiping and drying this place. nine0003

      Water is not drawn into the tank

      There may be several reasons for such a problem, but they all boil down to the fact that there is some kind of barrier that prevents water from entering the tank. It is better to start the search with the simplest options and gradually move towards the more complex ones.

      The first step is to turn off the water and remove the flexible hose from the side or bottom of the toilet. If there is a blockage, clean it and check the pressure by opening the water and lowering the hose into a basin or other container. If the jet is good, the next step is to check the filter inside the supply valve. nine0003

      It has the appearance of a plastic mesh insert. You need to get the filter, clean it in the presence of dirt and rinse under the tap. Then the part is installed in place and checked if the situation has changed. It should be borne in mind that some valves may not have such a filter.

      If cleaning did not help, you need to remove the tank cap, remove the filling mechanism and, having unscrewed the valve nut, carefully examine the contamination under running water, clean the channel with a thin wire, remove deposits from the rubber membrane. After that, everything is assembled in the reverse order and installed in place. nine0003

      If water is still not drawn in, most likely the valve itself is faulty and will have to be replaced with a new one.

      Noisy filling

      Noisy filling is usually a problem with cisterns with side connection. Due to the design features, the valve is located on top and a jet of water, falling to the bottom of an empty tank, creates noise. To reduce it, special muffler tubes are installed at the valve outlet, reaching the bottom, along which the flow flows. nine0003

      Often such tubes fall off, and sometimes they are completely absent. Therefore, as a solution, you need to return them to their place or select and install new ones of a suitable diameter on the valve outlet. The length of the hose should reach the very bottom or even lie on it.

      Troubleshooting compact toilets

      Constant leakage into the toilet

      If water is constantly flowing into the bowl in a thin stream, then the fill or drain valve is not working. If the first one breaks down after filling the tank, the water does not shut off, but if the second one is faulty, the collected water is not retained by the valve. nine0003

      To determine which valve is not working, you need to press the drain and watch:

      • If there is no leakage during the intake of water, and a trickle appears after the tank is full, then the filling valve is faulty.
      • If water starts to flow immediately after pressing the flush button, the drain valve is the cause.

      In very rare cases, both mechanisms do not work at the same time. Also, overflow can occur due to improper setting of the filling valve - how to adjust it is described at the end of the article. nine0003

      What to do if the filling valve breaks down

      To eliminate the problem, you need to remove the reservoir cap and remove the filling mechanism. Next, you need to unscrew the valve nut and carefully remove the rubber membrane from it. From it, as well as from the valve seat, remove rust and scale deposits with a toothbrush, then rinse well with water. If the channel inside is clogged, clean it with a thin wire.

      In older tanks, remove the cap from the valve, pull out the rocker shaft and remove the problematic part. With a thin knitting needle or wire, you need to clean the channel, and then rinse with water. nine0003

      After cleaning and assembly, everything should work. If this does not happen, the diaphragm or the entire filling valve assembly will have to be replaced.

      Gaskets for this mechanism are rarely sold separately. Therefore, just try to turn the old one upside down: it will still serve for some time. Alternatively, you can sand it with sandpaper, and then stick a circle of bicycle inner tube or other thin rubber on top.

      What to do if the drain valve breaks down

      First of all, you need to turn off the water, drain the liquid from the tank and, removing the residue with a sponge or rag, remove the drain valve. Next, you need to remove the gasket and clean it from rust deposits. If possible, it is better to replace the gasket with a new one. nine0003

      If you can't find one, try flipping it upside down, or placing some kind of weight, like a large nut, on top of the valve to help the diaphragm press against the seat better. If all else fails, you will have to change the entire drain mechanism entirely.

      Reservoir not filling enough

      Sometimes fillers with a float inside the cup get stuck due to rust due to rust. This leads to the fact that when filling the tank, water enters the glass from below, and not overflowing over its edge. As a result, the valve closes ahead of time and the tank is not filled to the desired level. nine0003

      To solve the problem, turn off the water, flush out the residue and remove the filler mechanism. Next, remove the bracket and pull the plug valve out of the glass. Then it is necessary to clean the part and its seat from plaque, and also make sure that the plug fits well on the glass and moves freely.

      Leak from under the cistern

      Leakage from the bottom of the cistern can occur if the cone gaskets of the mounting bolts or the large rubber ring between the toilet bowl and the cistern have failed. nine0003

      In both cases, turn off the water and press the flush, and then remove the cover, remove the filling and drain fittings. After removing the remaining water, unscrew the mounting bolts and carefully inspect all seals for cracks.

      It is advisable to replace the gaskets with new ones. If you can’t find the same ones, you can thoroughly clean them, dry them and install them in place, having previously lubricated all joints with silicone sealant.

