How big is a 315 70r17 tire


35×12.5R17 vs 315/70R17 – SIZE/WEIGHT/HEIGHT/LOAD Difference – 4WheelDriveGuide

Understanding tire measurements can be very tricky and complicated, especially when tires are similar in size but described using different measurements. There is the metric measurement and the imperial or standard measurements and these can become confusing very quickly. So what is the main difference between 35×12.5R17 vs 315/70R17 tire?

The 35” tire represents the overall combined width (mm), aspect ratio (%), and wheel diameter (inches) measurement. The 315 tire measurement is a metric value and only represents the tire width which is measured in millimeters.

The two sizes are almost the same but vary somewhat between tire models and brands. Let’s find out what the exact differences are between the two tires when it comes to size, weight, height, and load ratings.

Let’s go!

Table of Contents

35×12.5R17 vs 315/70R17 – SIZE/WEIGHT/HEIGHT/LOAD Differences Explained

So let’s start with the 315/70R17 tire. This tire measurement means the tire is measured as follows:

315 – The tire width, measured in millimeters

70 – The tire aspect ratio (sidewall) height, measured in percentage

17 – The tires wheel circumference, measured in inches

Let’s see what that looks like in a formula form

Tire Size: 315/70R17 (35”)

  • 315 = the metric width of the tire measured in mm
  • 70 = the height percentage (Aspect Ratio) of the sidewall
  • (315 width x .70 = 220.5mm)
  • Divide mm by 25.4 to get inches
  • So….. 220.50 x 2 sidewalls = 441mm (divided by 25.4 = 17.36″)
  • 17.36″ + 17″ wheel = 34.362″ approximate tire diameter.

As you can see above, the 315 70 17 tire measures 12.4″ wide and 34.362″ tall.

Let’s now see how that differs to a 35/12.5R17

35×12.5R17 vs 315/70R17 – SIZE Differences

So now we know what the 315/70R17 represents, let’s look at how to read and decipher the 35×12. 5R17 measurement.

When looking at a 35×12.5R17, the 35” measurement represents the overall tire size which includes the width, aspect ratio, and wheel diameter.

The 12.5 represents the section width. The Section width is defined as the measurement between the widest point of the outside sidewall to the widest point of the inner sidewall.

17 represents the wheel diameter, measured in inches.

35×12.5R17 vs 315/70R17 – WEIGHT Differences

These two tire sizes might differ slightly in physical dimensions, however, there are factors like load ratings, tire tread pattern, tire molds, etc. that makes the difference. The weight differences can vary between 500g to 1. kg or 1.102 to 2.204 pounds.

315/70-1735/12.5-17Difference
Diameter inches (mm)34.36 (872.8)35.03 (889.72)0.67 (16. 92) 1.9%
Width inches (mm)12.4 (315)12.52 (318)0.12 (3) 1%
Circum. inches (mm)107.95 (2741.98)110.04 (2795.14)2.09 (53.16) 1.9%
Sidewall Height inches (mm)8.68 (220.5)9.01 (228.96)0.33 (8.46) 3.8%
Revolutions per mile (km)586.93 (364.7)575.77 (357.76)-11.16 (-6.94) -1.9%

35×12.5R17 vs 315/70R17 – HEIGHT Differences

As you can see in the above table, the differences in aspect ratio (sidewall height) is roughly 3.8%.

The table below will show how the aspect ratio affects the accuracy of your speedo readings.

