The three digits following the service type prefix (if present) tell us the cross-sectional width of the tire in millimeters.
In the example above, the tires width, measured from the widest point of the inner sidewall to the widest point of the outer sidewall when properly mounted, is 225 millimeters. The section width can be converted to inches by dividing the width in millimeters by 25.4 like so: (225 millimeters) / (25.4 mm/in) = 8.86 inches.
The two-digit number that usually follows the tire's section width tells us the aspect ratio, or tire profile measurement.
In this example, the 45 indicates that the sidewall distance, from the wheel rim to the outside of the tread, is 45% of the section width. A lower aspect ratio means a lower-profile tire with a shorter sidewall, while a tire with a higher aspect ratio will have a taller sidewall and look more like a donut. Because we know that the tire size shown in this example has a section width of 8.86 inches and the aspect ratio is 45%, the sidewall height for this tire is 3.98 inches: (8.86 inches) x (.45) = 3.98 inches.
Again using our example tire size from above, the 17 means that the tire should be matched to a 17-inch diameter wheel.
Tires usually come in the following widths (in inches): 8, 10, 12, 13, 14, 15, 17, 18, 19, 20, 22, 23, 24, 26, and 28. Tires in these sizes are typically found on most passenger cars, light-duty light trucks, SUVs, minivans, and vans. Tires with a rim diameter measured in inches are called "inch rim" sizes.
In addition to the inch rim sizes, there are also some unique tire sizes out there. Although not as common, tires are made in half-inch diameters for some heavy-duty light trucks, box vans, and heavy-duty trailers. These sizes are usually 14.
5, 15.5, 16.5, 17.5, and 19.5 inches, and an example would be 33x12.5R16.5 118R.
Tires and wheels with unique rim diameters should never be combined with traditional inch rim tires and wheels. Before mounting tires on wheels, the tire and wheel diameters should always be confirmed to match.
When a letter (R, D, or B) follows the two-digit aspect ratio, it tells us the tire's construction. In this example, the R means that the tire has radial construction. Over 98% of all tires sold today are radial tires, where the internal body plies of the tire radiate outward from the center. If there's a D instead of an R, the tire has a bias ply construction, meaning that the internal body plies of the tire crisscross on a diagonal pattern. In belted tires (marked as B), the internal plies crisscross like in a D construction, but there's also an extra layer of reinforcing belts under the tread area.
Belted tires are rarely seen these days.
Today, the only speed rating still included in the tire size is the Z rating (sports cars). Since 1991, all other speed ratings are included in the service description, as shown below.
Since 1991, the service description rating is mandatory for all speed ratings (except Z-rated tires) and appears at the end of the tire's size brand. The service description is used to identify the tire's load index (91 in the example above) and speed rating (V in the example).
For more on load indexes and speed ratings, read Breaking the tire code: Understanding tire service description, load index, and speed rating
SHOP FOR TIRES
Nitrogen vs. air: Which is best?
It’s been a hot debate amongst tire nerds for years.
We investigated and have the answer (sort of).
Original Equipment tires vs. replacement tires
Is it best to stick with your car's Original Equipment tires, or try something different? We’ll help you decide.
Your vehicle's trim/style
This is a pretty important bit of info when you’re buying tires. We’ll tell you how to find your trim level.
Our chart shows the overall section width, the outside diameter, the sidewall height and the recommended rim width range.
If your car requires something unique, start with picking the tire for the end of the car that is the most difficult.
If you’ve mini-tubbed the rear for example, and are going to run a big tire with less brand/tread/size choices, start by figuring out that size and what your options are. Then see if the those tire manufacturers also make a matching tire for your front.
We’ve included the sidewall height of the tire as a quick way to make sure your front tire doesn’t have a taller sidewall than your rear tire when doing staggered sizes.
That’s usually not a good look.
There is a recommended rim width range for any given tire size with the ideal width usually around the middle of that spread. Some things to consider are how much sidewall bulge you want to see and most importantly, how wheel width affects the tires ride, handling and wear characteristics.
