How big is a 305 70r17 tire

305 70r17 Inch Tire Size

If you are looking for a new set of tires, you may have come across the size 305 70r17. But what does that mean? And is it the right size for your vehicle? In this blog post, we will answer all of your questions about the 305 70r17 tire size!

Details	305/70r17 Tires
Overall Diameter	33. 9 inches or 860 mm
Section Width	12.0 inches or 305 mm
Wheel Size	17 inches or 431.8 mm
Circumference	106.4 inches or 2700.4 mm
Revolutions Per Mile	595 RPM
Sidewall Height	8. 4 inches or 214 mm
Construction Type	Radial Tire

Overall Diameter

The 305 70r17 size tire has an overall diameter of 33.9 inches or 860 mm. This is the measurement from one end of the tire to the other. It is important to know the overall diameter because it will determine if the tire will fit on your vehicle. If the overall diameter is too big or too small, it will not fit on your vehicle.

Section Width

The section width of a 305 70r17 tire is 12.0 inches or 305 mm. This is the width of the tire from one side to the other. The section width is important because it will determine how much contact the tire has with the ground. A wider tire will have more contact with the ground, providing better traction.

Circumference

The circumference of a 305 70r17 tire is 106. 4 inches or 2700.4 mm. This is the distance around the tire. The circumference is important because it will determine how far the tire will travel in one revolution. A longer circumference will mean that the tire will travel further in one revolution.

Revolutions Per Mile

The revolutions per mile (RPM) of a 305 70r17 tire is 595. This is the number of times the tire will go around in one mile. The RPM is important because it will determine how fast the tire will travel. A higher RPM will mean that the tire will travel faster.

Sidewall Height

The sidewall height of a 305 70r17 tire is 8.4 inches or 214 mm. This is the tire’s height from the edge of the rim to the top of the tire. The sidewall height is important because it will determine how much suspension travel you have. A taller sidewall will mean that you have more suspension travel.

Wheel Size

The wheel size of a 305 70r17 tire is 17 inches. This is the diameter of the wheel that the tire will fit on. The wheel size is important because it will determine the size of the tire. A larger wheel will mean that you need a larger tire.

Construction Type

The construction type of a 305 70r17 tire is radial. This means that the layers of the tire are perpendicular to the centerline of the tire. Radial tires are the most common tire type used on most passenger vehicles.

305 70R17 is the same size as 33.9x12R17. To sum up, the overall diameter is 33.9 inches, the section width is 12.00 inches, and the circumference is 106.41 inches. The sidewall height is approximately 8.4 inches, give or take a few millimeters.

The wheel size is 17 inches in diameter. And finally, the construction type is radial. I hope this blog post has answered all of your questions about the 305 70r17 tire size. If you have any other questions, feel free to leave a comment below!report this ad

Related Article

• Tire Size 305 70r18 in Inches
• 295 70r17 vs 305 70r17 Tire Size
• 305 70r17 vs 285 70r17 Tire Size

305/70R17 Tires - 17 Inch Tires

Cross Section

Aspect Ratio

Rim Diameter

• # Reflects promotional pricing.
• *** Contact Store — Product may need to be special ordered. Please call store to confirm availability and pricing.

Show Full Disclaimer

NOTE: Verification of the vehicle’s rim size must be completed if the vehicle model is available in one or more O.E. rim width options or if the vehicle is currently equipped with non-original equipment rims.
Original equipment sizes are based on the best information currently available to us. Variations based on options or changes by the manufacturer may change the original equipment size on your vehicle. Please verify the size listed matches the tire size listed on your vehicle (usually found in the door jamb) or in the Owner’s Manual. Replacement of tires with a speed rating less than the original equipment tires may reduce performance and handling.
NOTE: We make every effort to ensure that the following search results are up-to-date and accurately presented. Some variables, including vehicle modifications, “Plus Size” fitments or search menu selection errors, may result in incorrect data.
If you have any questions regarding the correct product for your vehicle, please contact a Customer Service Advisor at your local store who will assist you in selecting the correct size.
NOTE: Winter driving presents special challenges for vehicle mobility. The use of winter tires while improving traction performance in snow and ice — requires special care with regard to acceleration, braking, cornering and speed. It is important to drive with care, not only on snow and ice, but on dry and wet roads as well.
In winter driving conditions, vehicle control — and safe operation — under braking and cornering is especially dependent upon the rear tires. For this reason, winter tires are best applied to all wheel positions.
Some vehicles have specific recommendations regarding winter tires and their usage; always check and follow the vehicle tire placard and/or the vehicle owner’s manual.

