Suzuki Cycles - 2022 KingQuad 400FSi

2022 KingQuad 400FSi Overview

In 1983, Suzuki introduced the world's first 4-wheel ATV. Today, Suzuki ATVs are everywhere. From the most remote areas to the most everyday tasks, you'll find the KingQuad powering a rider onward. Across the board, our KingQuad lineup is an exceptional group of ATVs.

The 2022 Suzuki KingQuad 400FSi features a five-speed manual-shift transmission and semi-automatic clutch for those who favor a bit sportier performance. It cranks out an impressive amount of torque and has an incredibly wide powerband for exceptional performance on the trail or on the job. A...

Find a Dealer

Gallery

There was an error loading these images. please try again later!

Terra Green

Loading. ..

Features

Powerful, fuel-injected, 4-stroke engine is easy on gas

Durable manual transmission with semi-automatic clutch

Select 2WD or 4WD via a handlebar-mounted lever

Large fuel tank and plush seat delivers extended, comfortable riding range

Rugged bodywork and full racks to tackle any task


The KingQuad 400FSi’s fuel-injected, 376cc, four-stroke, four-valve engine produces efficient power and driveablity.

Suzuki's class-leading fuel injection smooth’s power output, especially in the mid-to-high range, and provides excellent cold starting. The system uses 3-D maps for optimum ignition, creating responsive yet environmentally compliant performance.

Suzuki Advanced Cooling System (SACS) uses an oil cooler and thermostat-controlled cooling fan to shed engine heat during hard work or cargo hauling.

Push-button electric starting has a start-in-gear function—when the rear brake is applied—allowing starting without shifting to neutral (as conditions permit).

The Engine Control Unit (ECU) has slip control logic, which adjusts fuel injector duration and timing to improve drivability and grip in loose/slippery conditions.

Highly efficient iridium spark plug contributes to better combustion, cleaner emissions and longer plug life. Engine starting under low temperature is also improved.

Pulsed-secondary AIR-injection (PAIR) system and catalyst-equipped exhaust system help the ATV comply with Environmental Protection Agency (EPA) emission standards while maintaining a high level of performance.


Five-speed transmission with semi-automatic clutch with reverse allows the rider to select the ideal gear for maximum traction and fuel efficiency.

Select 2WD or 4WD with the flip of a handlebar-mounted lever. The shaft drive system is reliable and durable and is nearly maintenance-free.

Torque-sensing limited-slip front differential provides maximum traction and light steering when in 4WD mode.

High/low selectable sub-transmission provides wide-ranging versatility.

Automotive gate-type gearshift lever lets you conveniently choose high or low range, neutral or reverse.

The ECU has a Reverse Mode that monitors vehicle speed, so higher engine rpm can be used when getting out of mud or loose soil in reverse mode.


Sporty bodywork features sharply angled, high-clearance fenders.

Suzuki's exclusive T-shaped seat delivers rider mobility during sport riding or tackling difficult terrain. It’s also plush for extended riding comfort.

Overall length is under 82 inches (208 cm), so the KingQuad fits into a 6.5-foot truck bed for easy transportation.

Independent front A-arm suspension offers smooth performance and remarkable ground clearance with 6.7 inches (170.1 mm) of wheel travel.

A swing-arm rear suspension with 6. 7 inches (170.1 mm) of wheel travel and twin shock absorbers provides agile handling and plush riding.

Dual front hydraulic disc brakes feature calipers with large, 34mm pistons and wide brake-pad surface area for increased stopping power and outstanding durability.

Large, 25-inch Carlisle tires with aggressive tread offer consistent traction in wet conditions, yet make for a quiet, smooth ride on hard-packed trails.

The tires are mounted to rugged steel wheels powder-coated with a durable matte black finish.

Lightweight and strong plastic skid plates are sturdy to withstand trail pounding, yet slippery to let obstacles slide below.


Dual 35-watt headlights (with high and low settings) are part of the distinctive KingQuad grille appearance. Bright tail light helps make the ATV visible in dark conditions.

Heavy-duty front and rear cargo racks let you take advantage of the ATV’s superb load capabilities. Wrinkle paint finish on the racks and front bumper is durable and scratch resistant.

LCD instrumentation includes speedometer, odometer, trip meter, hour meter, clock, fuel gauge, and indicators for reverse, neutral, oil and FI (fuel injection).

Automotive-style DC power outlet is included on front fender.

Winch-ready mounts and wire conduit makes winch installation simple.

Large, 4.2 gallon (16.0 L) fuel tank provides outstanding riding range.

Full floorboards with integrated raised footpegs provide protection.


