SKU: POLATV
$661.85
Free Shipping
(No reviews yet) Write a Review
Rating Required Select Rating1 star (worst)2 stars3 stars (average)4 stars5 stars (best)
Name
Email Required
Review Subject Required
Comments Required
Select Plow Blade: Required Choose Options48" Straight Blade [105048]54" Straight Blade [105054] Adds $2760" Straight Blade [105060] Adds $61
Select Plow Mount by Model: Required Choose OptionsACE 500 '17-19 [105630]ACE 570 900 '14-19 [105630]ACE 900 SP 2016 [105630]ACE 900 XC '17-19 [105630]ATP 330, 500 '04-05 [106020]Magnum 330 4x4 '03-06 [105080]Scrambler 850 '13-16 [105075]Scrambler 1000 '14-16 [105075]Sportsman ETX '15 [106020]Sportsman 300 '08-10 [105745]Sportsman 400 '01-05 [106020]Sportsman 400 '11-14 [106020]Sportsman 450 '06-07 [106020]Sportsman 450 '16-22 [106020]Sportsman 500 '96-13 [106020]Sportsman 500 '11-13 [106020]Sportsman 550 '09-14 [105075]Sportsman 550 Touring '10-14 [105075]Sportsman 550 X2 '10-14 [105075]Sportsman 570 / SP '14-20 [106020]Sportsman 570 SP '15-20 [106020]Sportsman 570 Touring '14-20 [106020]Sportsman X2 '15-19 [106020]Sportsman 600 '03-05 [106020]Sportsman 700 '02-08 [106020]Sportsman 800 '05-14 [106020]Sportsman 850 '09-22 [105075]Sportsman 850 Touring '10-22 [105075]Sportsman 850 X2 '10-11 [105075]Sportsman 1000 '15-16 [105075]Sportsman 1000 Touring '15-21 [105075]
Select Winch Mount by Model:
Required
Choose OptionsNo, Thank youATP 330, 500 '04-05 [100430] $54. 95Magnum 330 4x4 '03-06 [100430] $54.95Scrambler 850 XP '13-19 [101740] $54.95Scrambler 1000 '14-16 [101740] $54.95Sportsman 300 '08-10 [100590] $54.95Sportsman 400 '01-03 [100430] 56.95Sportsman 400 2004 [100650] $54.95Sportsman 400 '11-14 [101740] $54.95Sportsman 450 '06-07 [100440] $54.95Sportsman 450 '16-21 [101840] $54.95Sportsman 500 '96-03 [100430] $54.95Sportsman 500 '08-10 [100440] $54.95Sportsman 500 '11-13 [101840] $54.95Sportsman 550 '10-14 [101840] $54.95Sportsman 550 Touring '10-14 [101840] $54.95Sportsman 550 X2 '07-09 [101840] $54.95Sportsman 570 '14-20 [101840] $54.95Sportsman 700 '05-06 [100440] $54.95Sportsman 800 '11-14 [101740] $54.95Sportsman 850 Touring 10-20 [101840] $54.95Sportsman XP 1000 '15-20 [101840] $54.95Sportsman 1000 Touring '15-20 [101740] $54.95
Select Winch:
Required
Choose OptionsNo, Thank youKFI 2000 ATV Series Steel Cable Winch [A2000] $208.00KFI 2500 ATV Series [A2500-R2] $229.
00KFI 3000 ATV Series [A3000] $272.00All Balls 3500lb Synthetic Rope Winch [431-01024] $324.95
Push Tubes: Required Push Tubes [SKU# 105000]
Shipping Notice: Required Additional Shipping Required for Alaska, Hawaii, and California. We will contact you for shipping cost and approval.
Current Stock:
Quantity:
Call Us For
More Questions
Like it? Share it!
NOTE: We Can Not ship plow kits to California
Each year when winter comes around, the issue of moving snow efficiently presents itself.