For grip and even wear the wheel width needs to allow for a good contact patch where the tread meets the pavement.
A wider wheel tends to make the tire more responsive to steering inputs but also taken to extremes can make the ride harsh because the sidewall doesn’t flex as easily.
A narrower wheel can give up some of that responsive handling and will tend to give a softer ride because the sidewall has more curve that flexes more easily.
| Budnik Tire Chart | |||||
|---|---|---|---|---|---|
| SIZE | Overall Diameter | Overall (section) Width | Sidewall Height | Approx Rim Widths | Nitto Tires |
| 205/40-17 | 23. 5 | 8.1 | 3.3 | 7.0-7.5 | NT01 |
| 205/45-17 | 24.3 | 8.1 | 3.6 | 7 | |
| 205/50-17 | 25.1 | 8.1 | 4 | 7 | |
| 215/35-17 | 22.9 | 8.5 | 3 | 7.0-8.5 | |
| 215/40-17 | 23.8 | 8.5 | 3.4 | 7.0-8.5 | |
| 215/45-17 | 24.7 | 8.5 | 3.8 | 7.0-8.0 | |
| 225/35-17 | 23.2 | 8.9 | 3.1 | 7.5-9.0 | |
| 225/40-17 | 24.1 | 8.9 | 3.5 | 7.5-9.0 | |
| 225/45-17 | 25 | 8.9 | 4 | 7.0-8.5 | |
| 225/50-17 | 25.9 | 8.9 | 4.4 | 6.0-8.0 | |
| 235/40-17 | 24.4 | 9.3 | 3.7 | 8.0-9.5 | NT05,NT01 |
| 235/45-17 | 25.3 | 9.3 | 4. 2 | 7.5-9.0 | NT555, INVO |
| 235/50-17 | 26.3 | 9.3 | 4.6 | 6.5-8.5 | |
| 245/35-17 | 23.8 | 9.6 | 3.4 | 8.0-9.5 | |
| 245/40-17 | 24.7 | 9.6 | 3.9 | 8.0-9.5 | INVO |
| 245/45-17 | 25.7 | 9.6 | 4.3 | 7.5-9.0 | INVO, NT01 |
| 245/50-17 | 26.7 | 9.6 | 4.9 | 7.0-8.5 | |
| 255/40-17 | 25 | 10 | 4 | 8.5-10.0 | NT05,NT555,NT01 |
| 255/45-17 | 26 | 10 | 4.5 | 8.0-9.5 | |
| 265/40-17 | 25.3 | 10.4 | 4.2 | 9.0-10.0 | |
| 275/40-17 | 25.7 | 10.8 | 4.4 | 9.0-11.0 | |
| 275/50-17 | 27.8 | 10.8 | 5.4 | 7.5-9.5 | |
| 285/40-17 | 26 | 11. 2 | 4.5 | 9.5-11.0 | NT555 |
| 315/35-17 | 25.7 | 12.4 | 4.3 | 11.0-12.0 | NT05,NT555,NT01 |
| 18″ | Overall Diameter | Overall (section) Width | Sidewall Height | Approx Rim Widths | |
| 205/40-18 | 24.5 | 8.1 | 3.2 | 7.0-8.0 | |
| 215/35-18 | 23.9 | 8.5 | 3 | 7.0-8.5 | |
| 215/40-18 | 24.8 | 8.5 | 3.4 | 7.0-8.5 | |
| 215/45-18 | 25.6 | 8.5 | 3.8 | 7.0-8.0 | |
| 225/35-18 | 24.2 | 8.9 | 3.1 | 7.5-9.0 | |