• Winter tires are best applied to all wheel positions.
• If winter tires are applied to the front axle of any vehicle, they must also be installed on the rear. Do not apply winter tires to only the front axle — this applies to all passenger cars, SUVs and light trucks, including front wheel drive, 4X4 and all-wheel drive vehicles.
• If winter tires are applied to the rear axle of any vehicle, it is recommended (but not required) that they be installed on the front axle.
• All winter tires applied should be the same speed rating. It is generally acceptable to apply winter tires with a lower speed rating than the Original Equipment/All Season tires for use in winter conditions; however, speed should be reduced accordingly. Vehicles should never exceed the “top speed” of the lowest speed-rated tire on the vehicle. Otherwise, tire failure could result.
• Winter tires operated in summer conditions may wear rapidly.
• Studded tires, where legally allowed, follow the same recommendations above.

The tires you need, the quality you deserve

---

Compare best-in-class 305/70R17 tires and get an online quote or visit your local Firestone Complete Auto Care store. Evaluate tire performance, load index, warranty, speed rating, and more to choose the best style for your vehicle. Get your competitively priced tire quote and schedule an appointment for installation with one of our certified technicians today!

Legend:

• All Season
• Performance
• Summer
• Winter
• Eco-Friendly
• All Terrain

{{#if tire.tire.speedRating}}{{tire.tire.speedRating}}{{else}} NONE{{/if}}

{{#if tire.tire.mileage}}{{formatNumber tire.tire.mileage}}{{else}} No mileage warranty{{/if}}

{{tire.tire.technology}}

{{#if tire.tire.sidewallDescription}}{{tire.tire. sidewallDescription}}{{else}} NONE{{/if}}

{{{bundleWithSpan tire.tire.tireSize}}} {{{bundleWithSpan rearTire.tire.tireSize}}}

{{{checkForRetailPrice tire.tire.retailPrice rearTire.tire.retailPrice}}}

{{{offerDescriber tire.tirePromotion rearTire.tirePromotion}}}

{{{checkCharacteristic tire.tire.tireClassName tire.tire.tireName}}}

{{{checkForGetQuoteBtn tire.tire rearTire.tire storePhone tire.tire.tireInventoryId tire.tire.tireInventoryQuantity}}}

Product Name
Product Detail
Brand
Avg. Rating
Speed Rating
Mileage Warranty
Technology
Sidewall Type
Size
Price Per Tire
Special Offers
Characteristic

Please choose at least 2 tires to compare

305/70 R17 vs 305/70 R16 Tire size comparison with graphical visualization

00 2222. 52324 Your machine size / 25303540455055606570758085 R 121314151617181 Calculate 00 2222.52324 135145155165175185195205215225235245255265275285295305315325335345355365375385395 / 25303540455055606570758085 R 121314151617181 New tire size CM INCHES Index Old New Difference Diameter - - - Width - - - Circumference - - - Profile height - - - RPM - - - Clearance change - Result: - With speedometer: Real speed will be:

Comparison of 305/70 R17 and 305/70 R16 tire sizes.

In the table above you can see a detailed comparison of the difference in dimensions, parameters and performance between a 305/70 R17 tire and a 305/70 R16 tire. The results of the calculations are also presented in the form of visual models (infographics), on which the tire with a size of 305/70 R17 is on top, and with a size of 305/70 R16, respectively, at the bottom. The visualization was generated in two projections: lateral (left) and frontal (right). The online calculator compares tires according to the following characteristics: diameter, width, circumference, profile height, revolutions per km, ground clearance change. In addition, a potential deviation between the actual speed and the speed displayed on the speedometer is calculated, which can occur if the difference between tires 305/70 R17 and 305/70 R16 is significant.

