Balancing beads chart


Tire Balancing Beads Application Chart

Off Road vehicles with an aggressive tire tread, add 2oz to the recommended application. ABC Balancing Beads can be installed through the valve stem. For any questions please feel free to contact us at the number located at the top of your screen.

Light Truck

6000 lbs or less

6001 lbs to 10,000 lbs

Delivery & Light Truck

10,001 lbs to 14,000 lbs

14,001 lbs to 16,000 lbs

Medium Duty Truck

16,001 lbs to 19,500 lbs

19,001 lbs to 26,000 lbs

Heavy Duty Truck & Bus

26,001 lbs to 33,000 lbs

33,001 lbs to 105,000+ lbs

Off Road and Lifted Pickups

Tire Size:
215/75R14 4oz
205/70R14 4oz
215/70R14 4oz

Tire Size:
700R15 4oz
7.50R15 6oz
8.25R15 6oz
9R15 8oz
10R15 8oz
215/80R15 4oz
195/75R15 40z
205/75R15  40z
215/75R15 4oz
225/75R15 4oz
235/75R15 4oz
245/75R15  40z
255/75R15  40z
265/75R15 40z
235/70R15  40z
245/70R15  40z
255/70R15 4oz
265/70R15 4oz
285/70R15  40z
315/70R15 6oz
245/65R15 4oz
225/60R15  4oz
325/60R15 6oz

Tire Size:
325/75R20 80z
275/65R20 6oz
275/60R20 6oz
325/60R20 6oz
255/60R20 6oz
275/55R20 4oz
285/55R20 4oz
255/50R20 4oz
285/50R20 4oz
305/50R20 6oz
325/50R20 6oz
355/50R20 6oz
325/45R20 6oz
275/40R20 6oz
315/35R20 6oz

Tire Size:
6. 5R16 4oz
7.50R16 4oz
8.25R16 6oz
1R16 8oz
215/85R16 4oz
225/85R16 4oz
245/85R16 4oz
255/85R16 4oz
265/85R16 6oz
275/85R16 6oz
205/80R16 4oz
325/80R16 6oz
175/75R16 4oz
195/75R16 4oz
225/75R16 4oz
235/75R16 4oz
245/75R16 4oz
265/75R16 6oz
285/75R16 6oz
315/75R16 6oz
215/70R16 4oz
225/70R16 4oz
235/70R16 4oz
245/70R16 4oz
255/70R16 4oz
265/70R16 4oz
275/70R16 4oz
305/70R16 4oz
315/70R16 6oz
355/70R16 6oz
365/70R16 6oz
395/70R16 6oz
195/65R16 4oz
215/65R16 4oz
225/65R16 4oz
245/65R16 4oz
255/65R16 4oz
305/65R16 4oz
345/65R16 6oz
375/65R16 6oz
215/60R16 4oz
225/60R16 4oz
235/60R16 4oz
285/60R16 4oz
255/55R16 4oz
315/55R16 4oz
345/55R16 6oz
355/55R16 6oz
375/55R16 6oz
245/50R16 4oz

Tire Size:
8R16.5 6oz
8.75R16.5 6oz
9.50R16.5 6oz
10R16.5 6oz
12R16.5 6oz

Tire Size:
235/80R17 6oz
235/75R17 6oz
245/75R17 6oz
255/75R17 6oz
245/70R17 6oz
255/70R17 6oz
285/70R17 6oz
305/70R17 6oz
315/70R17 6oz
355/70R17 6oz
255/65R17 6oz
235/65R17 4oz
245/65R17 4oz
255/65R17 4oz
265/65R17 6oz
305/65R17 6oz
375/65R17 8oz
225/60R17 4oz
235/60R17 4oz
255/60R17 6oz
275/60R17 6oz
285/60R17 6oz
225/55R17 4oz
255/55R17 4oz
275/55R17 6oz
345/55R17 6oz
255/50R17 4oz

Tire Size:
325/55R22 6oz
335/55R22 6oz
325/50R22 6oz
305/45R22 6oz
305/40R22 6oz
285/35R22 6oz

Tire Size:
8R17. 5 6oz
8.5R17.5 6oz
9R17.5 6oz
9.5R17.5 8oz
10R17.5 80z
11R17.5 80z
225/90R17.5 8oz
205/80R17.5 8oz
225/80R17.5 8oz
205/75R17.5 6oz
215/75R17.5 6oz
225/75R17.5 6oz
235/75R17.5 6oz
245/75R17.5 6oz
195/70R17.5 6oz
215/70R17.5 6oz
235/70R17.5 6oz
195/60R17.5 6oz
205/60R17.5 6oz
225/60R17.5 6oz

Tire Size:
7.50R18 8oz
255/70R18 6oz
285/60R18 6oz
325/60R18 6oz
375/60R18 8oz
395/60R18 8oz
255/55R18 4oz
275/55R18 4oz
285/55R18 4oz
285/50R18 4oz
375/50R18 6oz