Speedometer Difference

Speedo ReadingActual Speed
20 mph (32.19 km/h)20.39 mph (32.81 km/h)
25 mph (40.23 km/h)25.48 mph (41.01 km/h)
30 mph (48. 28 km/h)30.58 mph (49.22 km/h)
35 mph (56.33 km/h)35.68 mph (57.42 km/h)
40 mph (64.37 km/h)40.78 mph (65.62 km/h)
45 mph (72.42 km/h)45.87 mph (73.82 km/h)
50 mph (80.47 km/h)50.97 mph (82.03 km/h)
55 mph (88.51 km/h)56.07 mph (90.23 km/h)
60 mph (96.56 km/h)61.16 mph (98.43 km/h)
65 mph (104.61 km/h)66.26 mph (106.64 km/h)
70 mph (112.65 km/h)71.36 mph (114.84 km/h)
75 mph (120.7 km/h)76.45 mph (123.04 km/h)
80 mph (128.75 km/h)81.55 mph (131.24 km/h)
85 mph (136.79 km/h)86.65 mph (139.45 km/h)
90 mph (144.84 km/h)91.74 mph (147.65 km/h)
95 mph (152.89 km/h)96.84 mph (155.85 km/h)
100 mph (160.93 km/h)101.94 mph (164.05 km/h)

35×12.

5R17 vs 315/70R17 – LOAD Differences

The load range is just a complicated way of telling you what the maximum number of pounds the tire can comfortably support is. It’s a common misconception that Size and load rating are related however they actually have very little to do with each other. 315/70R17s are also available in C/D/E rages.

As you go up in ratings you get improved load carrying abilities and a beefier tire however due to the stiffer sidewall, offering little flexibility you can sacrifice ride quality and added unsprang weight.

Personally, I am a fan of XL for most 4WD ½ ton trucks and SUV applications. Here the application is key i.e. is it your daily driver or is it used as a work truck etc.

SL – Standard load, normal body ply with regular load capacity, P metric like P255/70R17
XL – Extra load, heavier body ply with high load capacity also P metric
C ply(6) rating, heavier body ply with higher load capacity, LT metric like LT285/70R17
E ply(10) rating, heavier body ply with higher load capacity also LT metric

Gas Mileage Difference between 33 and 35” Tires

You can expect 1 to 2 mpg difference when upgrading from 33” to 35“tires. The larger diameter, width, and circumference add to the unsprang weight which has a direct effect on fuel economy, performance, gearing, and other drivetrain components.

Users who have made the switch have reported a decrease of anything between 1-2mpg when cruising on the highway and 2-4mpg when driving in the city. Of course, the truck’s low-down torque and overall performance outputs play a major factor and figures will vary from vehicle to vehicle.

It’s not uncommon for Jeep Wrangler owners to fit 35” tires, since they have SFA and plenty of options to improve wheel clearance. Of course, re-gearing is key. Once you fit 35s it recommended to go with either the 5.13 or 4.88 gears. Even though frugal gas mileage shouldn’t really be your main concern when driving a 4WD, many JK owners report a drop of between

Difference between 35-Inch and 315 Tires (Metric Vs Mm)

YES, 315 wide tires are the same as 35” tires although 315 is the tread width in millimeters and 35″ is the tire diameter. 315/70/17 is usually the accepted metric equivalent size for standard/imperial 35-inch tires.

Click here to get more detail on this topic

Resources

  • https://www.tacomaworld.com/tirecalc?tires=315-70r17-35-12.5r17
  • https://www.wranglerforum.com/threads/315-70-17-vs-35-12-50-17-whats-the-load-differences.2346679/
  • https://www.jeepgladiatorforum.com/forum/threads/35×12-50r17lt-vs-lt315-70r17.16750/

Conclusion

In most cases when comparing physical differences most 35″ tires hardly crack the 34″ mark in actual tire size. If you find a tire that has both “315” and “35” measurements take a look at load range/speed rating to determine the best fit for your application.

315/70r17 vs 285/70r17 Tire Size

When buying a new tire, most drivers probably never think about the size of the tire; they just look at the price and brand. However, if you’re going to be driving on rough terrain or even on gravel roads, you need to know more about your tire size. There are three main sizes for tires: small, medium, and large. Which size is best for you? Read on to find out!