For years when the snowfall requires better tools than shovels and snow blowers, the Polaris ATV snow plow kit can step in for reinforcement. This kit includes your choice of everything you need, including plow style, size, plow mount, and push tubes. Browse our snow plow options and accessories to find the right fit for your ATV at West End Motorsports.
Built Tough and Built to Last
When you choose the Polaris ATV plow kit, you’ll have a strong, resilient, and durable means of moving snow. Our snow plow packages for Polaris ATV models are available in different options, suited to handle the toughest conditions such as snow, sand, and ice. The Polaris ATV snow plow kit ships as a complete package, and features convenient attachment technology for easy installation and removal.
Important: Do not choose too large of a blade for your Polaris snow plow as you may lack the horsepower needed for heavier snowfall. You will also need a winch to ensure plow operation.
We offer different winch options to meet your needs.
About the Plow Blades:
About the Plow Mounts:
About the Plow Base Push Tube System:
S.A.About Optional Winches and Mounts:
Recommend Plow Lengths based on Engine Size
| 350cc - 400cc | 48 inch - 54 inch plow length |
| 400cc - 499cc | 48 inch - 54 inch plow length |
| 500cc - 599cc | 54 inch - 60 inch plow length |
| 600cc and Up | 60 inch plow length |
Winch Recommendations
Good for plow operationOrder Online Now
If you’re looking for a premium-quality snow plow, get the Polaris ATV snow plow package at West End Motorsports. We offer free shipping on all orders over $99 plus guaranteed fitment. Contact us for help with placing your order.
KFI ATV Plow Mount Application Chart
ATV Mid-Mount Plow Mount:
NOTE: Mounts listed below will use the #105000 ATV push tubes.
| Polaris ATV's | Year | Model Specific Mount | Universal Mount | Hybrid System |
|---|---|---|---|---|
| 350 2x4 / 4x4 / 6x6 | '93-Older | 105190 | N/D | N/D |
| 400 2x4 / 4x4 | '94-97 | 105190 | N/D | N/D |
| 445 Diesel | 1999 | 106020 or 105080 | N/D | N/D |
| ACE 325 | ‘14-16 | 105630 | N/D | N/A |
| ACE 500 | ‘17-19 | 105630 | N/D | N/A |
| ACE 570 / SP | ‘15-19 | 105630 | N/D | N/A |
| ACE 900 SP | 2016 | 105630 | N/D | N/A |
| ACE 900 XC | ‘17-19 | 105630 | N/D | N/A |
| ATP 330 | ‘04-05 | 106020 or 105080 | N/D | N/D |
| ATP 500 | ‘04-05 | 106020 or 105080 | N/D | N/D |
| Big Boss 6x6 400L | 1995 | 105190 | N/D | N/D |
| Hawkeye 300 | '06-08 | N/A | 105745 | N/D |
| Magnum 330 4x4 | ‘03-06 | 106020 or 105080 | N/D | N/D |
| Magnum 425 4x4 / 4x6 | '98-Older | 105190 | N/D | N/D |
| Magnum 500 4x4 | 2002 | 106020 or 105080 | N/D | N/D |
| Scrambler 400 | '98-99 | N/D | N/D | Yes |
| Scrambler 850 | ‘13-22 | 105075 | 105745 | Yes |
| Scrambler 1000 | ‘14-18 | 105075 | 105745 | Yes |
| Scrambler 1000 XP S | '20-22 | 106185 | N/A | N/D |
| Sportsman 300 | ‘06-08 | N/A | 105745 | N/D |
| Sportsman 335 | '00-Older | 106020 or 105080 | N/D | N/D |
| Sportsman 400 | ‘01-05 | 106020 or 105080 | N/D | Yes |
| Sportsman 400 (Hawkeye) | '08-10 | N/D | 105745 | N/D |
| Sportsman 400 | ‘11-14 | 106020 or 105080 | N/D | Yes |
| Sportsman 450 | ‘06-07 | 106020 or 105080 | N/D | N/D |
| Sportsman 450 | ‘16-22 | 106020 or 105080 | N/A | N/A |
| Sportsman 500 | ‘96-13 | 106020 or 105080 | N/A | Yes |
| Sportsman 500 Touring | '08-13 | N/A | N/D | Yes |