Tire Size:
255/55R19 4oz
255/50R19 4oz
275/45R19 4oz
285/45R19 4oz

Tire Size:
325/45R24 6oz

Tire Size:
8R19.5 8oz
9R19.5 80z
18R19.5 14oz
280/75R19.5 8oz
285/75R19.5 8oz
225/70R19.5 8oz
245/70R19.5 8oz
265/70R19.5 8oz
275/70R19.5 10oz
285/70R19.5 10oz
305/70R19.5 12oz
385/65R19. 5 14oz
445/65R19.5 14oz

Tire Size:
7.50R20 10oz
8.25R20 10oz
9.00R20 12oz
10.00R20 12oz
11R20 14oz
12.00R20 14oz
12.5R20 14oz
14/80R20 14oz
14.00R20 16oz
365/80R20 16oz
395/80R20 16oz

Tire Size:
525/65R20.5 20oz
615/65R20.5 20oz

Tire Size:
10.00R22 12oz
1.00R22 12oz

Tire Size:
9R22.5 10oz
10R22.5 10oz
11R22.5 12oz
12R22.5 14oz
13R22.5 12oz
15R22.5 12oz
16R22.5 14oz
16.5R22.5 14oz
18R22.5 16oz
235/80R22.5 6oz
255/80R22.5 8oz
275/80R22.5 12oz
295/80R22.5 14oz
315/80R22.5 14oz
365/80R22.5 14oz
245/75R22.5 10oz
265/75R22.5 10oz
285/75R22.5 12oz
295/75R22.5 12oz
315/75R22.5 12oz
345/75R22.5 12oz
350/75R22.5 14oz
235/70R22.5 8oz
255/70R22.5 10oz
11/70R22.5 10oz
265/70R22.5 10oz
275/70R22.5 12oz
305/70R22.5 12oz
315/70R22.5 12oz
365/70R22. 5 120z
365/65R22.5 12oz
385/65R22.5 12oz
425/65R22.5 14oz
445/65R22.5 160z
285/60R22.5 10oz
295/60R22.5 10oz
305/60R22.5 10oz
315/60R22.5 10oz
385/55R22.5 12oz
455/55R22.5 16oz
275/50R22.5 10oz
445/50R22.5 16oz

Tire Size:
1.00R24 14oz
12.00R24 14oz
14.00R24 16oz
445/70R24 16oz
495/70R24 16oz

Tire Size:
11R24.5 12oz
12R24.5 14oz
285/75R24.5 12oz
305/75R24.5 12oz
315/75R24.5 12oz
275/80R24.5 12oz
295/80R24.5 12oz

MUD TERRAIN

Tire Size:
35/12.5 R20 14oz
35/13.5 R20 14oz
36/13.5 R20 14oz
37/13.5 R20 14oz
38/13.5 R20 14oz
33/12.5 R20 12oz
37/12.5 R20 14oz

33/12.5 R22 14oz
35/12.5 R22 14oz
37/12.5 R22 14oz
36/13.5 R22 112oz
37/13.5 R22 16oz
38/13.5 R22 16oz

33/12.5 R18 12oz
34/12.5 R18 12oz
35/12.5 R18 12oz
36/12.5 R18 12oz
37/12.5 R18 12oz
42/12. 5 R18 12oz

33/13.5 R18 12oz
36/13.5 R18 12oz
37/13.5 R18 14oz
38/13.5 R18 14oz
40/13.5 R18 14oz

35/14.5 R18 12oz
38/14.5 R18 14oz
40/14.5 R18 14oz
41/14.5 R18 16oz

33/12.5 R17 12oz
35/12.5 R17 12oz
37/12.5 R17 14oz

33/13.5 R17 12oz
36/13.5 R17 14oz
37/13.5 R17 14oz
40/13.5 R17 14oz

35/14.5 R17 12oz

31/12.5 R16 10oz
32/12.5 R16 10oz
33/12.5 R16 10oz
34/12.5 R16 10oz
35/12.5 R16 12oz
36/12.5 R16 12oz
37/12.5 R16 12oz

33/13.5 R16 10oz
36/13.5 R16 12oz
40/13.5 R16 14oz

33/14.5 R16 12oz
35/14.5 R16 12oz
36/14.6 R16 14oz
38/14.5 R16 14oz
40/14.5 R16 16oz

31/12.5 R15 8oz
32/12.5 R15 10oz
33/12.5 R15 10oz
34/12.5 R15 10oz
35/12.5 R15 10oz
36/12.5 R15 12oz
37/12.5 R15 12oz
38/12.5 R15 12oz

31/13.5 R15 8oz
33/13.5 R15 610oz
35/13.5 R15 12oz
37/13.5 R15 12oz
40/13.5 R15 14oz