12-month limited warranty. Longer coverage periods with other benefits available through Suzuki Extended Protection (SEP).*

*Subject to separate coverage for certain parts and the exclusions and limitations described in the New ATV Limited Warranty.

A variety of Suzuki Genuine Accessories are available, including winches, windshield, front and rear bumpers, snowplow, aluminum skid pans, rack extensions, utility box, and more.

Minimum Operator Age: 16 Years Old

This model is not eligible for sale in California per California Air Resource Board (CARB) regulations.


Specifications

  • Engine
  • Drivetrain
  • Chassis
  • Electrical
  • Dimensions
  • Warranty
  • Engine376cc (22. 94 cubic in.), 4-stroke, air-cooled with SCAS, OHC single cylinder
  • Bore x Stroke82.0 x 71.2 mm (3.228 in. x 2.803 in.)
  • Compression Ratio9.0:1
  • Fuel SystemSuzuki electronic fuel injection
  • StarterElectric
  • LubricationWet sump
  • Transmission5-speed forward constant mesh, with high/low range and reverse
  • ClutchDry shoe, automatic, centrifugal type
  • Driven Wheels2WD and 4WD
  • Final DriveShaft drive
  • Suspension FrontIndependent, double wishbone, coil spring, oil damped
  • Suspension RearSwingarm type, coil spring, oil damped
  • Brakes FrontDisc brakes, twin rotors
  • Brakes RearSingle drum brake
  • Tires FrontAT25 x 8-12, tubeless type x 2
  • Tires RearAT25 x 10-12, tubeless type x 2
  • Fuel Tank Capacity16. 0 L (4.2 US gal.)
  • ColorTerra Green or Flame Red
  • IgnitionElectronic ignition (transistorized)
  • Headlight12V 35/35W (HS1) × 2
  • Tail Light12V 21/5W
  • Overall Length2060 mm (81. 1 in.)
  • Overall Width1145 mm (45.1 in.)
  • Overall Height1220 mm (48.0 in.)
  • Wheelbase1270 mm (50.0 in.)
  • Ground Clearance250 mm (9.8 in.)
  • Seat Height840 mm (33. 1 in.)
  • Curb Weight279 kg (615 lb.)
  • Warranty12-month limited warranty
  • ExtensionLonger coverage periods with other benefits are available through Suzuki Extended Protection (SEP)

Financing

Get Pre-Approved

Price Base MSRP*

Down Payment

Trade-in Value

Interest Rate (APR)**

Term

24 Months36 Months48 Months60 Months72 Months84 Months

Estimated Payment

*Manufacturer’s Suggested Retail Price (also referred to as “MSRP”, “Base MSRP” or the “Starting At” price), excludes taxes, title, license and registration fees, destination freight and delivery charges, dealer fees, and optional equipment.

**Payments are estimates only and subject to actual available finance rates which customer may qualify for on a given model. Not all buyers will qualify. Approved rates and terms will be based on credit worthiness. For current available rates, please visit our offers page.

†Freight surcharge is effective on certain MY22 and MY23 models shipped on or after March 1, 2022. See dealer for details.



Get A Quote

Tell us your ZIP code

Enter a valid 5-digit ZIP code

No dealers within range!

Loading...

Here are dealers near "" Select Your Dealer

Suzuki Cycles - 2022 QuadSport Z90

2022 QuadSport Z90 Overview

The 2022 Suzuki QuadSport Z90 is the ideal ATV for adult-supervised riders ages 12 and older to develop their skills. Convenient features like an automatic transmission and electric starter help make this ATV suitable for supervised riders ages 12 and up. An easy-to-set throttle limiter lets adults set the power level appropriately for young riders, and a keyed ignition switch makes sure there are no unauthorized journeys. Get your little ones started on the QuadSport Z90, so your whole family can experience the fun of the outdoors and the joy of riding a Suzuki!

Find a Dealer

Gallery

There was an error loading these images. please try again later!

Champion Yellow No. 2

Loading. ..

Features

Designed for adult-supervised riders ages 12 and older

Adjustable throttle limiter controls speed

Easy electric starting, plus back-up recoil starter

Smooth-running CVT automatic transmission

Competition-inspired styling with new yellow bodywork


Compact, 90cc, four-stroke, single cylinder, air-cooled engine has been designed for durability and low maintenance.

Suzuki Composite Electrochemical Material (SCEM) cylinder, derived from Suzuki's high-performance, GSX-R sportbikes, provides durability, weight reduction and superior heat dissipation.

Smooth running, multi-plate cam chain lets the engine operate quietly. Easy-access oil filter and oil strainer cap reduces service time.

Clean-burning four-stroke engine easily achieves Environmental Protection Agency (EPA) emissions regulations (eligible for red sticker registration in California).