| 225/40-18 | 25.1 | 8.9 | 3.6 | 7.5-9.0 | NT05,NT555,NT01 |
| 225/45-18 | 26 | 8.9 | 4 | 7.0-8.5 | NT555, INVO |
| 235/35-18 | 24. 5 | 9.3 | 3.2 | 9.0-9.5 | |
| 235/40-18 | 25.4 | 9.3 | 3.7 | 8.0-9.5 | NT05, NT555, NT01 |
| 235/45-18 | 26.3 | 9.3 | 4.2 | 7.5-9.0 | |
| 245/35-18 | 24.8 | 9.6 | 3.4 | 8.0-9.5 | |
| 245/40-18 | 25.7 | 9.6 | 3.9 | 8.0-9.5 | NT05,NT555,INVO,NT01 |
| 245/45-18 | 26.7 | 9.6 | 4.4 | 7.5-9.0 | NT555, INVO |
| 245/50-18 | 27.6 | 9.6 | 4.8 | 7.0-8.5 | |
| 255/35-18 | 25 | 10 | 3.5 | 8.5-10.0 | NT05, NT555 |
| 255/40-18 | 26 | 10 | 4 | 8.5-10.0 | |
| 255/45-18 | 27 | 10 | 4.5 | 8.0-9.5 | |
| 265/35-18 | 25.3 | 10.4 | 3.7 | 9.0-10.0 | NT05, NT555, INVO |
| 265/40-18 | 26. 3 | 10.4 | 4.2 | 9.0-10.0 | |
| 275/35-18 | 26.7 | 10.8 | 3.8 | 9.0-11.0 | NT555, INVO,NT01 |
| 275/45-18 | 26.7 | 10.8 | 4.9 | 8.5-10.5 | |
| 285/35-18 | 25.9 | 11.2 | 3.9 | 9.5-11.0 | NT05, NT555 |
| 295/35-18 | 26.1 | 11.6 | 4.1 | 10.0-12.0 | NT05. INVO |
| 315/30-18 | 25.4 | 12.4 | 3.7 | 11.0-12.0 | NT05,NT01 |
| 335/30-18 | 25.9 | 13.2 | 4 | 12.0-13.0 | |
| 345/30-18 | 26.1 | 13.6 | 4.1 | 12.0-14.0 | |
| 19″ | Overall Diameter | Overall (section) Width | Sidewall Height | Approx Rim Widths | |
| 225/40-19 | 26.1 | 8.9 | 3. 5 | 7.0-9.0 | NT05, INVO |
| 235/35-19 | 25.5 | 9.3 | 3.2 | 8.0-9.5 | NT05, NT555,NT01 |
| 235/40-19 | 26.4 | 9.3 | 3.7 | 8.0-9.5 | |
| 245/35-19 | 25.8 | 9.6 | 3.4 | 8.0-9.5 | NT05, NT555, INVO |
| 245/40-19 | 26.7 | 9.6 | 3.9 | 8.0-9.5 | NT05, INVO |
| 245/45-19 | 27.7 | 9.6 | 4.3 | 7.5-9.0 | |
| 255/30-19 | 25 | 10 | 3 | 8.5-9.5 | INVO |
| 255/35-19 | 26 | 10 | 3.5 | 8.5-10.0 | INVO |
| 255/40-19 | 27 | 10 | 4 | 8.5-10.0 | NT05, INVO |
| 265/35-19 | 26.3 | 10.4 | 3.7 | 9.0-10.5 | |
| 275/35-19 | 26.6 | 10.8 | 3.8 | 9.0-11.0 | INVO |
| 275/40-19 | 27. 7 | 10.8 | 4.3 | 9.0-11.0 | |
| 285/30-19 | 25.7 | 11.2 | 3.4 | 9.5-10.5 | INVO |
| 285/35-19 | 26.9 | 11.2 | 3.9 | 9.5-11.0 | INVO |
| 285/40-19 | 28 | 11.2 | 4.5 | 9.5-11.0 | |
| 295/35-19 | 27.1 | 11.6 | 4.1 | 10.0-12.0 | INVO |
| 305/30-19 | 26.2 | 12 | 3.6 | 10.5-11.5 | NT05,NT01 |