31/14.5 R15 10oz
33/14. 5 R15 12oz
35/14.5 R15 12oz
36/14.5 R15 14oz
37/14.5 R15 14oz
40/14.5 R15 14oz

Tire Size:
27/8.5R14 4oz

Tire Size:
31/10.50R16.5 6oz
33/12.50R16.5 8oz
35/12.50R16.5 8oz
37/12.50R16.5 10oz
33/14.50R16.5 10oz
35/14.50R16.5 10oz
38/15.50R16.5 12oz
33/16.50R16.5 10oz
36/16.50R16.5 12oz
40/17B16.5 14oz
44/18.50B16.5 14oz

Tire Size:
33/12.50R17 10oz
35/12.50R17 10oz
37/12.50R17 10oz
37/13.50R17 10oz
40/13.50R17 10oz

ALL TERRAIN

Tire Size:
35/12.5 R20 12oz
35/13.5 R20 12oz
36/13.5 R20 12oz
37/13.5 R20 12oz
38/13.5 R20 12oz
33/12.5 R20 10oz
37/12.5 R20 12oz

33/12.5 R22 12oz
35/12.5 R22 12oz
37/12.5 R22 12oz
36/13.5 R22 12oz
37/13.5 R22 14oz
38/13.5 R22 14oz

33/12.5 R18 10oz
34/12.5 R18 10oz
35/12.5 R18 10oz
36/12.5 R18 10oz
37/12. 5 R18 10oz
42/12.5 R18 10oz

33/13.5 R18 10oz
36/13.5 R18 10oz
37/13.5 R18 12oz
38/13.5 R18 12oz
40/13.5 R18 12oz

35/14.5 R18 10oz
38/14.5 R18 12oz
40/14.5 R18 12oz
41/14.5 R18 14oz

33/12.5 R17 10oz
35/12.5 R17 10oz
37/12.5 R17 12oz

33/13.5 R17 10oz
36/13.5 R17 12oz
37/13.5 R17 12oz
40/13.5 R17 12oz

35/14.5 R17 10oz

31/12.5 R16 8oz
32/12.5 R16 8oz
33/12.5 R16 8oz
34/12.5 R16 8oz
35/12.5 R16 10oz
36/12.5 R16 10oz
37/12.5 R16 10oz

33/13.5 R16 8oz
36/13.5 R16 10oz
40/13.5 R16 12oz

33/14.5 R16 10oz
35/14.5 R16 10oz
36/14.6 R16 12oz
38/14.5 R16 12oz
40/14.5 R16 14oz

31/12.5 R15 8oz
32/12.5 R15 8oz
33/12.5 R15 8oz
34/12.5 R15 8oz
35/12.5 R15 8oz
36/12.5 R15 10oz
37/12.5 R15 10oz
38/12.5 R15 10oz

31/13.5 R15 8oz
33/13.5 R15 8oz
35/13.5 R15 10oz
37/13.5 R15 10oz
40/13.5 R15 12oz

31/14.5 R15 8oz
33/14. 5 R15 10oz
35/14.5 R15 10oz
36/14.5 R15 12oz
37/14.5 R15 12oz
40/14.5 R15 12oz

Tire Size:
29/9.50R15 8oz
30/9R15 8oz
33/9.50R15 8oz
31/10.50R15 8oz
33/10.50R15 8oz
31/11.50R15 8oz
32/11.50R15 8oz
31/12.50R15 8oz
32/12.50R15 8oz
33/12.50R15 8oz
35/12.50R15 8oz
36/12.50R15 10oz
37/12.50R15 10oz
35/13.50R15 10oz
31/14.50R15 8oz
33/14.50R15 10oz
36/14.50R15 10oz
38/15.50R15 12oz
33/16.50R15 10oz
36/16.50R15 12oz
40/17R15 12oz
44/18.50R15 12oz

Tire Size:
35/12.50R20 12oz

ALL SEASON

Tire Size:
35/12.5 R20 10oz
35/13.5 R20 10oz
36/13.5 R20 10oz
37/13.5 R20 10oz
38/13.5 R20 10oz
33/12.5 R20 8oz
37/12.5 R20 10oz

33/12.5 R22 10oz
35/12.5 R22 10oz
37/12.5 R22 10oz
36/13.5 R22 10oz
37/13.5 R22 12oz
38/13.5 R22 12oz

33/12.5 R18 8oz
34/12.5 R18 8oz
35/12. 5 R18 8oz
36/12.5 R18 8oz
37/12.5 R18 8oz
42/12.5 R18 10oz

33/13.5 R18 8oz
36/13.5 R18 8oz
37/13.5 R18 10oz
38/13.5 R18 10oz
40/13.5 R18 10oz

