If you have a large property, it can be difficult to maintain. If you own an ATV, one useful lawn accessory is a high-quality boom sprayer. ATV boom sprayers are particularly useful for treating your lawn, garden, trees, and more with herbicides, pesticides, water, and other treatments. Most boom sprayers can easily be mounted and attached to the rear basket of your ATV, UTV, tractor, or other vehicles. They are available in several different types with several special features to best fit your lawn care needs. Whether you are looking for great value, durability, versatility, or a user-friendly option, we took a look at the best ATV boom sprayers currently on the market. Read on to see which ATV boom sprayer is the best fit for your needs.
If you’re looking for a high-quality product, the Precision Products TCS25 Spot Sprayer may be the best ATV boom sprayer on the market. This spot sprayer can easily be mounted into the rear basket of an ATV, UTV, or other vehicles. It is extremely easy to use: simply connect to the vehicle’s 12-volt battery, fill the 25-gallon plastic tank, and use the handgun with thumb control and a 15-foot hose. It has a power rating of up to 60 PSI and sprays at a rate of up to 1.8 gallons per minute. The tank even has a drain plug for easy cleanup. This sprayer ships fully assembled and comes with a limited 90-day warranty, which will cover any immediate issues or manufacturing defects.
One downside of the Precision Products TCS25 Spot Sprayer is with its nozzle. The nozzle can be difficult to adjust, especially if you need to make adjustments on the fly or quickly while working.
Key Features
Specification
5 pounds PROS
Power rating up to 60 PSI and sprays at a rate of up to 1.8 gallons per minute
Has a drain plug for easy cleanup
Ships fully assembled and comes with a limited 90-day warranty
CONS
An issue with its nozzle
Can be difficult to adjust, especially if you need to make adjustments on the fly or quickly while working
The Master Manufacturing ATV Broadcast & Spot Sprayer is one of the best budget-friendly options available on the market today. For its price point, this spot sprayer provides excellent value. It can spray up to 18 feet vertically and 20 feet horizontally. The 15-gallon polyethylene tank is translucent to be able to see your liquid level, and it is also completely UV resistant. A durable 15-foot hose and spray gun are included with this spot sprayer. It is an ideal product for the rear of your ATV, UTV, and other vehicles. This spot sprayer delivers up to one gallon per minute of herbicides, pesticides, insecticides, disinfectants, water, and more.
There is an easily accessible molded drain port, which allows for convenient and complete drainage when you are done with your application.
One issue with the Master Manufacturing ATV Broadcast & Spot Sprayer is that the mounting kit is sold separately. To maximize your efficiency, you will need to purchase some additional items separately.
Key Features
Specification
PROS
15-gallon polyethylene tank is translucent and completely UV-resistant
Includes durable 15-foot hose and spray gun
Delivers up to 1 gallon per minute of herbicides, pesticides, insecticides, disinfectants, water, and more
CONS
Mounting kit sold separately
To maximize your efficiency, you will need to purchase some additional items separately
Although it is priced at a premium, the NorthStar Tow-Behind Spot Sprayer is another high-quality product.
This spot sprayer is designed specifically to be towed behind an ATV, UTV, tractor, or other vehicles on your property. It features a maximum power rating of 70 PSI and a 12-volt, 2.2 gallons-per-minute open flow pump. This sprayer includes a large, 31-gallon tank with extra-thick walls that are UV-resistant and compatible with almost all pesticides. The boom delivers 120 inches of overall spray width and at least 80 inches of effective spray width. The spring-loaded, breakaway boom arms fold away for convenience and a compact storage option. There are nozzle control valves on both the left and right boom arms. The tank includes a 7-1/2 inch diameter lid and a bottom drain for added convenience when filling or draining.
One downside of the NorthStar Tow-Behind Spot Sprayer is its durability. Some customers have reported that their products have arrived damaged upon delivery. If this happens with you, reach out to the company regarding a potential refund or replacement.
