Wheel lock rings

Drive wheels are located on one side of the bogie and are structurally distinguished by the presence of a ring gear that receives torque from the gear on the shaft of the travel motor. The gear is located exactly in the middle between the two drive wheels and engages simultaneously with both of them. Thus, the driving wheels are part of the open and dry running gearbox of the hoist.

The driven wheels simply support the trolley and the hoist from the other side, without being involved in the operation of the gearbox. All four running wheels are compactly located within the frame, consisting of the sidewalls of the hoist trolley. The sidewalls, in turn, are pulled together with studs. nine0003

The running wheels are mounted on axles located on the inside of the sidewalls. Ball bearings are used to reduce friction between the wheel mounting hole surface and the axle surface. And for precise positioning of the wheels, special spacers and locking rings are used.

The alignment and distance between the drive and driven wheels is of great importance, because if the wheels are too far apart, the working surface of the wheels will not be fully used and the hoist may fall. If the wheels are too close to each other, then they can pinch the monorail, and the hoist will not be able to move at all. nine0003

Since Bulgarian hoists can have different carrying capacities, the load taken by the undercarriage and wheels can also vary widely. For this reason, the dimensions of the running wheels can also vary. The exact dimensions and catalog numbers of the required driving and driven wheels should be specified in the table, referring to the brand and load capacity of the hoist.

For more information about the product and prices, please call tel. (343)352-44-24, 379-54-23

Hoist limit switches ensure that the drive is switched off in its extreme operating positions. As part of the Bulgarian hoists, the lift drive is equipped with limit switches.

As part of the lifting drive of the Bulgarian hoist, the limit switch is located in a closed terminal box on the motor housing. Structurally, this switch consists of two or three pairs of contacts in a common housing, switched using a rigid lever. nine0003

We always have limit switches: KI-G11, KI-G1.

The hoist limit switch lever is actuated by a special rod located along the drum. The rod carries a pair of crackers, which are pressed by the rope layer during its movement. By moving the crackers along the rod, the operation of the limit switch is adjusted and the extreme positions of the hook suspension are fixed.

Adjustment of the hoist lifting drive begins precisely with adjusting the position of the crackers and setting the lifting and lowering switch. This work must be carried out very carefully, since any mistake can lead to serious damage to the hoist or its load rope. nine0003

Purpose and safety

If you do not turn off the lifting drive in the uppermost position, then during operation, situations will systematically arise when the hook suspension hits the hoist body during lifting.

This situation is considered an emergency because it is fraught with the following consequences:

• damage to body and hoist hook block;
• damage and / or breakage of the cargo rope, as well as the fall of the load; nine0083
• failure of the rope layer.

Excessive descent of the hook suspension also does not bode well: a loose hoist rope falls off the drum grooves and from the clip block. Subsequently, when tensioned, the rope does not fall into the streams, the rope layer breaks off, is clamped between the cheeks of the hook clip and is damaged. In addition, a situation is possible when a fully unwound rope begins to wind onto the drum from the other side with a crease at the attachment point. All of the above leads to the failure of the rope and damage to the body of the hoist and hook suspension. nine0003

Thus, the hoist lifting drive must be automatically turned off in the extreme upper and extreme lower positions , not relying on the operator's eye and his consciousness.

The hoist movement drive is not equipped with limit switches, as it is low-speed. The operation of this drive is limited by elastic end stops that dampen shock loads.