If you want to compare other tyres, just select the required parameters in the drop-down fields and click on the green button.

Infographic

Side Comparison	Frontal comparison

See also:

Tire and wheel matching

Home

Contents

Tire and rim size charts

• Cars
• 4x4
• Commercial vehicles

Passenger cars (table of tire and rim sizes)

Diameter	Size	Rim width
		Min.	Recommended mend.	Max.
12	125 R12	3.5	3.0	4.0
	135 R12	4.0	3.5	4.5
	145 R12	4.0	3.5	5.0
	155 R12	4.5	4.0	5.0
	145/70 R12	4.5	4.0	5.0
	155/70 R12	4.5	4.0	5.5
13	145/80 R13	3.5	4	5
	145/70 R13	3.5	4.5	5
	145/60 R13	4	4.5	5
	155/80 R13	4	4.5	5
	155/70 R13	4	4. 5	5
	165/80 R13	4	4.5	5
	165/70 R13	4	5	5.5
	165/65 R13	4.5	5	6
	175/70 R13	4.5	5	6
	175/65 R13	5	5	6
	185/70 R13	4.5	5.5	6
14	145/65 R14	4	4.5	5
	155/65 R14	4.5	4.5	5.5
	165/70 R14	4	5	5.5
	165/65 R14	4.5	5	6
	165/60 R14	4.5	5	6
	175/80 R14	4.5	5	6
	175/70 R14	4. 5	5	6
	175/65 R14	5	5	6
	175/60 ​​R14	5	5	6
	185/70 R14	4.5	5.5	6
	185/65 R14	5	5.5	6.5
	185/60 R14	5	5.5	6.5
	185/55 R14	5	6	6.5
	195/70 R14	5	6	6.5
	195/65 R14	5.5	6	7
	195/60 R14	5.5	6	7
15	145/65 R15	4	4.5	5
	155/70 R15	4	4.5	5
	155/65 R15	4.5	4.5	5. 5
	165/65 R15	4.5	5	6
	175/65 R15	5	5	6
	175/60 ​​R15	5	5	6
	175/55 R15	5	5.5	6
	185/65 R15	5	5.5	6.5
	185/60 R15	5	5.5	6.5
	185/55 R15	5	6	6.5
	195/70 R15	5	6	6.5
	195/65 R15	5.5	6	7
	195/60 R15	5.5	6	7
	195/55 R15	5.5	6	7
	195/50 R15	5.5	6	7
	195/45 R15	6	6. 5	7.5
	205/70 R15	5	6	7
	205/65 R15	5.5	6	7.5
	205/60 R15	5.5	6	7.5
	205/55 R15	5.5	6.5	7.5
	205/50 R15	5.5	6.5	7.5
	215/70 R15	5.5	6.5	7
	215/65 R15	6	6.5	7.5
	225/60 R15	6	6.5	8
	225/55 R15	6	7	8
	225/50 R15	6	7	8
16	195/60 R16	5.5	6	7
	195/55 R16	5.5	6	7
	195/50 R16	5. 5	6	7
	195/45 R16	6	6.5	7.5
	205/60 R16	5.5	6	7.5
	205/55 R16	5.5	6.5	7.5
	205/50 R16	5.5	6.5	7.5
	205/45 R16	6.5	7	7.5
	215/65 R16	6	6.5	7.5
	215/60 R16	6	6.5	7.5
	215/55 R16	6	7	7.5
	215/40 R16	7	7.5	8.5
	225/60 R16	6	6.5	8
	225/55 R16	6	7	8
	225/50 R16	6	7	8
	235/60 R16	6. 5	7	8.5
	245/55 R16	7.5	8	9
17	205/55 R17	5.5	6.5	7.5
	205/50 R17	5.5	6.5	7.5
	205/45 R17	6.5	7	7.5
	205/40 R17	7	7.5	8
	215/60 R17	6	6.5	7.5
	215/55 R17	6	7	7.5