| 305/35-19 | 27.4 | 12 | 4.2 | 10.5-11.5 | |
| 315/40-19 | 28.9 | 12.4 | 5 | 11.0-12.0 | INVO |
| 325/30-19 | 26.7 | 12.8 | 3.8 | 12.0-13.0 | INVO |
| 345/30-19 | 27.1 | 13.6 | 4.1 | 12.0-14.0 | INVO |
| 345/35-19 | 28.5 | 13.6 | 4.8 | 11.0-13.5 | |
| 20″ | Overall Diameter | Overall (section) Width | Sidewall Height | Approx Rim Widths | |
| 225/35-20 | 26. 2 | 8.9 | 3.1 | 7.5-9.0 | NT555 |
| 235/30-20 | 25.6 | 9.3 | 2.8 | 8.5 | INVO |
| 235/35-20 | 26.5 | 9.3 | 3.2 | 8.0-9.5 | |
| 235/45-20 | 28.3 | 9.3 | 4.2 | 7.5-9.0 | |
| 235/55-20 | 30.2 | 9.3 | 5.1 | 6.5-8.5 | |
| 245/30-20 | 25.8 | 9.6 | 2.9 | 8.0-9.0 | NT555, INVO |
| 245/35-20 | 26.8 | 9.6 | 3.4 | 8.0-9.5 | NT555, INVO |
| 245/40-20 | 27.7 | 9.6 | 3.9 | 8.0-9.5 | NT555, INVO |
| 245/45-20 | 28.7 | 9.6 | 4.3 | 7.5-9.0 | INVO |
| 245/50-20 | 29.6 | 9.6 | 4.8 | 7.0-8.5 | |
| 255/30-20 | 26 | 10 | 3 | 8.5-9.5 | INVO |
| 255/35-20 | 27 | 10 | 3. 5 | 8.5-10 | NT05, NT555, INVO |
| 255/40-20 | 28 | 10 | 4 | 8.5-10 | NT01 |
| 255/45-20 | 29 | 10 | 4.5 | 8.0-9.5 | NT05, INVO |
| 255/50-20 | 30 | 10 | 5 | 7.0-9.0 | |
| 255/55-20 | 31 | 10 | 5.5 | 7.0-9.0 | |
| 265/30-20 | 26.3 | 10.4 | 3.1 | 9.0-10.0 | |
| 265/35-20 | 27.3 | 10.4 | 3.7 | 9-10.5 | NT555 |
| 265/40-20 | 28.3 | 10.4 | 4.2 | 9.0-10.5 | |
| 265/45-20 | 29.4 | 10.4 | 4.7 | 8.5-10.0 | |
| 275/30-20 | 26.5 | 10.8 | 3.2 | 9.0-10.0 | NT555, INVO |
| 275/35-20 | 27.6 | 10.8 | 3.9 | 9.0-11.0 | NT05, NT555, INVO |
| 275/40-20 | 28. 7 | 10.8 | 4.3 | 9.0-11.0 | INVO |
| 275/45-20 | 29.7 | 10.8 | 4.9 | 8.5-10.0 | |
| 285/30-20 | 26.7 | 11.2 | 3.4 | 9.5-10.5 | NT555, INVO |
| 285/35-20 | 27.9 | 11.2 | 3.9 | 9.5-11.0 | NT01 |
| 285/40-20 | 29 | 11.2 | 4.5 | 9.5-11.0 | |
| 285/45-20 | 30.1 | 11.2 | 5 | 9.0-10.5 | |
| 295/30-20 | 27 | 11.6 | 3.5 | 10.0-11.0 | |
| 295/35-20 | 28.1 | 11.6 | 4.1 | 10.0-11.5 | INVO |
| 295/40-20 | 29.3 | 11.6 | 4.6 | 10.0-12.0 | |
| 295/45-20 | 30.5 | 11.6 | 5.2 | 9.5-11.0 | |
| 295/50-20 | 31.6 | 11.6 | 5.8 | 8.0-10.5 | |
| 305/35-20 | 28. 4 | 12 | 4.2 | 10.0-12.0 | |
| 305/40-20 | 29.6 | 12 | 4.8 | 10.0-12.0 | |