35/14.5 R18 8oz
38/14.5 R18 10oz
40/14.5 R18 12oz
41/14.5 R18 12oz

33/12.5 R17 8oz
35/12.5 R17 8oz
37/12.5 R17 10oz

33/13.5 R17 8oz
36/13.5 R17 10oz
37/13.5 R17 10oz
40/13.5 R17 10oz

35/14.5 R17 8oz

31/12.5 R16 6oz
32/12.5 R16 6oz
33/12.5 R16 6oz
34/12.5 R16 6oz
35/12.5 R16 8oz
36/12.5 R16 8oz
37/12.5 R16 8oz

33/13.5 R16 6oz
36/13.5 R16 8oz
40/13.5 R16 10oz

33/14.5 R16 8oz
35/14.5 R16 8oz
36/14.6 R16 10oz
38/14.5 R16 10oz
40/14.5 R16 12oz

31/12.5 R15 6oz
32/12.5 R15 6oz
33/12.5 R15 6oz
34/12.5 R15 6oz
35/12.5 R15 6oz
36/12.5 R15 8oz
37/12.5 R15 8oz
38/12.5 R15 8oz

31/13.5 R15 6oz
33/13.5 R15 6oz
35/13.5 R15 8oz
37/13.5 R15 8oz
40/13.5 R15 10oz

31/14. 5 R15 6oz
33/14.5 R15 8oz
35/14.5 R15 8oz
36/14.5 R15 10oz
37/14.5 R15 10oz
40/14.5 R15 10oz

Tire Size:
32/9.50R16 6oz
35/10.50R16 6oz
31/12.50R16 6oz
32/12.50R16 6oz
33/12.50R16 6oz
35/12.50R16 6oz
36/12.50R16 8oz
37/12.50R16 8oz
33/14.50R16 8oz
36/14.50R16 10oz
38/15.50R16 10oz

Tire Size:
35/12.50R18 6oz
37/12.50R18 8oz

NOTE – For aggressive Mud Terrain Tires add an additional 2oz per tire application.

Tire Balancing Charts for Light Truck, Commercial and Motorcycles

Tire Size

Single Wheel

Dual Wheel



Tire Size

Single Wheel

Dual Wheel

P205/75 R15 3 oz     LT215/85 R16 4 oz
P215/75 R15 3 oz     LT225/85 R16 5 oz
P225/75 R15 3 oz     LT235/85 R16 5 oz
P235/75 R15 4 oz     LT245/85 R16 5 oz
P265/75 R15 5 oz
P165-195/70 R15 3 oz
P205/70 R15 3 oz     LT255/85 R16 5 oz
P215/70 R15 3 oz     LT265/85 R16 5 oz
P225/70 R15 3 oz     LT275/85 R16 6 oz
P235/70 R15 4 oz     7. 50 R16 4 oz
        8.25 R16 6 oz
LT215/70 R16 4 oz     9.00 R16 8 oz
LT225/70 R16 4 oz   LT235/70 R17 5 oz
LT235/70 R16 5 oz     LT265/70 R17 5 oz
LT245/70 R16 5 oz     LT285/70 R17 5 oz
LT255/70 R16 5 oz     LT305/70 R17 6 oz
LT265/70 R16 5 oz     LT315/70 R17 6 oz
LT275/70 R16 5 oz     LT235/80 R17 5 oz
LT305/70 R16 5 oz

LT225/75 R16 4 oz
LT235/75 R16 5 oz
LT245/75 R16 5 oz
LT265/75 R16 5 oz
LT285/75 R16 5 oz


Motorcycles

Motorcycle applications are easy for all bikes, 2 wheel or 3 wheel

Front

80 - 120 mm tire width

1 oz

80 - 120 mm tire width (BMW Telelever only)

2 oz

130 mm tire width

2 oz

Rear

130 mm - 240 mm width

2 oz

250 mm - 360mm tire width

3 oz

195 - 205 car tires on the rear

3 oz

M Series Tires Sizes

MH use 80 mm width

MR use 120 mm width

MJ use 90 mm width

MT use 130 mm width

MM use 100 mm width

MU use 140 mm width

MN or MP use 110 mm width

MV use 150 mm width

These codes are typical for Harleys but can be for any tire. The codes do not go beyond 150mm in width. With these tires, the first number of the tire size is not the actual width, it is just a number. The M-code is what tells you the actual width.

Scooters

10" diameter wheels (scooters)

1 oz

12" & Up diameter wheels (scooters)

2 oz

Dual Purpose / Off Road with Rim Locks

Front - 80 - 120 mm tire width

2 oz

Rear - 130 -230 mm width

3 oz

Rim Locks - add one ounce over what you normaly use for that size tire to accomodate the additional weight of the rim lock. Two rim locks opposite each other don't require any more Dyna Beads other than stated above, as they have a tendency to cancel each other out.

Note:  Filtered valve cores do not fit all stems. They require a seat 1-1/4" down in the stem. If you cannot use them, simply rotate the tire so the valve stem is about the 6:00 position, then give the valve stem a quick shot of air prior to checking pressure.