	215/50 R17	6	7	7.5
	215/45 R17	7	7	8
	215/40 R17	7	7.5	8.5
	225/60 R17	6	6.5	8
	225/55 R17	6	7	8
	225/50 R17	6	7	8
	225/45 R17	7	7. 5	8.5
	225/35 R17	7.5	8	9
	235/65 R17	6.5	7	8.5
	235/55 R17	6.5	7.5	8.5
	235/50 R17	6.5	7.5	8.5
	235/45 R17	7.5	8	9
	235/40 R17	8	8.5	9.5
	245/55 R17	7	7.5	8.5
	245/45 R17	7.5	8	9
	245/40 R17	8	8.5	9.5
	255/55 R17	7	8	9
	255/45 R17	8	8.5	9.5
	255/40 R17	8.5	9	10
	265/40 R17	9	9. 5	10.5
	275/40 R17	9	9.5	11
	285/40 R17	9.5	10	11
	335/35 R17	11	12	13
18	205/40 R18	7	7.5	8
	215/45 R18	7	7	8
	225/60 R18	6	6.5	8
	225/45 R18	7	7.5	8.5
	225/40 R18	7.5	8	9
	225/35 R18	7.5	8	9
	235/65 R18	6.5	7	8.5
	235/50 R18	6.5	7.5	8.5
	235/45 R18	7.5	8	9
	235/40 R18	8	8. 5	9.5
	245/50 R18	7	7.5	8.5
	245/45 R18	7.5	8	9
	245/40 R18	8	8.5	9.5
	245/35 R18	8	8.5	9.5
	255/45 R18	8	8.5	9.5
	255/40 R18	8.5	9	10
	255/35 R18	8.5	9	10
	265/40 R18	9	9.5	10.5
	265/35 R18	9	9.5	10.5
	275/45 R18	8.5	9	10.5
	275/40 R18	9	9.5	11
	275/35 R18	9	9.5	11
	285/40 R18	9. 5	10	11
	285/35 R18	9.5	10	11
	285/30 R18	10	10	10.5
	295/35 R18	10	10.5	11.5
	295/30 R18	10.5	10.5	11
	315/30 R18	11	11	12.5
	335/30 R18	12	12	12.5
	345/35 R18	11.5	12	13.5
	345/30 R18	12	12	12.5
19	225/40 R19	7.5	8	9
	225/35 R19	7.5	8	9
	235/35 R19	8	8.5	9.5
	245/45 R19	7.5	8	9
	245/40 R19	8	8. 5	9.5
	245/35 R19	8	8.5	9.5
	255/40 R19	8.5	9	10
	255/35 R19	8.5	9	10
	255/30 R19	8.5	9	9.5
	265/35 R19	9	9.5	10.5
	265/30 R19	9	9.5	10
	275/50 R19	7.5	8.5	9.5
	275/40 R19	9	9.5	11
	275/35 R19	9	9.5	11
	275/30 R19	9	9.5	10
	285/35 R19	9.5	10	11
	295/30 R19	10.5	10.5	11
	305/30 R19	11	11	12
	315/25 R19	11	11. 5	12
	325/30 R19	11	11.5	12
	345/30 R19	12	12	12.5
20	235/30 R20		8.5
	245/40 R20	8	8.5	9.5
	245/35 R20	8	8.5	9.5
	245/30 R20	8	8.5	9
	255/35 R20	8.5	9	10
	255/30 R20	8.5	9	9.5
	275/45 R20	8.5	9	10.5
	275/35 R20	9	9.5	11
	285/30 R20	10	10	10.5
	285/25 R20		10.5
	295/25 R20	10. 5	10.5	11
	305/35 R20	10	11	12
	305/25 R20	10.5	11	11.5
	325/25 R20	11.5	12	12.5
	335/30 R20	12	12	12.5
21	245/35 R21	8	8.5	9.5
	255/30 R21	9	9	9.5
	285/30 R21	10	10	10.5
	295/25 R21	10	10.5	11
22	255/30 R22	8.5	9	9.5
	295/25 R22	10.5	10.5	11