Key Features
2 gallons-per-minute open flow pump Specification
PROS
Includes a large, 31-gallon tank with extra-thick walls that are UV-resistant and compatible with almost all pesticides
Boom delivers 120 inches of overall spray width and at least 80 inches of effective spray width
Spring-loaded, breakaway boom arms fold away for convenience and a compact storage option
CONS
Durability issues
Some customers have reported that their products have arrived damaged upon delivery
If this happens with you, reach out to the company regarding a potential refund or replacement
The Ironton ATV Spot Sprayer is an extremely versatile product available at a nearly unbeatable price.
This spot sprayer can be attached to your ATV, UTV, or other vehicles to spot spray weeds, fence lines, and even the tops of large trees. It features a 1 gallon per minute pump and an 8-gallon tank, which is UV-resistant and compatible with virtually all pesticides. The gallon markers on the tank make it easy to monitor your fuel levels. The tank has a convenient 3 1/2-inch opening and a bottom drain that can be easily emptied. The stream has a 12-foot vertical and a 20-foot horizontal maximum spray distance. The lightweight 3/8-inch by 12-foot clear PVC hose is reinforced with a braided synthetic cord for added durability.
One issue with the Ironton ATV Spot Sprayer is that you cannot adjust the speed of the sprayer. This can be a problem for some customers, so you may want to consider another model if you need to adjust the sprayer speed.
Key Features
Specification
56 pounds PROS
Features 1 gallon per minute pump and an 8-gallon tank, which is UV-resistant and compatible with virtually all pesticides
Gallon markers on the tank make it easy to monitor your fuel levels
Tank has a convenient 3-1/2 inch opening and a bottom drain that can be easily emptied
Stream has a 12-foot vertical and a 20-foot horizontal maximum spray distance
CONS
Cannot adjust the speed of the sprayer
Can be a problem for some customers, so you may want to consider another model if you need to adjust the sprayer speed
The Chapin International 97200B Spot Sprayer is another option that is user-friendly and perfect for applications on a large area of the property. It can easily be mounted onto the back of your ATV, UTV, tractor, or other vehicles. This spot sprayer includes an adjustable nozzle that can be used for a mist or a coarse stream. The entire spray handle can easily be taken apart for simple cleaning and maintenance.
A translucent white spray tank allows you to easily see the liquid levels remaining in your tank. There is a convenient drain plug on the bottom of the tank for added convenience. The 12-volt pump allows this model to spray at a rate of up to one gallon per minute. It includes a 30-foot maximum vertical spray and an 18-foot maximum horizontal spray area.
One downside of the Chapin International 97200B Spot Sprayer is that some customers have reported issues with the drain plug and connections. There is a chance of the connections and drain plug leaking, so be aware of this if you purchase this product.
Key Features
Specification
6 pounds PROS
Entire spray handle can easily be taken apart for simple cleaning and maintenance
Translucent white spray tank allows you to easily see the liquid levels remaining in your tank
Drain plug on the bottom of the tank for added convenience
12-volt pump allows this model to spray at a rate of up to one gallon per minute
CONS
Issues with drain plug and connections
Chance of connections and drain plug leaking, so be aware of this if you purchase this product
The NorthStar High-Pressure ATV Spot Sprayer is one of the most powerful boom sprayers on the market. This product delivers 2.0 gallons per minute at wide-open flow, and it has a maximum system pressure of 200 PSI. This pump is completely resistant to harsh environments and corrosive chemicals. It is made from UV-stabilized material to prevent fading and other sun damage. The spray gun nozzle can be adjusted to three different spraying modes: stream, cone, and atomized mist.
The heavy-duty, 35-foot hose provides extended reach and flexibility to reach great heights and large trees. A large 6-inch tank lid allows for easy filling, and the tank-bottom drain provides easy emptying. There are included tie-down straps to easily attach the 16-gallon tank to your ATV, UTV, tractor, vehicle, and more.