Commercial / Large Truck

Tire Size

Single Wheel

Dual Wheel

Tire Size

Single Wheel

Dual Wheel

7.00 R15 3 oz 3 oz   7. 50 R20 8 oz 10 oz
7.50 R15 6 oz 6 oz   8.25 R20 8 oz 10 oz
8.25 R15 6 oz 6 oz   9.00 R20 10 oz 12 oz
9.00 R15 8 oz 8 oz   10. 00 R20 10 oz 12 oz
10.00 R15 8 oz 8 oz   11.00 R20 12 oz 14 oz
1000 R15 8 oz 8 oz   1000 R20 12 oz 14 oz
        12.00 R20 14 oz 16 oz
195/65 R16 4 oz 4 oz   1200 R20 14 oz 14 oz
245/65 R16 4 oz 4 oz   12. 50 R20 14 oz 16 oz
305/65 R16 4 oz 4 oz   13/80 R20 12 oz 12 oz
205/75 R16 4 oz 4 oz   14/80 R20 12 oz
225/75 R16 4 oz 4 oz   14.00 R20 16 oz
245/75 R16 4 oz 4 oz   16. 00 R20 16 oz
265/75 R16 4 oz 4 oz   275/80 R20 12 oz 14 oz
285/75 R16 5 oz 5 oz   335/80 R20 12 oz 14 oz
315/75 R16 5 oz 5 oz   365/80 R20 12 oz
215/85 R16 4 oz 4 oz
225/85 R16 5 oz 5 oz   10 R22 12 oz 14 oz
235/85 R16 5 oz 5 oz   11 R22 12 oz 14 oz
245/85 R16 5 oz 5 oz
255/85 R16 5 oz 5 oz   8 R22. 5 8 oz 10 oz
265/85 R16 5 oz 5 oz   9 R22.5 8 oz 10 oz
275/85 R16 5 oz 5 oz   10 R22.5 8 oz 10 oz
345/65 R16 5 oz 5 oz   11 R22. 5 10 oz 12 oz
7.50 R16 4 oz 4 oz   12 R22.5 12 oz 14 oz
8.25 R16 6 oz 6 oz   13 R22.5 14 oz 16 oz
9.00 R16 6 oz 6 oz   15 R22. 5 12 oz
11.00 R16 10 oz 10 oz   16.5 R22.5 14 oz
        18 R22.5 16 oz
265/70 R17 6 oz 6 oz   275/50 R22.5 10 oz 12 oz
275/70 R17 6 oz 6 oz   385/65 R22. 5 14 oz
285/70 R17 6 oz 6 oz   425/65 R22.5 16 oz
305/70 R17 6 oz 6 oz   445/65 R22.5 18 oz
        11/70 R22.5 10 oz 12 oz
        235/70 R22. 5 10 oz 12 oz
8     R17.5 5 oz 6 oz   255/70 R22.5 10 oz 12 oz
8.5  R17.5 5 oz 6 oz   265/70 R22.5 10 oz 12 oz
9     R17.5 6 oz 6 oz   275/70 R22. 5 10 oz 12 oz
9.5  R17.5 8 oz 8 oz   305/70 R22.5 10 oz 12 oz
10   R17.5 8 oz 8 oz   315/70 R22.5 10 oz 12 oz
11   R17.5 8 oz 8 oz   245/75 R22. 5 10 oz 12 oz
        265/75 R22.5 10 oz 12 oz
195/70 R17.5 5 oz 6 oz   285/75 R22.5 10 oz 12 oz
215/70 R17.5 5 oz 6 oz   295/75 R22.5 10 oz 12 oz
235/70 R17. 5 5 oz 6 oz   315/75 R22.5 10 oz
245/70 R17.5 5 oz 6 oz   345/75 R22.5 12 oz
265/70 R17.5 5 oz 6 oz   350/75 R22.5 14 oz
205/75 R17.5 5 oz 6 oz   235/80 R22. 5 10 oz 12 oz
215/75 R17.5 5 oz 6 oz   255/80 R22.5 10 oz 12 oz
225/75 R17.5 6 oz 8 oz   275/80 R22.5 10 oz 12 oz
235/75 R17.5 6 oz 8 oz   295/80 R22. 5 12 oz 12 oz
205/80 R17.5 5 oz 6 oz   315/80 R22.5 12 oz
225/80 R17.5 5 oz 6 oz   365/80 R22.5 12 oz
225/90 R17.5 6 oz 8 oz