315 70r17

285 70r17

Overall Diameter 34.36 inches

Overall Diameter 32. 71 inches

Width 12.4 inches

Width 11.22 inche

Sidewall Height 8.68 inches

Sidewall Height 7.85 inches

Radial Tire (A Radial-Ply Tire)

Radial Tire (A Radial-Ply Tire)

Rim Size 17 inches

Rim Size 17 inches

Circumference 107. 95 inches

Circumference 102.76 inches

Revs Per Mile 586

Revs Per Mile 616

What Does 315 70r17 Tire Mean?

The 315 70r17 tire size is famous for many trucks and SUVs. This size offers a balance of traction, comfort, and durability. The “315” refers to the width of the Tire in millimeters.

The “70” refers to the aspect ratio, which is the height of the tire sidewall relative to the width. The “r” indicates that the Tire is a radial tire. The “17” refers to the diameter of the wheel in inches.

What Does 285 70r17 Tire Mean?

This size is very similar to the 315 70r17 dimensions. This size may be a good choice if you’re looking for a little more agility and fuel efficiency. The first number 285 refers to the width of the Tire in millimeters.

The second number, 70, still refers to the aspect ratio or height of the sidewall. The “r” still stands for radial, and the last number, 17, is still the diameter of the wheel in inches.

Tire Diameter
The diameter is the main difference between the 315 70r17 and 285 70r17 tire sizes. The 315 tires have a diameter of 34.36 inches, while the 285 tires have a diameter of 33.26 inches. This difference in diameter can affect the overall height of your vehicle. The final difference in the diameter is 1.1 inches or 3.2%.

Section Width
The section width is the width of the Tire from sidewall to sidewall. The 315 70r17 has a section width of 12.4 inches. The 285 70r17 has a section width of 11.61 inches. This difference in section width is 0.79 inches or about 6.3%.

Wider sidewall tires provide better traction and stability but may decrease fuel economy. Narrower sidewall tires may improve fuel economy but can decrease comfort and handling.

Circumference
The circumference of a tire is the distance around the outside of the Tire. The 315 70r17 has a circumference of 107.95 inches. The 285 70r17 has a circumference of 104.49 inches. This difference in circumference is about 3.2%. A larger tire covering more ground per revolution can slightly improve fuel economy.

Revolutions Per Mile
The revolutions per mile (RPM) measure how far a tire will travel in one mile. The 315 70r17 has an RPM of 586, while the 285 70r17 has an RPM of 616. This difference in RPM is about 3.3%. A higher RPM means the Tire will cover more ground in one mile.

Sidewall Height
The sidewall height is the distance from the edge of the wheel to the top of the Tire. The 315 70r17 has a sidewall height of 8.68 inches. The 285 70r17 has a sidewall height of 8.13 inches.

This difference in sidewall height is about 0.55 inches or about 6.3%. A taller sidewall height provides more cushioning and comfort but can decrease handling. A shorter sidewall height can improve handling but may decrease comfort.

Wheel Size
Rim size is an essential factor to consider when choosing a tire size. The 315 70r17 is typically mounted on wheels that are 17 inches in diameter. The 285 70r17 is generally mounted on wheels that are 17 inches in diameter. Both of these sizes can also be mounted on 17-inch wheels.

Construction Type
The 315 70r17 and 285 70r17 are both radial tires. Radial tires have steel belts that run perpendicular to the direction of travel. These tires are designed for extended wear and high speed.

Suitable Vehicle
285/70R17 tires were at the height of popularity in the mid-2000s but came back even stronger in 2019. You can find them on Jeeps, light trucks, and larger SUVs like the Jeep Wrangler Rubicon, RAM 2500 Power Wagon, and Ford Bronco.

The 315/70R17 tire size can be found on a few vehicles from the early 2000s like the Hummer and 2010-2020 Ford F-150 Raptors. If you’re considering taking your car off-roading, these are two great models to explore.