| 315/35-20 | 28.7 | 12.4 | 4.3 | 10.5-12.5 | NT05, INVO |
| 335/25-20 | 26.6 | 13.2 | 4 | 12.0-13.00 | |
| 335/30-20 | 27.9 | 13.2 | 4 | 11.5-12.5 | |
| 345/25-20 | 26.8 | 13.6 | 3.4 | 12.0-13.0 | INVO |
| LT TRUCK | Overall Diameter | Overall (section) Width | Sidewall Height | Approx Rim Widths | |
| 265/60-20 | 32.5 | 10.4 | 6.3 | 7.5-9.5 | TERRA |
| 275/60-20 | 33 | 10.8 | 6.5 | 7.5-9.5 | TERRA |
| 285/55-60 | 32.3 | 11.2 | 6.2 | 8.0-10. 0 | TERRA |
| 285/60-20 | 33.5 | 11.2 | 6.7 | 8.0-10.0 | |
| 305/55-20 | 33.2 | 12 | 6.6 | 8.5-11.0 | TERRA |
| 22″ | Overall Diameter | Overall (section) Width | Sidewall Height | Approx Rim Widths | |
| 235/30-22 | 27.6 | 9.3 | 2.8 | 8.5 | |
| 245/30-22 | 27.8 | 9.6 | 2.9 | 8.0-9.0 | NT555, INVO |
| 255/30-22 | 28 | 10 | 3 | 8.0-8.5 | NT555, INVO |
| 255/35-22 | 29 | 10 | 3.5 | 8.5-10 | INVO |
| 265/30-22 | 28.3 | 10.4 | 3.1 | 9.0-10.0 | INVO |
| 265/35-22 | 29.3 | 10.4 | 3.7 | 9.0-10.5 | 420S |
| 265/40-22 | 30. 3 | 10.4 | 4.2 | 9.0-10.5 | 420S, NT555 |
| 265/45-22 | 31.4 | 10.4 | 4.7 | 8.5-10.0 | |
| 275/30-22 | 28.5 | 10.8 | 3.2 | 9.0-10.0 | INVO |
| 275/40-22 | 30.7 | 10.8 | 4.3 | 9.0-11.0 | 420S |
| 275/45-22 | 31.7 | 10.8 | 4.9 | 8.5-10.0 | 420S |
| 285/30-22 | 28.7 | 11.2 | 3.4 | 9.5-10.5 | INVO |
| 285/35-22 | 29.9 | 11.2 | 3.9 | 9.5-11.0 | 420S, NT555 |
| 285/40-22 | 31 | 11.2 | 4.5 | 9.5-11.0 | 420S |
| 285/45-22 | 32.1 | 11.2 | 5 | 9.0-11.0 | |
| 295/30-22 | 29 | 11.6 | 3.5 | 10.0-11.0 | |
| 295/45-22 | 32.5 | 11.6 | 5.2 | 9.5-11.0 | |
| 305/35-22 | 30. 4 | 12 | 4.2 | 10.5-11.5 | |
| 305/40-22 | 31.6 | 12 | 4.8 | 10.0-12.0 | |
| 305/45-22 | 32.8 | 12 | 5.4 | 9.0-1.0 | |
| 315/25-22 | 28.2 | 12.4 | 3.1 | 11.0-12.0 | |
| 335/25-22 | 28.5 | 10.8 | 3.2 | 11.5-12.5 | |
| 335/30-22 | 28.7 | 13.7 | 3.3 | 12.0-13.0 |
home
Articles
* These tables are for informational purposes only and are not intended as a guide to action. For specific applicability of non-standard discs, please contact the vehicle manufacturer or vehicle dealer. We do not test wheel interchangeability and cannot make recommendations.