New Michelin XDA2+ Energy

7. 50 R18 8 oz 8 oz   315/80 R22.5 12 oz
8 R19.5 6 oz 8 oz   295/80 R22.5 12 oz
9 R19.5 6 oz 8 oz   315/70 R22.5 12 oz
18 R19.5 14 oz     305/70 R22. 5 12 oz
225/70 R19.5 6 oz 8 oz   275/70 R22.5 10 oz 12 oz
245/70 R19.5 8 oz 10 oz   315/60 R22.5 12 oz
265/70 R19.5 8 oz 10 oz   295/60 R22.5 10 oz 12 oz
275/70 R19. 5 8 oz 10 oz
285/70 R19.5 8 oz 10 oz
305/70 R19.5 10 oz 12 oz
280/75 R19.5 8 oz 10 oz   11 R24 12 oz 14 oz
385/65 R19. 5 14 oz     12 R24 14 oz
425/44 R19.5 14 oz     14 R24 16 oz
435/50 R19.5 10 oz
445/45 R19.5 12 oz     11 R24.5 10 oz 12 oz
        12 R24. 5 12 oz 14 oz
        285/75 R24.5 10 oz 12 oz
        305/75 R24.5 10 oz 12 oz
        315/75 R24.5 10 oz 12 oz
        275/80 R24. 5 10 oz 12 oz
        295/80 R24.5 10 oz 12 oz


Super Singles

445/50 R22.5

Michelin X One XDA/XTE/XRV/XTA

14 oz

445/50 R22.5

Michelin X One XDA-HT Plus

16 oz

445/55 R22. 5

Michelin X One XDA-HT Plus

16 oz

445/50 R22.5

Bridgestone Greatec Drive

16 oz

445/50 R22.5

Bridgestone Greatec Trailer

14 oz

385/65 R22.5 J

GoodYear G286A

14 oz

425/65 R22.5 L

GoodYear G286A

16 oz

445/65 R22.5 L

GoodYear G286A

20 oz

Information about the equipped classrooms of the state budgetary educational institution school No.

1980, sp. Yuzhnobutovskaya d.11


Kol-in

cabinets


STOMS OF Equipment



1
1
– 1, Piano-1, VCR-1, Samsung-1 tape recorder, Samsung-1 TV, Epson-1 projector, Panasonic-1 music center

Sports hall

1

Compix. Mult. Music mon.-4, bench Gim.-4, mats-4

Group




1

Sony TV-1, VCR-1

Moscow, Chechersky pr.0004
Kol-valve

Cabinets


Sum sets of equipment

Cabinet of the Supply Article

1
9000 Xerox-2, scanner-1, LG TV-1
Psychologist's office

1

Sony video camera-1, digital multi-camera computer, Eson printer-2, printer -1

MUZ. ZAL

1

Sony-1 video camera, Piano-1 projector. 2, synthesizer -1, Overded-projector-1

Sports. Hall

1
Computer Cartoons-1, Gim.-4 wall, bench.-4, mats-4 Cabinet of the manager

1
9000
Computer cartoon. student macbook-6

Power Specialist

1
Multichenika MacBuk-2, Printer Inkjet Color.-1

The resulting educational institutions of the city of Moscow in order to move to the new federal state educational institutions standard of primary general education in
2010 academic year.


1

900
1
9000
  1. 9000
9000 . Analog input signals are shown in table 1.1

Table 1.1 - Analog input signals


No.

Demonstration beads. (Series "From 1 to 10") with methodical recommendations (Series "" From 1 to 10 ")

Consumer beads (series" from 1 to 10 ". " From 1 to 20 "," From 1 to 1 to 1 to 20 to 20 100"). Guidelines 9

1

Demonstration beads. (Series "From 1 to 20") with methodical recommendations (Series 1 to 20)

1

Counting beads (Series "From 1 to 10", "From 1 to 20", "From 1 to 100"). Guidelines

1

Magnetic poster "Mathematical boats". (Series "From 1 to 20") with guidelines

1

Magnetic boats. (Series "From 1 to 20")

1

Magnetic poster "Math boats". Guidelines. (Series "From 1 to 20")

1

Set of "materials of the ship" albums for "mathematical" tasks albums. (Series "From 1 to 20") with guidelines

25

Album of tasks "Mathematical Ships" (Series "From 1 to 20")
,0004 000
Album of tasks for the counting material "Mathematical boats". Guidelines. (Series 1 to 20)

25

Magnetic poster "Multiples table" with methodological recommendations
00 00 00 00 00 00 00 00 00 00 (Series "Multiplication Table").