You can buy limit switches in our office: Ekaterinburg, Zavokzalnaya st. 5, of. 207. Ask our managers for the price, delivery information, etc. by phone (343) 352-40-96, 352-44-24

Always in stock all types of seals for Bulgarian hoists:

Seal A 25 x 45
Seal A 30 x 55
Seal A 35 x 55
Seal A 45 x 70
Seal A 50 x 70
Seal A 55 x 75

Seal B100x130x12-3
Seal B130x160x15-3
Seal B20x42x10-3
Seal B25x52x10-3
Seal B30x62x10-3
Seal B65x90x10-3

Bulgarian hoist seals are parts made of technical rubber of a certain normative elasticity and chemical composition and designed to retain lubricant at the shaft reference point. In addition, the seal helps ensure more accurate shaft positioning, reducing vibration and shock loads. Structurally, the seal is a rubber ring with specified dimensions. nine0003

Seals are installed on the input shaft of the hoist gearbox and on the rotor of the hoist motor itself. Their installation location is on the side of the front and rear covers, two pieces per gearbox and per engine.

Seals designed to work as part of a gearbox are marked with the letter B in the marking, and seals for the motor rotor are marked with the letter A . However, these are not the only differences. The fact is that the design of the bearing supports of the gearbox should provide greater tightness, and for this reason, the marking of the seal B for this reason always strictly indicates the normalized thickness of the seal - from 10 to 15 mm, while for type A seals only the inner and outer diameters are indicated. nine0003

Since the nomenclature of the production of Bulgarian hoists includes models with a lifting capacity of 1 ton to tens of tons, the motors and lifting gearboxes included in them can have a wide variety of dimensions and power. Therefore, the diameters of the necks of the shaft of the gearbox and the rotor of the lifting motor can also be different. Moreover, as part of the same motor and gearbox, the front and rear journals of the shaft and rotor have different diameters and are equipped with seals of different sizes. nine0003

These factors account for the variety of A and B seal sizes and are listed above in the seal nomenclature list.

The cost of spare parts and additional information can be found by phone (343) 352-44-24

Remote control assembly

Follow the installation instructions (tightening torque, nut orientation, identification labels, selection of accessories listed in the product catalog). Proper assembly is essential to ensure proper operation of the equipment and obtain the IP rating. nine0003

Operations performed during assembly, routine maintenance or replacement of parts:

Assembly

• Carry out assembly steps in sequence (A, B, C…),
• Observe the tightening torques given in the table.
• Use all necessary items (plates, clamp, caps, nuts, etc.).

Scheduled maintenance

• Check that the screws (XX) on the rear cover are tightened to the torque given in the table. nine0083
• Check the condition and tightness (strap and screws) of the protective edge (YY + ZZ + AA),
• Check the condition of the chassis.
• Check the condition of the controls (buttons, indicators, etc.).

Replacement parts

• When replacing, use only genuine parts listed in the catalog.
• Observe the tightening torques given in the table.

Electrical wiring

• Do not lubricate controls.
• Wiring in accordance with all applicable codes and standards.
• Check that the protection class of the devices is appropriate for the environment in which they are used.

Safety regulations

Electrical shock, burns and explosion hazard:

• Turn off all power before working on this equipment. nine0083
• Do not connect more than one phase to the terminals.
• Installation, operation and maintenance of electrical devices must be performed by qualified personnel. Failure to follow these instructions will result in death or serious injury

Always in stock in our warehouse in Yekaterinburg the following retaining rings for hoists:

The electric hoist is a complex machine with many mating and rotating parts. In this case, the most important moving parts of the hoist are the moving trolley, the lifting gearbox and the hook suspension.

Minimal friction in the moving parts of these hoist assemblies is achieved by using rolling bearings. Bearings are held in place by using a wide range of circlips. In addition, the circlips ensure that the bearing and the entire assembly are always rigidly oriented along the shaft of the mechanism, and also largely prevent lubricants from falling out. nine0003

Since each hoist contains a large number of ball bearings, there are also a lot of retaining rings of types A or B . Moreover, due to the variety of sizes of these bearings and the installation dimensions of the shafts, the retaining rings also differ in variety.

To select a retaining ring for installation in a specific assembly of a specific mechanism of a specific hoist, you must first familiarize yourself with the catalog and write out a specific marking of the ring, including its diameter and a letter indicating the type (A or B).