| Sportsman 500 X2 | '06-09 | N/A | N/D | Yes |
| Sportsman 550 | '09-14 | 105075 | 105745 | Yes |
| Sportsman 550 Touring | '10-14 | 105075 | 105745 | Yes |
| Sportsman 550 X2 | '10-14 | 105075 | 105745 | Yes |
| Sportsman 570 | '14-22 | 106020 or 105080 | N/D | N/A |
| Sportsman 570 SP | '15-18 | 106020 or 105080 | N/D | N/D |
| Sportsman 570 Touring | '14-22 | 106020 or 105080 | N/A | N/D |
| Sportsman 570 X2 | '15-22 | 106020 or 105080 | N/D | N/D |
| Sportsman 600 | '03-05 | 106020 or 105080 | N/D | N/D |
| Sportsman 700 | '02-08 | 106020 or 105080 | N/D | N/D |
| Sportsman 700 X2 | 2008 | N/A | N/D | Yes |
| Sportsman 800 | '05-14 | 106020 or 105080 | N/D | Yes |
| Sportsman 800 Touring | '08-09 | N/A | N/D | Yes |
| Sportsman 800 X2 | '07-09 | N/A | N/D | Yes |
| Sportsman 850 | '09-22 | 105075 | 105745 | Yes |
| Sportsman 850 Touring | '10-22 | 105075 | 105745 | Yes |
| Sportsman 850 X2 | '10-11 | 105075 | 105745 | Yes |
| 1000 Sportsman | '15-22 | 105075 | 105745 | Yes |
| 1000 Sportsman Touring | '15-22 | 105075 | 105745 | Yes |
| 1000 Sportsman XP S | '20-22 | 106185 | N/A | N/D |
| Sportsman ETX (Hawkeye) | 2015 | 106020 or 105080 | N/D | N/D |
| Sportsman 570 6x6 | '17-22 | 106020 or 105080 | N/D | N/D |
| Trail Boss 2x4 | '88-99 | 105190 | N/D | N/D |
No products found.
This mini tractor implement is used for plowing. Since the design of the model is quite simple, many craftsmen make homemade units at home. Below you will learn not only how to set up a plow for a mini tractor and make parts and assemble it yourself.
During the cultivation of the land, single-furrow, double-furrow and three-furrow plows are installed. The installation of certain units depends on the power of the engine, the properties of the soil. The bottom line is that the entire mass is entirely superimposed on the hitch. In design, there are three types of plows.
Disc structures. Mainly used for plowing virgin and heavy soils. The working bodies are disks on bearings. This solution is used in weedy and wet fields. Plowing depth up to 25 cm.
negotiable. Shares act as working elements. During plowing, the soil is cut and turned over.
In this case, the fertile layer is crushed. The plowing depth is adjusted by installing the support wheels of the unit.
Rotary. This is modern equipment, when several shares are installed in one rotating shaft. The units are used immediately before sowing.
Consider in more detail, how to make a plow for a minitractor .
A share-dump or reversible plow is the simplest option, so the first test of development and assembly should begin with it.
How to make a plow for a mini tractor with your own hands? First you need to make the frame itself, for which you need a thick-walled pipe, a corner.
Don't forget to take into account the installation of the support wheel in the design even at the drawing stage. After that, the middle of the structure on the frame is calculated, where the cross member and eyelets for the drawbar are welded.
The next step in the assembly is to fix the post. To install it, two holes are drilled at the edges of the pipe, which will serve to fasten the handles, which will also be made from the pipe. The pipe is rolled out from two edges, one of which is fixed on the frame, and the other is used as a holder. Additionally, a cross member is welded in the middle of the structure.