| Landing width of the disk | Minimum tire width | Optimum tire width | Maximum tire width |
|---|---|---|---|
5. 0 inches | 155 mm | 165 or 175 mm | 185 mm |
| 5.5 inches | 165 mm | 175 or 185 mm | 195 mm |
| 6.0 inches | 175 mm | 185 or 195 mm | 205 mm |
| 6.5 inches | 185 mm | 195 or 205 mm | 215 mm |
| 7.0 inches | 195 mm | 205 or 215 mm | 225 mm |
| 7.5 inches | 205 mm | 215 or 225 mm | 235 mm |
| 8.0 inches | 215 mm | 225 or 235 mm | 245 mm |
| 8.5 inches | 225 mm | 235 or 245 mm | 255 mm |
| 9.0 inches | 235 mm | 245 or 255 mm | 265 mm |
| 9.5 inches | 245 mm | 255 or 265 mm | 275 mm |
10. 0 inches | 255 mm | 265 or 275 mm | 285 mm |
| 10.5 inches | 265 mm | 275 or 285 mm | 295 mm |
| 11.0 inches | 275 mm | 285 or 295 mm | 305 mm |
| 11.5 inches | 285 mm | 295 or 305 mm | 315 mm |
| 12.0 inches | 295 mm | 305 or 315 mm | 325 mm |
| 12.5 inches | 305 mm | 315 or 325 mm | 335 mm |
| Profile | Designation in metric dimension | Permissible range of landing width of the disc |
|---|---|---|
| 35 Series | 275/35R17 | 9.0-10.5 |
| 335/35R17 | 11. 0-13.0 | |
| 345/35R15 | 11.0-13.5 | |
| 40 Series | 285/40R15 | 11.0-13.5 |
| 215/40R15 | 7.0-8.5 | |
| 245/40R17 | 8.0-9.5 | |
| 255/40R17 | 8.5-10.0 | |
| 265/40R17 | 8.5-10.0 | |
| 235/40R18 | 8.0-9.5 | |
| 45 Series | 195/45/R15 | 6.5-7.5 |
| 215/45R15 | 7.0-8.5 | |
| 255/45R15 | 8.5-10.0 | |
| 205/45R16 | 7.0 | |
| 225/45R16 | 7.5-9.0 | |
| 245/45R16 | 8.0-9.5 | |
| 215/45R17 | 7.0-8.5 | |
| 235/45R17 | 8.0-9.5 | |
| 255/45R17 | 8. 5-10.5 | |
| 50 Series | 175/50R13 | 5.0-6.0 |
| 195/50R14 | 5.5-7.0 | |
| 205/50R15 | 5.5-7.5 | |
| 215/50R15 | 6.0-7.5 | |
| 225/50R15 | 6.0-8.0 | |
| 195/50R16 | 5.5-7.0 | |
| 205/50R16 | 5.5-7.5 | |
| 225/50R16 | 6.0-8.0 | |
| 235/50R16 | 6.5-8.5 | |
| 215/50R17 | 6.5-7.5 | |
| 55 Series | 205/55R14 | 5.5-7.5 |
| 185/55R15 | 6.0-6.5 | |
| 195/55R15 | 5.5-7.0 | |
| 205/55R15 | 5.5-7.5 | |
| 205/55R16 | 5.5-7.5 | |
| 225/55R16 | 6. 0-8.0 | |
| 60 Series | 185/60R13 | 5.0-6.5 |
| 205/60R13 | 5.5-7.5 | |
| 185/60R14 | 5.0-6.5 | |
| 195/60R14 | 5.5-7.0 | |
| 205/60R14 | 5.5-7.5 | |
| 195/60R15 | 5.5-7.0 | |
| 205/60R15 | 5.5-7.5 | |
| 215/60R15 | 6.0-7.5 | |
| 225/60R15 | 6.0-8.0 | |
| 235/60R15 | 6.5-8.5 | |
| 65 Series | 185/65R15 | 5.0-6.5 |
| 195/65R15 | 5.5-7.0 | |
| 205/65R15 | 5.5-7.5 | |
| 215/65R15 | 6.0-7.5 | |
| 70 Series | 165/70R10 | 4.5-5.5 |
| 175/70R12 | 5. 0-6.0 | |