1
9000 9000
1
9 9
9000 9000



When copying the material, indicate the link © 2018
Contacts
Rykovodstvo. ru


1

Magnetic poster "Multiplication table". Guidelines. (Series "Multiplication Table")

1

Set of album tasks (25 pieces) for counting material. (Series "From 1 to 1000") with methodological recommendations (Series "1 to 10000")

25

Set of laboratory equipment "From the embryo to the adult organism"

1

"From the Benzers". Teacher's manual

1

"Weight measurements" lab equipment set with teacher's manual 9Pneumatics 0015

13
  1. A set of additional elements to the designer 'Technology and Physics "with a set of tasks

13

Pneumatics. Set of additional elements to the constructor' Technology and physicist"

Pneumatic. A set of additional elements to the constructor "Technology and physics". A set of tasks (CO)

13

Methodological guide for the teacher for the use of the designer designer






























0198

Wall stand for mounting the tool

1

Tool wall plate, steel, 100x

Educational game "Book-Labyrinth" for the development of coordination of movements Toys put on toys

1

Developing game Labyrinth for the development of coordination of movements

Developing game "Raid" (floor)

1
13 Round base with colored chips

15

Palette. Cards "Perception and attention


Information on the availability of ownership or on a different legal basis ...

Information on the availability of ownership or on a different legal basis ...

Local act No. 14 Instructions for safety and rules of work in ...
Municipal educational institution "Secondary school No. 6"
I approve: Director of the MBU of the city of Kostroma
Classes are held in classrooms and workshops equipped with workplaces, safe in sanitary and epidemiological terms, having... educational institution of the city of Moscow. The main purpose of the School is to train...
Provision of classrooms, workshops n/a
Name of equipped classrooms, objects for conducting practical classes with a list of basic equipment
General information about GBOU school No. 1234
GBOU school No. 1234 is subordinate to the Moscow Department of Education and is a public educational institution
territories, type and purpose of buildings, structures, structures, premises, territories
Literature 28 General information about Tomsk State University...
General rules of conduct for employees on the territory of the university, in laboratories and classrooms, classrooms, departments Location ...
11. 01. 2016 list of instructions on labor protection competitions in the technique of hiking by teachers GBOU RK "rtsdyut"
Agreed approve
General information about the computer science classrooms of the municipal educational institution "Gymnasium No. 4"
Name of equipped classrooms, facilities for conducting... needs of gbou...
Information about the provision of the educational process80 g

Functional parameters-computer science, information technology

Domestic technical characteristics

EXITS

Unified 0-5mA, Rin = 400 Ohm; 0-20 mA, Rin = 100 Ohm; 4-20 mA, Rin = 100 Ohm; 0-10 V, Rin = 27 kOhm.
Signals of thermocouples ХА,ХК, ПП, КР, ВР according to GOST 3044-84 (initial values ​​and range are specified when ordering)
Signals of resistance thermocouples operating range is specified when ordering)
Error in converting thermocouple and resistance thermometer signals into a unified signal 0.4 %
The permits of the ACP 0.025 % (12 categories)

Analogue output signals are presented in table 1.2

Table 1.2-analogy outplace output

9000 0-5 9000 0-5 9000 0-5 9000 0-5 9000 0-5 9000 0-5 9000 0-5 9000 0-5 9000 0-5 9000 0-5 9000 0-5 9000 0-5 9000 , Rн? 2 kOhm; 0-20 mA, Rн? 0. 5 kΩ; 4-20 mA, Rн? 0.5 kΩ;
Unified
DAC resolution 0.05% (11 digits)
Maximum DAC error after calibration 0, 5%
Halvanic output Inputs are tied, each pair is isolated from the neighboring pair and from the rest of the circuits

Discrete input signals and discrete transistor output signals are presented in tables 1.3 and 1.4

- Disgro input signals

Signal logic 0 0 - 7 V
Signal logic 1 18 - 30 V
Halvanic execution Inputs are tied into groups of 16 inputs, each load is isolated from other chains

Table 1.4 - Discrete (pulsed) transistor output output 9000 9000 9000 9000 9000 B 9000 B 9002 B 9002 output 0.3 A per 12) 0.6 A Maximum total current of all simultaneously switched on outputs 2 A Type of load Active, inductive; Defending a short circuit there is

006

Table 1. 5-Discrete (pulsed) high-current relay signals

TIMRELE RPG-8
The maximum spacing of the alternating (active current) or DC 220 V
9000 2 A
Galvanic isolation Outputs connected in pairs, each pair isolated from other circuits

general functional parameters

Controller parameters are presented in Table 1.6

Table 1.6 - Controller parameters

Maximum number of algoblocks 99;
Number of algorithms in the library 76;
Cycle time, s 0.2 - 2.0;
Digital processing error
Subtraction, summation, Multiplication, division, Square root extraction 0% 0.01% 0.1%
Memory capacity: 1) ROM 2) RAM 3) PROM 32 kb; 8 kb; 8 kb.

1.2 Structural scheme PLC Remikont R-1309

Structural scheme PLC Remikont R-130 shows below in Figure 1. 1

Figure 1.1-structural scheme of PLC R-1309

in remikynta R-130 (figure 1.1) includes: the central unit - the BK-21 controller unit with the PN-21 settings panel and means of communication with the object. The power supply unit BP-21 provides power to the entire composition of Remikont R-130.