4x4 (tire and wheel size chart)

Diameter	Size	Rim width
		Min.	Recommended mend.	Max.
15	185/65 R15	5	5.5	6.5
	195/80 R15	5	5.5	6.5
	195/70 R15	5	6	6.5
	205/70 R15	5	6	7
	215/80 R15	5.5	6	7
	225/75 R15	6	6	7.5
	235/75 R15	6	6.5	8
	255/75 R15	6.5	7	8.5
	265/70 R15	7	8	9
16	205/80 R16	5	5.5	7
	215/70 R16	5. 5	6.5	7
	215/65 R16	6	6.5	7.5
	215/60 R16	6	6.5	7.5
	225/75 R16	6	6	7.5
	225/70 R16	6	6.5	7.5
	235/85 R16	6	6.5	7.5
	235/70 R16	6	7	8
	235/60 R16	6.5	7	8.5
	245/70 R16	6.5	7	8
	255/70 R16	6.5	7.5	8.5
	255/65 R16	7	7.5	9
	265/70 R16	7	8	9
	275/70 R16	7	8	9
17	225/65 R17	6	6. 5	8
	225/55 R17	6	7	8
	235/65 R17	6.5	7	8.5
	235/55 R17	6.5	7.5	8.5
	245/65 R17	7	7	8.5
	255/60 R17	7	7.5	9
	255/50 R17	7	8	9
	265/65 R17	7.5	8	9.5
	265/70 R17	7	8	9
	275/65 R17	7.5	8	9.5
	275/55 R17	7.5	8.5	9.5
18	225/55 R18	6	7	8
	235/60 R18	6.5	7	8.5
	235/50 R18	6. 5	7.5	8.5
	255/60 R18	7	7.5	9
	255/55 R18	7	8	9
	255/45 R18	8	8.5	9.5
	265/60 R18	7.5	8	9.5
	285/50 R18	8	9	10
19	255/55 R19	7	8	9
	255/50 R19	7	8	9
	275/45 R19	8.5	9	10.5
	285/45 R19	9	9.5	10.5
20	255/50 R20	7	8	9
	275/50 R20	7.5	8.5	9.5
	275/40 R20	9	9. 5	11
	295/40 R20	10	10.5	11.5
	315/35 R20	10.5	11	12.5
21	295/35 R21	10	10.5	11.5
22	285/35 R22	9.5	10	11
	295/30 R22	10	10.5	11
23	315/25 R23	11	11.5	12

Commercial vehicles (tire and rim size chart)

Diameter	Size	Rim width
		Min.	Recommended mend.	Max.
13	155/80 R13	4	4. 5	5
	165/70 R13	4.5	5	5
14	165/70 R14	4.5	5	5
	165/75 R14	4	4.5	5
	175/65 R14	5	5	5.5
	175/75 R14	4.5	5	5.5
	185/75 R14	4.5	5	6
	185/80 R14	4.5	5	6
	195/75 R14	5	5.5	6
	195/80 R14	5	5.5	6
	205/75 R14	5	5.5	6.5
15	185/80 R15	4.5	5	6
	195/70 R15	5.5	6	6
	205/65 R15	5. 5	6	6.5
	205/70 R15	5.5	6	6.5
	215/65 R15	6	6.5	7
	215/70 R15	6	6.5	7
	225/70 R15	6	6.5	7
16	6.5/100 R16	4.5	4.5	6
	175/75 R16	4.5	5	5.5
	175/80 R16	4.5	5	5.5
	185/75 R16	4.5	5	6
	195/60 R16	5.5	6	6.5
	195/65 R16	5.5	6	6
	195/75 R16	5	5.5	6
	205/65 R16	5.5	6	6. Learn more How to adopt a retired seeing eye dog How not to be tired during the day External tire patch How to decrease tire pressure How often to get tires rotated and balanced How long do winter tires last in years How to bypass a cdi box on atv Tech tyre repair How to check tire alignment How long do lawn mower tires last How often do you have to balance your tires