| 175/70R13 | 5.0-6.0 | |
| 205/45R16 | 7.0 | |
| 185/70R13 | 5.0-6.5 | |
| 185/70R14 | 5.0-6.5 | |
| 195/70R15 | 5.5-7.0 | |
| 205/70R14 | 5.5-7.5 | |
| 185/70R15 | 5.0-6.5 | |
| 205/70R15 | 5.5-7.5 | |
| 215/70R15 | 6.0-7.5 | |
| 82 Series | 155R12 | 4.0-5.0 |
| 155R13 | 4.0-5.5 | |
| 165R13 | 4.0-5.5 | |
| 175R14 | 4.5-6.0 | |
| 185R14 | 4.5-6.0 | |
| 165R15 | 4.0-5.5 | |
| Profile | Designation in metric dimension | Permissible range of landing width of the disc |
|---|---|---|
| 75 Series | P205/75R15 | 5. 5-7.5 |
| P215/75R15 | 5.5-7.5 | |
| P225/75R15 | 6.0-8.0 | |
| P235/75R15 | 6.0-8.0 | |
| 80 Series | P155/80R13 | 4.5-5.5 |
| P165/80R13 | 4.5-6.0 | |
| P175/80R13 | 4.5-6.0 | |
| P185/80R13 | 5.0-6.5 | |
| 35 Series | P315/35R17 | 10.0-12.0 |
| 40 Series | P275/40R17 | 8.5-10.0 |
| 50 Series | P215/50R13 | 5.5-8.5 |
| P235/50R13 | 6.0-9.0 | |
| P245/50R14 | 6.5-9.0 | |
| P225/50R15 | 6.0-8.0 | |
| P295/50R15 | 7.5-11.0 | |
| P225/50R16 | 6. 0-8.0 | |
| P245/50R16 | 6.5-9.5 | |
Return to list
Tire and wheel size matching is an important step towards safety and driving comfort for any driver. A frivolous attitude to this issue is fraught with serious consequences, both for the technical condition of the vehicle, and for the health and life of drivers and passengers. Consider this problem on SUVs, crossovers or pickup trucks of various classes. Of course, here the size range is not so large, which makes it easier to select discs for tires. To begin with, it is worth recalling what indicators are important when deciding whether tires and wheels match:
Wheel marking with dimensions R13 4x98 ET35 J5 D58.6
The table below shows almost all off-road vehicle wheel sizes. We remind you that on our website there is also an option for selecting discs by car brand .
Also on our website there is similar information regarding cars .
Tire/rim matching chart
| Wheel diameter | Tire size | Wheel rim width (inches) | ||
| Minimum | Recommended | Maximum | ||
| 16" | 7.50R16 | 5.50 | 6.00 | 6.50 |
| 235/85R16 | 6.0 | 6.5 | 7.5 | |
| 15" | 195/80R15 | 5.0 | 5.5 | 6.5 |
| 215/80R15 | 5. 5 | 6.0 | 7.0 | |
| 16" | 205/80R16 | 5.0 | 5.5 | 7.0 |
| 215/80R16 | 5.5 | 6.0 | 7.0 | |
| 15" | 215/75R15 | 5.5 | 6.0 | 7.0 |
| 225/75R15 | 6.0 | 6.0 | 7.5 | |
| 235/75R15 | 6.0 | 6.5 | 8.0 | |
| 255/75R15 | 6.5 | 7.0 | 8.5 | |
| 16" | 225/75R16 | 6. 0 | 6.0 | 7.5 |