One downside of the NorthStar High-Pressure ATV Spot Sprayer is with the seals. Some customers have reported that the seals tend to leak, so be aware of this issue if you purchase this spot sprayer.
Key Features
Specification
PROS
Made from UV-stabilized material to prevent fading and other sun damage
Spray gun nozzle can be adjusted to three different spraying modes: stream, cone, and atomized mist
Heavy-duty, 35-foot hose provides extended reach and flexibility to reach great heights and large trees
CONS
Issue with the seals
Some customers have reported that the seals tend to leak, so be aware of this issue if you purchase this spot sprayer
The Guide Gear ATV Broadcast and Spot Sprayer is another reliable product with a 16-gallon tank capacity.
It includes a 12-volt, 2.2 gallons per minute, an open-flow pump, and a pressure rating of up to 70 PSI. The chemical-resistant valves allow you to use a wide variety of chemicals and products without worry. The extra-thick tank walls are made from a chemical-resistant and UV-resistant polymer. It is fully adjustable, from a cone to a stream, and it features a 30-foot maximum horizontal and 19-foot maximum vertical spray area. The clear 15-foot PVC hose allows you to easily monitor your flow rate while working. This spot sprayer includes a 100 percent continuous duty rating, and the quick-connect ports are another user-friendly accessory.
One issue with the Guide Gear ATV Broadcast and Spot Sprayer is its durability. Some customers have reported that their product has been shipped damaged or with broken parts. If you have any issues, reach out to the company regarding a refund or potential replacement product.
Key Features
2 gallons per minute, open-flow pump, and pressure rating of up to 70 PSI Specification
PROS
Chemical-resistant valves allow you to use a wide variety of chemicals and products
Extra-thick tank walls are made from chemical-resistant and UV-resistant polymer
Fully adjustable, from a cone to a stream
Features a 30-foot maximum horizontal and 19-foot maximum vertical spray area
CONS
Issue with its durability
Some customers have reported their product has been shipped damaged or with broken parts.
If you have any issues, reach out to the company regarding a refund or potential replacement product
The NorthStar ATV Broadcast and Spot Sprayer is another very reliable and dependable product. This spot sprayer features a two-nozzle broadcast system. The included spray gun delivers a maximum vertical spray height of 19 feet and a maximum horizontal spray distance of 30 feet. The pump can deliver a flow rate of up to 2.2 gallons per minute, and it has a pressure rating of up to 70 PSI. The extra-thick walled tank holds up to 26 gallons, and it can easily be attached to the back of your ATV, UTV, tractor, or vehicle. There are an adjustable stream-to-cone brass nozzle and 15 feet of hose for added convenience. The eight-foot wire harness with battery clamps can easily connect or disconnect from your vehicle’s battery.
One issue with the NorthStar ATV Broadcast and Spot Sprayer is with its customer service. This product is usually pretty reliable, but if there are any immediate issues or damage to your product upon delivery, the company can be difficult to get in touch with online or over the phone.
Key Features
Specification
PROS
Pump can deliver a flow rate of up to 2.
2 gallons per minute
Has a pressure rating of up to 70 PSI
Extra-thick walled tank holds up to 26 gallons
Can easily be attached to the back of your ATV, UTV, tractor, or vehicle
Adjustable stream-to-cone brass nozzle and 15 feet of hose
CONS
Issue with its customer service. Usually pretty reliable, but if there are any immediate issues or damage to your product upon delivery, the company can be difficult to get in touch with online or over the phone.
An ATV boom sprayer can be an extremely useful product to assist with the maintenance and care of your lawn. ATV boom sprayers are available in a wide variety of brands, styles, shapes, and sizes. In general, they are easy to operate and can easily be attached to your ATV, UTV, tractor, or other vehicles.
The best ATV boom sprayers are durable products, built to withstand the test of time. They are made from chemical-resistant and UV-resistant materials to withstand the outdoors and hazardous materials like herbicides and pesticides.