The 2022 QuadSport Z90 is eligible for California Green Sticker Off-Road registration.

Spark-arrestor equipped muffler is environmentally friendly, yet has a pleasant exhaust note.

Large 1.6-gallon (6.0-liter) fuel tank provies long riding time. A vacuum-operated fuel petcock automatically stops fuel flow when the engine’s not running.

A keyed ignition switch lets grown-ups decide when the action begins and ends.

Simple, screw-type throttle limiter allows adult supervisors to limit the maximum power delivery to suit the rider's ability.

Speed-limiter collar in the automatic clutch limits top speed to 15 mph. It can be removed to increase top speed as the rider gains ability.

Includes an easy electric starting system plus a standard back-up recoil starter.

Smooth-running CVT automatic transmission provides easy operation and allows the rider to focus on riding instead of shifting.


Child-size (Y-12) controls for easy operation.

Single A-arm front suspension with twin, independent shock absorbers and single-shock rear suspension provide long wheel travel for a smooth, comfortable ride.

Rear axle shaft has double oil seals for performance and reliability.

Headlamp style front piece is detachable to achieve the sporty look of the QuadSport Z400.

Modern styling with full floorboards creates a big Quad look that also features new yellow bodywork with coordinated graphics.

Front, side, and rear reflectors improve the ATV’s visibility to other riders.

Large-diameter, semi-sealed front drum brakes and single fully sealed rear drum brake provide strong braking performance.

One-piece, eight-inch wheels with tubeless tires provide a smooth comfortable ride.

Strong, high-rigidity steel frame is sturdy and compact.

The low seat height of just 25.6 inches makes it easy for the rider to get on and operate the ATV.

Suzuki T-shaped seat design is similar to the QuadSport Z400’s for smooth weight transition and a comfortable ride. The seat is easy to remove for service.

Easy to remove for service, the seat has a durable black cover that complements the ATV’s graphics package.

Competition-inspired bodywork features Champion Yellow bodywork with blue, black, and red graphics.


12-month limited warranty is double the length of most other youth ATV warranties. Longer coverage periods with other benefits available through Suzuki Extended Protection (SEP).*

*Subject to separate coverage for certain parts and the exclusions and limitations described in the New ATV Limited Warranty.

A variety of Genuine Suzuki Accessories for QuadSport owners are available, including a large selection of Suzuki logo apparel.

Minimum age: 12 years old.

ATVs are not toys. Serious injury or death can result from improper use of ATVs. Your youngster’s safety will depend on you taking a "Safety First" approach to ATV riding. The QuadSport Z90 may be used only by those aged 12 and older. Always supervise riders under the age of 16. All other Suzuki ATVs may be used only by those aged 16 and older. Even though your child may be the right age, you need to be sure that he or she has the size, strength, skills, and judgment to operate the ATV safely. The SVIA publication "Parents, Youngsters & ATVs" (included with products and available through your dealer) contains guidelines that can help you determine if your child is ready to ride an ATV.


Specifications

  • Engine
  • Drivetrain
  • Chassis
  • Electrical
  • Dimensions
  • Warranty
  • Engine90cc, 4-stroke, air-cooled, single cylinder, OHC
  • Bore x Stroke45. 5 mm x 55.2 mm (1.791 in. x 2.173 in.)
  • Compression Ratio9.5:1
  • Fuel SystemMikuni VM16, single carburetor
  • StarterElectric and back-up recoil
  • LubricationWet sump
  • TransmissionCVT automatic
  • ClutchDry shoe, automatic, centrifugal type
  • Driven Wheels2WD
  • Final DriveChain, RK530, 60 links
  • Suspension FrontIndependent, swing axle, coil spring, oil damped
  • Suspension RearSwingarm type, coil spring, oil damped
  • Brakes FrontTwin drum brakes
  • Brakes RearSingle drum brake
  • Tires FrontAT19 × 7-8, tubeless type x 2
  • Tires RearAT19 × 7-8, tubeless type x 2
  • Fuel Tank Capacity1. 6 US gal. (6.0 L)
  • ColorChampion Yellow No. 2
  • IgnitionElectronic ignition (CDI)
  • HeadlightN/A
  • Tail LightN/A
  • Overall Length1505 mm (59. 3 in.)
  • Overall Width875 mm (34.4 in.)
  • Overall Height915 mm (36.0 in.)
  • Wheelbase1005 mm (39.6 in.)
  • Ground Clearance150 mm (5.9 in.)
  • Seat Height650 mm (25. 6 in.)
  • Curb Weight127 kg (280 lb.)
  • Warranty12-month limited warranty
  • ExtensionLonger coverage periods with other benefits are available through Suzuki Extended Protection (SEP)