| 15" | 195/70R15 | 5.0 | 6.0 | 6.5 |
| 205/70R15 | 5.0 | 6.0 | 7.0 | |
| 265/70R15 | 7.0 | 8.0 | 9.0 | |
| 16" | 215/70R16 | 5.5 | 6.5 | 7.0 |
| 225/70R16 | 6.0 | 6.5 | 7.5 | |
| 235/70R16 | 6.0 | 7.0 | 8.0 | |
| 245/70R16 | 6. 5 | 7.0 | 8.0 | |
| 265/70R16 | 7.0 | 8.0 | 9.0 | |
| 275/70R16 | 7.0 | 8.0 | 9.0 | |
| 17" | 225/70R17 | 6.0 | 6.5 | 7.5 |
| 265/70R17 | 7.0 | 8.0 | 9.0 | |
| 15" | 185/65R15 | 5.0 | 5.5 | 6.5 |
| 16" | 215/65R16 | 6.0 | 6.5 | 7.5 |
| 255/65R16 | 7. | 7.5 | 9.0 | |
| 17" | 235/65R17 | 6.5 | 7.0 | 8.5 |
| 245/65R17 | 7.0 | 7.0 | 8.5 | |
| 265/65R17 | 7.5 | 8.0 | 9.5 | |
| 275/65R17 | 7.5 | 8.0 | 9.5 | |
| 16" | 215/60R16 | 6.0 | 6.5 | 7.5 |
| 236/60R16 | 6.5 | 7.0 | 8.5 | |
| 18" | 235/60R18 | 6. 5 | 7.0 | 8.5 |
| 275/60R18 | 7.5 | 8.0 | 9.5 | |
| 285/60R18 | 8.0 | 8.5 | 10.0 | |
| 17" | 225/55R17 | 6.0 | 7.0 | 8.0 |
| 235/55R17 | 6.5 | 7.5 | 8.5 | |
| 275/55R17 | 7.5 | 8.5 | 9.5 | |
| 18" | 255/55R18 | 7.0 | 8.0 | 9.0 |
| 19" | 255/55R19 | 7. 0 | 8.0 | 9.0 |
| 275/55R19 | 7.5 | 8.5 | 9.5 | |
| 285/55R19 | 8.0 | 9.0 | 10.0 | |
| 17" | 255/50R17 | 7.0 | 8.0 | 9.0 |
| 18" | 235/50R18 | 6.5 | 7.5 | 8.5 |
| 285/50R18 | 8.0 | 9.0 | 10.0 | |
| 19" | 255/50R19 | 7.0 | 8.0 | 9.0 |
| 20" | 255/50R20 | 7. 0 | 8.0 | 9.0 |
| 275/50R20 | 7.5 | 8.5 | 9.5 | |
| 18" | 255/45R18 | 8.0 | 8.5 | 9.5 |
| 19" | 235/45R19 | 7.5 | 8.0 | 9.0 |
| 275/45R19 | 8.5 | 9.0 | 10.5 | |
| 285/45R19 | 9.0 | 9.5 | 10.5 | |
| 20" | 265/45R20 | 8.5 | 9.0 | 10.0 |
| 19" | 255/40R19 | 8. 5 | 9.0 | 10.0 |
| 20" | 275/40R20 | 9.0 | 9.5 | 11.0 |
| 20" | 315/35R20 | 10.5 | 11.0 | 12.5 |
| 21" | 285/35R21 | 9.5 | 10.0 | 11.0 |
| 22" | 285/35R22 | 9.5 | 10.0 | 11.0 |
| 21" | 325/30R21 | 11.5 | 11.5 | 13.0 |
| 22" | 295/30R22 | 10. 5 | 10.5 | 11.5 |
| Tire labels - how to read? From November 1, 2012, tires sold in countries within the European Union must have special stickers. They contain information, in particular, about the fuel.. 11 July 2022, 11:34 | |
| Causes of tire wear Tire wear is often the result of too much speed at which we move. However, there are many more factors influencing this process. Tire condition during .. July 04, 2022, 11:58 | |
| What is the minimum tread depth allowed? The tread of a tire is sometimes analyzed in terms of appearance and shape, modern technologies implemented by the manufacturer, or performance in winter conditions.   | |