The BK-21 controller unit (Figure 1.1) includes:

a) the main part containing:

1) MCP control and programming module;

2) PRC processor module, which is directly connected to the battery, consisting of 3 pcs. elements D 0.06, and their design allows not to break this connection in order to save the memory of the PRC when removing the module;

3) stabilized voltage module MSN, which provides power to the entire BK-21 controller together with the PN-21 settings panel.

b) a variable part containing two seats for communication devices with the object USO A and USO B, each of which can include one of three modifications of USO modules:

1) MAC analog signal module;

2) analog and discrete signal module MDA;

3) MSD discrete signal module.

All other blocks shown in Figure 1.1 are used by the consumer as needed. These include:

1) block of low-level signal amplifiers and thermocouples BUT-20;

2) block of signal amplifiers for resistive sensors BUS-20;

3) BUM-20 power amplifier unit;

4) BPR switching unit - 20;

5) normalizing resistor RN-21;

6) terminal-block connectors for connections between blocks and with an object KBS-20, KBS-21, KBS-22, KBS-23;

7) power supply unit BP-21.

Front panel view is shown below in figure 1.2

Figure 1.2 — Front panel view of the control model

The view of the front panel of the setting console is shown below in Figure 1.3

Figure 1.3 — View of the front panel of the setting console

The commands for the operational control of the control loops are given in Table 1.7

Table 1.7 — The commands for the operational control of the control loops

0 9000 9000 9000 9000 9000 9000 9000 9000
Commands
N Loop selector
Loop mode selection
Transition for manual mode
manual exit change
Transition for automatic mode
Change to local mode
Change to cascade mode
Transition to manual number
manual change of assignment
Transition for software tunker
Changing program 1) Stop program
Reset program 2)
Transition to the next section of the program
Transition to an external controller

LI O signals with a flashing light about controller malfunctions. The type of malfunction can be determined by connecting the PN-21 setting console.

LI 1-4 signal with a steady light about an error in the corresponding (by number) circuit. If one or more indicators 1-4 light up, this means that in the corresponding circuit (or circuits) one of the parameters set during programming has gone beyond the permissible limits.

Having selected the circuit of interest and setting the control mode OK (circuit error), the number of the signal that has gone beyond the acceptable limits is determined by the lower DIG (if there are several such signals, the lowest number is displayed). If there are no errors, zero value is displayed on the lower DIG.

1.4 Complete list of tests Remikont R-130

Table 1.8 shows the complete list of tests Remikont R-130

Table 1.8 – List of tests Remikont R-130

9004 9000
N test Name of test Testing result
Complex (all RAM and RAM chips) 00 -the test has passed ¹00 -Numer of the non -passing test
000 ROM Chips 00 - Test Pass #00 - Test Fail Number
05-08 RAM Chips 00 - Test Pass #00 - Fail Number
Erasing PPZU 00 00 - PPZA TOSED 09 - PPZA NOT IS NOT IS IS IS
Information in the PPZU 00 - Information in the PPZA is saved 10 - Information in the PPZU Unsurient 20 - Information EEPROM not written
Continuation of Table 1. 8 — List of tests Remikont R-130
Interface exchange 00 — interface channel is faulty0013
Interface exchange rate If the result is 00 49-51s after the test start, then the test passed, otherwise the test failed. During the test, the dot on the lower DI flashes
Cycle watchdog If the DI is extinguished approximately 1s after the start of the test, then the test has passed. If code 13 appears on the lower DG, then the test failed
Settings Settings The result is controlled by indicators of the setting remote control
Personal panel The result is controlled by indicators of the front panel
DAC, group B The result is monitored at analog output
CDP, group A If there is no short circuit (short circuit) in the load, then the result is monitored by a digital output; If there is a short circuit, then on qi - code 75. 01
CDP, group B is the same as for group A, but under the KZ code 75.02

Table 1.9 - Technological Programming procedures

No. Procedures N Operations Name operations and complex parameters
Testing 01- 04 05- 09, 10 1116, 17 18, 19 Complex test test test test test tests Testrapz Testplos PN-21 settings Front panel tests DAC tests CDP tests
Instrument parameters 04, 05 0004 Initial conditions - Initial conditions at the outputs of algouses
PPZA Regeneration PPZU recording and system parameters of the Lava of Lava and the PPZO in the PPZO in the OCZO in the OCZO in the OCDO in the OCD Operator errors when controlling control loops

9000 9000 9000 9000 9000 9000 9000) input 06 of the OKO algorithm is not connected
Error code Cause of error
Lack of ALLGIRITME INDN or input 01 algorithm Eye
The Eye Algorithm Networking is not provided for
Nedimi systems for the
There is no ZDL algorithm or input 11 of the OKO 9 algorithm is not connected to it0013
The state of the program does not correspond to the one allowed for the execution of this program

CONCLUSIONS

In the course of this laboratory work, the device and technical characteristics of the PLC Remikont R-130 were studied.


Learn more