Our Observation
The main difference between 315 70r17 and 285 70r17 Tire Size is in the section width. The 315 70r17 is a wider tire and may provide better traction but decrease fuel economy. The 285 70r17 is a narrower tire and may improve fuel economy but can decrease comfort and handling.report this ad

Conclusion
Picking the correct tire size is important for many reasons. The right size can improve fuel economy, comfort, and handling. The wrong size can have the opposite effect. Comparing 315 70r17 and 285 70r17 tires can help you decide which size is right for you.

We hope you found this post helpful. If you have any questions, please feel free to contact us. Thank you for reading! We hope this post was helpful. If you have any questions, please feel free to contact us. Have a great day!

Related Article

  • 315 70r17 vs 295 70r17 Tire Size

315/70 R17 vs 335/70 R17 Graphic tire size comparison (difference in inches)

Your machine size

/ 253035404550556065707580859095100 R 121314151617181920212222. 52324

Calculate

135145155165175185195205215225235245255265275285295305315325335345355365375385395 / 253035404550556065707580859095100 R 121314151617181920212222.52324

New tire size

CM INCHES


Index Old New Difference
Diameter - - -
Width - - -
Circumference - - -
Profile height - - -
RPM - - -
Clearance change -
Result: -

With speedometer:

Real speed will be:

Size comparison between 315/70 R17 and 335/70 R17 tires.

In the table above you can see a detailed comparison of the difference in dimensions, parameters and performance between a 315/70 R17 tire and a 335/70 R17 tire. The results of the calculations are also presented in the form of visual models (infographics), on which the tire with a size of 315/70 R17 is on top, and with a size of 335/70 R17, respectively, at the bottom. The visualization was generated in two projections: lateral (left) and frontal (right). The online calculator compares tires according to the following characteristics: diameter, width, circumference, profile height, revolutions per km, ground clearance change. In addition, the potential deviation between the actual speed and the speed displayed on the speedometer is calculated, which can occur if the difference between tires 315/70 R17 and 335/70 R17 is significant. US and UK inch version of calculations.

If you want to compare other tyres, just select the required parameters in the drop-down fields and click on the green button.

Infographic

Side Comparison Frontal comparison

See also:

BF.GOODRICH All-Terrain 315/70 R17 T/A KO2

BF.GOODRICH All-Terrain KO2 315/70 R17

Further development of the proven BF.GOODRICH All-Terrain wheels. The new generation of tires, according to the manufacturer, is the most durable, reliable and durable in the history of the company.

The main differences from the previous series are:
- Increased sidewall strength by 20%, thanks to the use of advanced CoreGard ™ technology - the manufacture of the sidewalls of the tire from the rubber compound used on the Baja T / A® KR2 racing tires, which has increased strength;
- Shoulder zones made of thicker rubber and extending further into the sidewalls provide additional sidewall protection where the risk of damage is highest;
- Computer-simulated tread pattern designed to provide flotation in the harshest conditions, including gravel, mud, rocks and snow.
- The use of a new rubber compound makes it possible to increase the tread wear resistance by 15% on asphalt and by 100% on gravel, as well as uniform wear over a long period of time;
- Tires are marked 3PMSF (3 Peak Montain SnowFlake - Snowflake on the background of three peaks). This abbreviation confirms the possibility of confident driving even in the most extreme winter conditions.

Inch size 35x12.5R17
Metric size 315/70R17
Load/speed index 121S (max speed: 180 km/h or 113 mph. Max load 1450 kg.)
Disc diameter 17.0"
Line structure5 Radial 90 Tread Non-directional
Tread type Universal (AT)
Studding None
Tread Depth(x) 12mm,
Contact Patch Width (inches) (Normal Pressure) n/a
Actual Height 34.4"
Actual Width 12.70"
Recommended Wheel Size 8" - 11"
Max Pressure 4.30 atm.
Maximum load 1438 kg.
Weight 29.21 kg.