Most ATV boom sprayers feature long hoses to reach tall trees on your property and to cover a large radius with one application.
There are several key advantages to owning and operating your own ATV boom sprayer. The most obvious benefit is that it can easily attach to your ATV, UTV, or other vehicles to cover a large area of your yard or property.
Most ATV boom sprayers are extremely durable, versatile, and user-friendly, featuring a chemical and UV-resistant tank and heavy-duty hose that can be used outdoors in all types of conditions and withstand hazardous materials like herbicides and pesticides. Make sure to read all of our reviews to determine a product that best fits your lawn care needs.
There are two main types of ATV boom sprayers. Each type of ATV boom sprayer includes its own unique set of features and key advantages. Depending on your specific needs and the size of your property, you may require a different type of ATV boom sprayer. Make sure to familiarize yourself with all of the different types of ATV boom sprayers before making your final purchase.
Rear-mounted boom sprayers are the most common type of ATV boom sprayer. This type of boom sprayer can be mounted directly to the rear of your ATV, UTV, tractor, or other vehicles.
Rear-mounted boom sprayers are extremely popular and more budget-friendly than other types of boom sprayers.
Rear-mounted boom sprayers are often shipped pre-assembled, which makes them extremely user-friendly and easy to operate. The one downside of rear-mounted boom sprayers is that they are rather heavy compared to other types of boom sprayers.
Tow behind boom sprayers is the least common type of ATV boom sprayers. This type of boom sprayer is less popular and rather expensive compared to other types of boom sprayers.
If budget is not a concern and you have a lot of money to spend, tow behind boom sprayers has a major advantage because they typically have a larger sized tank. This type of boom sprayer comes with a cart on wheels that can be attached to your ATV, UTV, tractor, or other vehicles with a hitch. This allows you to hold and apply larger amounts of herbicides, pesticides, water, or other chemicals to your property at one time.
For this article, we extensively researched and tested a wide variety of different types and brands of ATV boom sprayers. These included both rear-mounted and tow behind boom sprayers. The ATV boom sprayers were all tested for reliability, durability, ease of use, and versatility. They were all tested with a variety of chemicals and in a variety of different conditions.
The results of this thorough research and testing can be found throughout this article. Make sure to familiarize yourself with the different types, brands, and features of each ATV boom sprayer before making your final purchase.
Understanding the different types of ATV boom sprayers and the one that is the best fit for your lawn care needs is essential to properly maintaining and caring for your property. Make sure to familiarize yourself with the various types and features of all the ATV boom sprayers before making a purchase that is the best fit for your lawn. While there are several models and brands available on the market today, make sure to find one that will work with your specific preferences.
There are several DIY videos you can find to make an ATV spray boom. The pieces are quite affordable, but if you are not into DIY projects, you can purchase one of the options available from our reviews.
Typically an ATV sprayer can be attached to the rear of your ATV or attached to the hitch if it is a tow behind the sprayer. The sprayer can be attached to your ATV’s battery to provide power to function properly. Make sure to read your instruction manual and familiarize yourself with the model before using your sprayer for the first time.
A boom sprayer can be made quite easily with PVC piping. Just do your proper research and watch DIY videos online before attempting. You can also purchase one of the options available from our thorough research and reviews.
The Precision Products TCS25 Spot Sprayer is our choice for best overall ATV boom sprayer.
This ATV boom sprayer can easily be mounted into the rear basket of an ATV, UTV, or other vehicles. It is extremely easy to use: simply connect to the vehicle’s 12-volt battery, fill the 25-gallon plastic tank, and use the handgun with thumb control and a 15-foot hose.
For the best overall ATV boom sprayer, consider the Precision Products TCS25 Spot Sprayer, featuring a power rating of up to 60 PSI and a spray rate of up to 1.8 gallons per minute, or the Master Manufacturing ATV Broadcast & Spot Sprayer, which can spray an area up to 18 feet vertically and 20 feet horizontally.