      Button sticking or sticking

      A problem with the flush button is usually caused by the fact that when fully pressed, the stem catches on the valve mechanism and jams. In this case, often replacing the button itself does not give anything. There are several solutions. nine0003

      The simplest thing is to unscrew the button, press it a little, sinking a couple of millimeters, and then put it back in place, holding it in this slightly pressed position. So the part looks a little recessed, but due to the reduced stroke it will not jam at the extreme point.

      For the same purpose, you can cut a ring 2–3 mm high from a plastic bottle cap and place it under the button. To do this, use a screwdriver to press the latches on the sides of the mechanism and pull the button out of the case. nine0003

      How to fix broken toilets with a plastic cistern

      Leak on the cuff of the drain pipe

      The rubber cuff that connects the cistern pipe to the toilet outlet dries out over time, loses its elasticity and starts to leak. Toilet repair in this case consists in replacing the problematic part. First you need to turn off the water and rinse.

      If a new part cannot be found, a 50/40 mm rubber reduction can be installed instead. Unlike the cuff, it is inserted inside the toilet bowl, and is not put on top of it. Otherwise, there is no difference, and this will not affect the operation of the mechanism in any way. nine0003

      As a temporary solution, you can carefully remove the old cuff, clean and dry it, and then install it, treating the joints with silicone sealant.

      Tank nut leak

      Water is leaking from the drain pipe nut due to a gasket installed inside the tank. Often it is cut by burrs from casting defects on the nozzle or shifted to the side when twisting. Also, the membrane itself may be of poor quality.

      To eliminate the defect, turn off the tap at the inlet to the tank, rinse off the water and remove the drain valve, first unscrewing the decorative nut on the socket, and then the clamping nut. Next, you need to clean the burrs with a sharp knife along the entire plane of the gasket and assemble everything in the reverse order, securely holding the pipe with your hand when tightening the nut. nine0003

      If this does not help, the gasket itself is most likely of poor quality. In this case, you need to cut a new one from a suitable piece of rubber 2–2.5 mm thick, using the old part as a template or tracing the nozzle with a pencil.

      Drain pipe joint leak

      Water leakage at the junction of the nozzle and drain occurs due to poor fit or deformation of the cone gasket. And it needs to be replaced with a new one. If such a gasket is not at hand, you can temporarily seal the joint with FUM tape. nine0003

      To do this, turn off the water supply to the tank and empty it. Next, unscrew the decorative nut, slide the cone gasket down a little and wind three or four turns of the FUM tape into the resulting gap. Then the gasket must be lifted up, tighten the wound tape, and then tighten the decorative nut, holding the pipe with your hand so that it does not turn.


      How to adjust the toilet fittings

      The flush and fill valves must be properly adjusted for the toilet to work properly. Otherwise, flushing will be poor, due to the fact that the tank is not filled enough or the water does not drain properly. nine0003

      How to adjust the filling mechanism of the compact toilet bowl

      In valves with a float inside the cup, it is necessary to remove the lid of the tank, shut off and drain the water. After pressing the glass latch, you should set it at such a height that the upper edge of the part corresponds to the mark on the overflow pipe (usually about 2 centimeters from its top). Then snap off the adjusting rod, lower the float to the bottom of the cup, make sure the bracket rests on the bottom, and then click the rod to fix the position of the float. nine0003

      In mechanisms without a glass, everything is much simpler. The height of the float and, accordingly, the amount of water in the tank is adjusted by twisting and unscrewing a long threaded pin. The higher the float, the more water is collected, the lower - the less.

      How to adjust the flush mechanism of the compact toilet bowl

      To adjust, unscrew the button, remove the cover and remove the drain valve, having previously flushed the water and turned off the tap at the inlet. Next, you need to return the lid to its place and measure the distance from its top to the bottom of the tank with a tape measure. nine0003

      Remove the cap again and replace the drain valve. Then tighten the button, release the rod lock and adjust the height of the mechanism so that the distance to the bottom of the button corresponds to the previously measured one. The missing millimeters are easy to catch due to the thread of the button, without wrapping it all the way.

      The next step is to set the frame of the mechanism at an angle downwards and fix it in this position with the rod lock. At the same time, the button moves freely in the guides, and the pusher does not raise the frame so that the valve does not open slightly. nine0003

      In the neutral position, the drain valve is closed and should fully rise when the button is pressed. If the adjusting rod rests against the bottom of the tank, it should be cut off.

      Finally, it is important to make sure that the frame of the mechanism does not hit the overflow tube when the button is pressed. If this happens, you need to remove the mechanism and lower the frame below. To do this, unscrew the nut, carefully slide the ring gasket and, sinking the tube a few millimeters, tighten the nut.

      How to adjust the float valve of the old tank

      In older toilets with a plastic cistern, the water level can be easily adjusted. If it is a wire rocker, it is enough to bend it to raise or lower the valve to the desired height. In more modern versions with a plastic hinge, it is necessary to loosen the screw connecting the two halves of the rocker and give it one shape or another.


      Learn more