The plowshare can be made from tool or disc steel 3-5 mm thick. The opener is made of the same steel, then bent at an angle of 80 about . All elements of the plow are welded into a single unit. The plowshare is installed at an angle, which, in relation to the overall design, is calculated independently or the parameters are taken from the forums. Motokosmos experts advise setting the angle in this case to about 150 about .
After that, a moldboard is made. To do this, choose a steel sheet of 2 mm. The dump is connected to the coulter using hinged elements. As a connecting element, you can take the most common steel door hinges.
To maintain a certain angle, spacers are installed, which also help to adjust the angle of the blade.
Finally, with the edges of the crossbar, fix the rods for connecting with the tractor. Note that the assembled home-made design is no worse than factory counterparts. Let's take a closer look at how to properly install the plow on a mini-tractor .
It doesn't matter if you use a purchased or homemade analogue, the setting of the machine is always the same. How to correctly set the plow on the minitractor so that the unit does not fail? The setting is carried out as follows:
The general integrity of all structural elements is checked. All moving parts are lubricated.
The plowing depth is also adjustable using the adjustment bolt. If it is tightened, the plowshare enters deeper into the ground; if it is untwisted, the plowing depth decreases.
The height of the frame posts is also checked.
The end bars must be adjusted and are at the same level.
Set the width of the grip, with a change in the length of the rod, the transverse shaft. The longer the draft is set, the wider the grip of the plow.
Mounting pin is vertical to the ground. During operation, the supporting chassis must follow the previous furrow.
Thus, you get a versatile machine that can work the land before sowing any crop.
Polaris Sportsman is the best selling ATV in the world. It has been produced for more than a quarter of a century: the line appeared back in 1996. "Sportsmen" are produced in several versions: from the most affordable 450 cc models to powerful liter ones, and each volume has several modifications.
570cc Sportsmans traditionally have the most. For example, in 2022, as many as 8 modifications are available in this volume. The most expensive and interesting is the Ride Command Limited Edition, a 44-horsepower single ATV with EPS and extended equipment.
And how exactly this version differs from the rest of the 570 cc "Sportsmen" - we will tell in the article.
Click to enlarge this and all the following photos
The ground clearance of the LE is the same as the rest of the Sportsman 570: 29 cm. However, there is an important difference: the suspension arms of this version are curved, not straight. Thanks to this, riding where there is a risk of running into a stump or bump will be a little calmer.
Before 2022, the Ride Command system was not fitted to the Sportsman. And this year, only two models received it: the hero of our review and the Sportsman XP 1000 Ride Command Edition.
Ride Command is a 7" waterproof touchscreen display with off-road oriented navigation app. It allows you to plot routes, transfer waypoints from your smartphone via Bluetooth, track the position of your group members (if they also have Ride Command).
In addition to purely navigational functions, Ride Command has other features - with its help you can:0005
The system can be used with gloves. In general, this is an indispensable thing for off-road - both convenient and useful. In Sportsman, it is mounted on the steering column at the top.
7 out of 8 Sportsman 570 modifications received these bumpers, except for the basic one (570 EPS). The design is made to last and looks impressive: it protrudes forward, has a pair of transverse elements, and most importantly, it completely protects the headlights, as it closes them around the perimeter. Thanks to this, they will not break, even if you run into something hard and durable (for example, a thick branch when driving through bushes) - the bumper will protect the glass.
The base Sportsman is equipped with halogen headlights and a lamp on the steering column. The Ride Command LE version has much more durable LED bulbs instead of halogens.
Not all Sportsman 570s come standard with an electric winch. But the most expensive and most complete version, of course, has it - synthetic, for 1587 kg.
If you want to use the Sportsman in agriculture, you can buy a plow. There is already a place to install it. What's more, the touch screen will allow you to control the plow by raising and lowering it.
Instead of 25-inch rubber, the model received larger tires: 26-inch 6-ply Duro Powergrip radial ply. This is a worthy analogue of the legendary (but also more expensive) Maxxis Bighorn, which has proven itself well off-road.
Tire rims, by the way, are also different: lighter aluminum instead of basic steel.
